NISSAN TEANA 2003 Service Manual GENERAL MAINTENANCE
MA-7
C
D
E
F
G
H
I
J
K
MA
B
MA

UNDER THE HOOD AND VEHICLE
The maintenance items listed here should be checked periodically e.g. each time you check the engine oil or refuel.
Item

Page 2986 of 3502

NISSAN TEANA 2003 Service Manual MA-8
PERIODIC MAINTENANCE

PERIODIC MAINTENANCEPFP:00026
Periodic MaintenanceBLS0008Z
The following tables show the normal maintenance schedule. Depending upon weather and atmospheric con-
ditions, v

MA-8
PERIODIC MAINTENANCE

PERIODIC MAINTENANCEPFP:00026
Periodic MaintenanceBLS0008Z
The following tables show the normal maintenance schedule. Depending upon weather and atmospheric con-
ditions, varying road surfaces, individual driving habits and vehicle usage, additional or more frequent mainte-
nance may be required.
Periodic maintenance beyond the last period shown on the tables requires similar maintenance.
ENGINE AND EMISSION CONTROL MAINTENANCE
(Annual Mileage <30,000 Km [18,000 miles]/year)
QR and VQ ENGINE
Abbreviations: I = Inspect and correct or replace as necessary, R = Replace
[ ] = At the specified distance only
NOTE:
(1) Periodic maintenance is not required. However, if valve noise increases, check valve clearance.
(2) Replace the drive belt if found damaged or if the auto tensioner reading (for QR20DE engine) reaches the maximum
limit.
(3) First replace at 100,000 km (60,000 miles)/60 months, then every 60,000 km (36,000 miles)/48 months. Perform “I”
(Checking the mixture ratio and correcting the mixture ratio if necessary) at the middle of replacement interval.
(4) Fuel filter is maintenance-free. For service procedures, refer to FL section.
(5) Perform only according to “Maintenance Under Severe Driving Conditions” for models without Euro-OBD system.
Maintenance items with “ ” should be performed more frequently according to “Maintenance Under Severe Driving
Conditions”. MAINTENANCE OPERATIONMAINTENANCE INTERVAL Reference page
Perform either at number of kilometers
(miles) or months, whichever comes first.km x
1,000
(Miles x
1,000)
Months15
(9)
1230
(18)
2445
(27)
3660
(36)
4875
(45)
6090
(54)
72105
(63)
84120
(72)
96QR20DEVQ23DE
VQ35DE
Engine compartment and under vehicle
Intake and exhaust valve clearanceSee
NOTE
(1)EM-50
EM-202
Drive beltsSee
NOTE
(2)I IIIIIIIMA-16MA-24
Engine oil (Use recommended oil.)RR RRRRRRMA-20MA-30
Engine oil filter (Use genuine NISSAN part
or equivalent)RR RRRRRRMA-21MA-31
Engine anti-freeze coolant (Use Genuine
NISSAN Anti-freeze Coolant or equivalent
in its quality.)See
NOTE
(3)IMA-16
MA-25
Cooling system I IIIIIIIMA-18MA-28
Positive crankcase ventilation (PCV) sys-
tem (VQ engine only)IIII—MA-33
Fuel and EVAP vapor lines I I I IMA-23MA-34
Air cleaner filterRRMA-20MA-30
Fuel filter (In-tank type)See
NOTE
(4)——
Spark plugs (Platinum-tipped type) [R] [R] [R] [R]MA-22
MA-32
Heated oxygen sensorSee
NOTE
(5)EC-150,
EC-143EC-496,
EC-486

Page 2987 of 3502

NISSAN TEANA 2003 Service Manual PERIODIC MAINTENANCE
MA-9
C
D
E
F
G
H
I
J
K
MA
B
MA

CHASSIS AND BODY MAINTENANCE
(Annual Mileage <30,000 Km [18,000 miles]/year)
Abbreviations: I = Inspect and correct or replace as necessary, R = R

Page 2988 of 3502

NISSAN TEANA 2003 Service Manual MA-10
PERIODIC MAINTENANCE

MAINTENANCE UNDER SEVERE DRIVING CONDITIONS
(Annual Mileage <30,000 Km [18,000 miles]/year)
The maintenance intervals shown on the preceding pages are for normal operating

