INTEGRATED COLOR DISPLAY SYSTEM
Component DescriptionBKS0027K
DISPLAY CONTROL UNIT
Display control unit draws a status of the audio system and air
conditioner system, a TRIP screen, a FUEL ECONOMY screen,
etc., and transmits the image signals to the display screen.
It receives operation signals of audio system and air conditioner
system from A/C and AV switch, and transmits the operation sig-
nal of audio system to the audio unit through the communication
line and transmits the operation signal of air conditioner system
to the unified meter and A/C amp. through CAN communication.
Display signal from audio unit is transmitted to display control
unit through the communication line, and then the operating
state of the audio system is displayed in the screen.
Display signal from unified meter and A/C amp. is transmitted to
display control unit through the CAN communication, and then the operating state of the air conditioner
system is displayed in the screen.
DISPLAY
Images on the display include RGB image and rear view image
displayed when setting the select lever to R range.
Display control unit controls images on the display.
A/C AND AV SWITCH
A/C and AV switch, an integrated combination of audio system
and air conditioner system switches, are adopted.
Operation signal of audio system is transmitted to the audio unit
through display control unit with the communication line.
Operation signal of air conditioner system is transmitted to uni-
fied meter and A/C amp. through display control unit with CAN
communication.
REAR VIEW CAMERA
Rear view camera transmits rear view image signals to the dis-
play screen through the rear view camera control unit, when
reverse signal is input.
The rear view image is a mirror image reversed left and right
that is the same as seeing rear side with a room mirror.
