Page 305 of 3502

NISSAN TEANA 2003 Service Manual REPAIR FOR COMPONENT PARTS AT-297 D E F G H I J K L MA B AT 4. Set SST on spring retainer, and remove snap ring from reverse clutch drum while compressing return spring. CAUTION: Set SST directly o

Page 306 of 3502

NISSAN TEANA 2003 Service Manual AT-298 REPAIR FOR COMPONENT PARTS ASSEMBLY 1. Install D-ring (1) and seal lip (2) on reverse clutch piston (3). CAUTION: Be careful to direction of seal lip (2). 2. Install reverse clutch piston by

Page 307 of 3502

NISSAN TEANA 2003 Service Manual REPAIR FOR COMPONENT PARTS AT-299 D E F G H I J K L MA B AT 5. Install drive plates, driven plates, retaining plate and dish plates. Refer to AT- 3 6 6 , " REVERSE CLUTCH" . CAUTION: Be careful to

Page 308 of 3502

NISSAN TEANA 2003 Service Manual AT-300 REPAIR FOR COMPONENT PARTS 7. Measure clearance between retaining plate and snap ring with feeler gauge. If not within allowable limit, select proper retaining plate. Refer to “Parts Inform

Page 309 of 3502

NISSAN TEANA 2003 Service Manual REPAIR FOR COMPONENT PARTS AT-301 D E F G H I J K L MA B AT High ClutchBCS001OP COMPONENTS DISASSEMBLY 1. Check operation of high clutch. a. Apply compressed air to oil hole of input shaft assembly

Page 310 of 3502

NISSAN TEANA 2003 Service Manual AT-302 REPAIR FOR COMPONENT PARTS 3. Remove snap ring with flat-bladed screwdriver. 4. Remove drive plates, driven plates and retaining plate. 5. Set SST on spring retainer assembly, and remove snap

Page 311 of 3502

NISSAN TEANA 2003 Service Manual REPAIR FOR COMPONENT PARTS AT-303 D E F G H I J K L MA B AT INSPECTION High Clutch Snap Rings and Spring Retainer Assembly Check for deformation, fatigue or damage. Replace if necessary. High Clutch

Page 312 of 3502

NISSAN TEANA 2003 Service Manual AT-304 REPAIR FOR COMPONENT PARTS ASSEMBLY 1. Install D-rings on high clutch piston. 2. Install high clutch piston on input shaft assembly (high clutch drum) by turning it slowly. CAUTION: Apply ATF
