Page 513 of 3502

NISSAN TEANA 2003 Service Manual REFRIGERANT LINES ATC-135 C D E F G H I K L MA B AT C VQ Engine 1. Use a refrigerant collecting equipment (for HFC-134a) to discharge the refrigerant. 2. Remove engine undercover, using power tools.

Page 514 of 3502

NISSAN TEANA 2003 Service Manual ATC-136 REFRIGERANT LINES 9. Remove mounting bolts and nut from compressor, using power tools. 10. Remove compressor from right side of the vehicle. INSTALLATION Installation is basically the revers

Page 515 of 3502

NISSAN TEANA 2003 Service Manual REFRIGERANT LINES ATC-137 C D E F G H I K L MA B AT C Removal and Installation of Low-pressure Flexible Hose and Low-pressure Pipe 1 BJS000HR REMOVAL 1. Use a refrigerant collecting equipment (for

Page 516 of 3502

NISSAN TEANA 2003 Service Manual ATC-138 REFRIGERANT LINES Removal and Installation of High-pressure Flexible HoseBJS000HS REMOVAL 1. Use a refrigerant collecting equipment (for HFC-134a) to discharge the refrigerant. 2. Remove mou

Page 517 of 3502

NISSAN TEANA 2003 Service Manual REFRIGERANT LINES ATC-139 C D E F G H I K L MA B AT C Removal and Installation of High-pressure Pipe 1 (Engine Compartment)BJS000HT REMOVAL 1. Use a refrigerant collecting equipment (for HFC-134a) t

Page 518 of 3502

NISSAN TEANA 2003 Service Manual ATC-140 REFRIGERANT LINES Removal and Installation of Low-pressure Pipe 2 and High-pressure Pipe 2BJS000HU REMOVAL 1. Set the temperature (passenger side) at 18°C, and then disconnect the battery c

Page 519 of 3502

NISSAN TEANA 2003 Service Manual REFRIGERANT LINES ATC-141 C D E F G H I K L MA B AT C 13. Remove mounting screws, and then remove evaporator cover. 14. Remove mounting bolt, and then remove low-pressure pipe 2 and high-pressure pi

Page 520 of 3502

NISSAN TEANA 2003 Service Manual ATC-142 REFRIGERANT LINES Removal and Installation of CondenserBJS000HV REMOVAL 1. Use a refrigerant collecting equipment (for HFC-134a) to discharge the refrigerant. 2. Remove air duct (inlet). Ref
