Page 2321 of 3502

NISSAN TEANA 2003 Service Manual CYLINDER HEAD EM-213 [VQ] C D E F G H I J K L MA EM Cylinder Head Distortion NOTE: When performing this inspection, cylinder block distortion should be also checking. Refer to EM-248, " CYLIN- DER B

Page 2322 of 3502

NISSAN TEANA 2003 Service Manual EM-214 [VQ] CYLINDER HEAD e. Turn all cylinder head bolts 90 degrees clockwise. (Angle tight- ening) CAUTION: Check the tightening angle by using angle wrench (SST). Avoid judgment by visual inspect

Page 2323 of 3502

NISSAN TEANA 2003 Service Manual CYLINDER HEAD EM-215 [VQ] C D E F G H I J K L MA EM INSPECTION AFTER INSTALLATION Inspection for Leaks The following are procedures for checking fluids leak, lubricates leak and exhaust gases leak.

Page 2324 of 3502

NISSAN TEANA 2003 Service Manual EM-216 [VQ] CYLINDER HEAD DISASSEMBLY 1. Remove spark plug with spark plug wrench (commercial service tool). 2. Remove valve lifter. Identify installation positions, and store them without mixing t

Page 2325 of 3502

NISSAN TEANA 2003 Service Manual CYLINDER HEAD EM-217 [VQ] C D E F G H I J K L MA EM 3. Install valve oil seal. Install with valve oil seal drift (SST) to match dimension in the figure. 4. Install valve spring seat. 5. Install val

Page 2326 of 3502

NISSAN TEANA 2003 Service Manual EM-218 [VQ] CYLINDER HEAD c. Using drift, press-fit spark plug tube so that its height “H” is as specified in the figure. CAUTION: When press-fitting, take care not to deform spark plug tube.

Page 2327 of 3502

NISSAN TEANA 2003 Service Manual CYLINDER HEAD EM-219 [VQ] C D E F G H I J K L MA EM If it exceeds the limit, replace valve and/or valve guide. When valve guide must be replaced, refer to EM- 219, "VALVE GUIDE REPLACEMENT" . VALVE

Page 2328 of 3502

NISSAN TEANA 2003 Service Manual EM-220 [VQ] CYLINDER HEAD 5. Using valve guide drift (commercial service tool), press valve guide from camshaft side to the dimensions as in the figure. CAUTION: Cylinder head contains heat. When wo
