EM-96
< UNIT DISASSEMBLY AND ASSEMBLY >[HR16DE]
CYLINDER BLOCK
a. Loosen and remove bolts in several steps in reverse of the
numerical order as shown.
NOTE:
When removing or installing signal plate, use socket (size T40).
b. Remove the main bearing cap from the cylinder block while tapping lightly with a plastic hammer.
10. Remove crankshaft (2). CAUTION:
• Do not damage or deform signal plate (1) mounted on
crankshaft.
• When setting crankshaft on a flat floor surface, use a
block of wood to avoid interf erence between signal plate
and the floor surface.
• Do not remove signal plate unless it is necessary to do
so.
NOTE:
When removing or installing signal plate, use socket (size T40).
11. Pull rear oil seal out from rear end of crankshaft.
12. Remove main bearing (upper/lower) and thrust bear ings from cylinder block and main bearing caps.
CAUTION:
Identify original installation positions, and store the bearings without mixing them up.
13. Remove oil jets. CAUTION:
Insert the dowel pin of oil jet into the cylinde r block dowel pin hole to loosen the bolt.
ASSEMBLY
CAUTION:
Do not reuse O-rings.
1. Fully air-blow engine coolant and engine oil passages in cylinder block, cylinder bore and crankcase to
remove any foreign material.
WARNING:
Use goggles to protect your eyes.
2. Install cylinder block plugs. • Apply liquid gasket to the thread of water drain plug (3).
Use Genuine Silicone RTV Seal ant, or equivalent. Refer to
GI-22, "
Recommended Chemical Products and Sealants".
CAUTION:
Do not reuse O-ring.
• Tighten each plug as specified below.
: Engine front
JPBIA4203ZZ
JPBIA4531ZZ
(2) : O-ring : Engine front
AWBIA1607ZZ
Part WasherTightening torque
(1) Yes54.0 N·m (5.5 kg-m, 40 ft-lb)
(3) No9.8 N·m (1.0 kg-m, 87 in-lb)
Revision: August 2015 2016 Versa Note
