NISSAN TEANA 2003 Service Manual POWER WINDOW SYSTEM GW-27 C D E F G H J K L MA B GW Terminal and Reference Value for BCMBIS000ZB Terminal and Reference Value for Power Window Main SwitchBIS000ZC Te r m i - nalWire colorItemSignal

Page 2522 of 3502

NISSAN TEANA 2003 Service Manual GW-28 POWER WINDOW SYSTEM Work FlowBIS000ZD 1. Check the symptom and customers requests. 2. Understand the outline of system. Refer to GW-17, " System Description" . 3. According to the trouble dia

Page 2523 of 3502

NISSAN TEANA 2003 Service Manual POWER WINDOW SYSTEM GW-29 C D E F G H J K L MA B GW Trouble Diagnosis Symptom ChartBIS000ZE Make sure other systems using the signal of the following systems operate normally. Symptom Repair orderRe

Page 2524 of 3502

NISSAN TEANA 2003 Service Manual GW-30 POWER WINDOW SYSTEM Check BCM Power Supply and Ground Circuit BIS000ZF 1. CHECK FUSE 10A fuse [No.1, located in fuse block (J/B)] 15A fuse [No.17, located in fuse block (J/B)] 50A fusible l

Page 2525 of 3502

NISSAN TEANA 2003 Service Manual POWER WINDOW SYSTEM GW-31 C D E F G H J K L MA B GW 2. CHECK GROUND CIRCUIT 1. Turn ignition switch OFF. 2. Disconnect power window main switch connector. 3. Check continuity between power window ma

Page 2526 of 3502

NISSAN TEANA 2003 Service Manual GW-32 POWER WINDOW SYSTEM Check Front Power Window Motor (Driver Side) Circuit BIS000ZH 1. CHECK POWER WINDOW MAIN SWITCH OUTPUT SIGNAL 1. Turn ignition switch OFF. 2. Disconnect front power window

Page 2527 of 3502

NISSAN TEANA 2003 Service Manual POWER WINDOW SYSTEM GW-33 C D E F G H J K L MA B GW Check Front Power Window Motor (Passenger Side) Circuit BIS000ZI 1. CHECK POWER WINDOW SWITCH OUTPUT SIGNAL 1. Turn ignition switch OFF. 2. Discon

Page 2528 of 3502

NISSAN TEANA 2003 Service Manual GW-34 POWER WINDOW SYSTEM 4. CHECK FRONT POWER WINDOW SWITCH POWER SUPPLY 1. Turn ignition switch ON. 2. Check voltage between front power window switch (passenger side) connector D36 terminal 1 an