Page 2989 of 3502

NISSAN TEANA 2003 Service Manual PERIODIC MAINTENANCE
MA-11
C
D
E
F
G
H
I
J
K
MA
B
MA

ENGINE AND EMISSION CONTROL MAINTENANCE
(Annual Mileage >30,000 Km [18,000 miles]/year)
QR and VQ ENGINE
Abbreviations: I = Inspect and correct o

Page 2990 of 3502

NISSAN TEANA 2003 Service Manual MA-12
PERIODIC MAINTENANCE

CHASSIS AND BODY MAINTENANCE
(Annual Mileage >30,000 Km [18,000 miles]/year)
Abbreviations: I = Inspect and correct or replace as necessary, R = Replace
NOTE:
(1) If towi

Page 2991 of 3502

NISSAN TEANA 2003 Service Manual PERIODIC MAINTENANCE
MA-13
C
D
E
F
G
H
I
J
K
MA
B
MA

MAINTENANCE UNDER SEVERE DRIVING CONDITIONS
(Annual Mileage >30,000 Km [18,000 miles]/year)
The maintenance intervals shown on the preceding page

Page 2992 of 3502

NISSAN TEANA 2003 Service Manual MA-14
RECOMMENDED FLUIDS AND LUBRICANTS

RECOMMENDED FLUIDS AND LUBRICANTSPFP:00000
Fluids and LubricantsBLS0009C
*1: For further details, see “SAE Viscosity Number”.
*2: Use Genuine NISSAN Anti-

MA-14
RECOMMENDED FLUIDS AND LUBRICANTS

RECOMMENDED FLUIDS AND LUBRICANTSPFP:00000
Fluids and LubricantsBLS0009C
*1: For further details, see “SAE Viscosity Number”.
*2: Use Genuine NISSAN Anti-freeze Coolant or equivalent in its quality, in order to avoid possible aluminum corrosion within the engine
cooling system caused by the use of non-genuine engine coolant.
Note that any repairs for the incidents within the engine cooling system while using non-genuine engine coolant may not be
covered by the warranty even if such incidents occurred during the warranty period.
*3: Contact a Nissan dealership for more information regarding suitable fluids, including recommended brand(s) of DEXRON
TM III/MER-
CONTM Automatic Transmission Fluid.
*4: Using transmission fluid other than Genuine NISSAN CVT Fluid NS-2 will damage the CVT, which is not covered by the war-
ranty.
*5: DEXRON
TM III type ATF can be used.
*6: Never mix different type of fluids (DOT 3 and DOT 4).Capacity (Approximate)
Recommended Fluids/Lubricants
Liter Imp measure
Engine oil
Drain and refillWith oil filter changeQR20DE 3.9 3- 3/8 qt
For QR20DE
Genuine NISSAN engine oil
API SG, SH, SJ or SL *1
ILSAC grade GF-1, GF-2 or GF-3 *1
ACEA A2*1
For VQ23DE & VQ35DE
Genuine NISSAN engine oil
API SJ, SL or SM *1
ILSAC grade GF-2, GF-3 or GF-4 *1
ACEA A2*1 VQ23DE 4.0 3-1/2 qt
VQ35DE 4.0 3-1/2 qt
Without oil filter changeQR20DE 3.7 3-1/4 qt
VQ23DE 3.7 3-1/4 qt
VQ35DE 3.7 3-1/4 qt
Dry engine (engine overhaul)QR20DE 4.5 4 qt
VQ23DE 5.0 4-3/8 qt
VQ35DE 5.0 4-3/8 qt
Cooling systemWith reservoir tankQR20DE 7.4 6-1/2 qt
Genuine NISSAN Anti-freeze Coolant or
equivalent in its quality *2 VQ23DE 8.2 7-1/4 qt
VQ35DE 8.8 7-3/4 qt
Reservoir tankQR20DE 0.8 3/4 qt
VQ23DE 0.8 3/4 qt
VQ35DE 0.8 3/4 qt
Automatic transaxle fluidQR20DE 8.4 7-3/8 qt
Genuine NISSAN ATF Matic Fluid D or
equivalent *3
VQ23DE 8.9 7-7/8 qt
CVT fluid VQ35DE 10.2 9 qt Genuine NISSAN CVT Fluid NS-2 *4
Power steering fluid 1.0 7/8 qt Genuine NISSAN PSF or equivalent *5
Brake fluid — — DOT 3 or DOT 4 (US FMVSS No. 116) *6
Multi-purpose grease — — NLGI No. 2 (Lithium soap base)
