RADIATOR CORE SUPPORT
RADIATOR CORE SUPPORT
Exploded ViewINFOID:0000000012430090
RADIATOR CORE SUPPORT UPPER
RADIATOR CORE SUPPORT UPPER
: Removal and InstallationINFOID:0000000012430091
REMOVAL
1. Remove front grille. Refer to EXT-32, "Removal and Installation".
2. Remove ground harness bolt (A).
1. Upper air guide 2. Air guide (RH)3. Front bumper reinforcement
4. Lower air guide 5. Air guide (LH)6. Radiator core lower support
7. Lower grommet 8. Upper grommet9. Radiator core upper support
Clip
ALKIA3172ZZ
ALKIA3174ZZ
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 834 of 3641
![NISSAN NOTE 2016 Service Repair Manual RADIATOR CORE SUPPORTDLK-145
< REMOVAL AND INSTALLATION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
3. Remove washer tube inlet clip (A).
4. Remove radiator cap adapter bracket b NISSAN NOTE 2016 Service Repair Manual RADIATOR CORE SUPPORTDLK-145
< REMOVAL AND INSTALLATION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
3. Remove washer tube inlet clip (A).
4. Remove radiator cap adapter bracket b](/manual-img/5/57363/w960_57363-833.png)
RADIATOR CORE SUPPORTDLK-145
< REMOVAL AND INSTALLATION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
3. Remove washer tube inlet clip (A).
4. Remove radiator cap adapter bracket bolt (A) and radiator reser- voir tank bolt (B).
5. Remove horn. Refer to HRN-6, "
Removal and Installation".
6. Remove crash zone sensor. Refer to SR-24, "
Removal and Installation".
7. Remove hood lock assembly. Refer to DLK-165, "
HOOD LOCK : Removal and Installation".
8. Release hood lock release cable clips from radi ator core support upper using a suitable tool.
9. Remove upper air guide. Refer to DLK-144, "
Exploded View".
10. Remove air guide (LH/RH). Refer to DLK-144, "
Exploded View".
11. Release all harness connector clips from radiator core support upper using a suitable tool.
12. Remove bolts (A) and radiator core support upper.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
After installation, perform hood assembl y adjustment procedure. Refer to DLK-141, "
HOOD ASSEM-
BLY : Adjustment".
RADIATOR CORE SUPPORT LOWER
RADIATOR CORE SUPPORT LOWE R : Removal and InstallationINFOID:0000000012430092
REMOVAL
1. Remove radiator core support upper. Refer to DLK-144, "RADIATOR CORE SUPPORT UPPER :
Removal and Installation".
2. Reposition the radiator and condenser.
AWKIA2567ZZ
JMKIA8027ZZ
AWKIA2568ZZ
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 835 of 3641
DLK-146
< REMOVAL AND INSTALLATION >[WITH INTELLIGENT KEY SYSTEM]
RADIATOR CORE SUPPORT
3. Using a suitable tool (A), suspend radiator and condenser to
prevent them from falling.
CAUTION:
Use care to avoid damaging radiator and condenser.
4. Remove bolts (A) and radiator core support lower (1).
INSTALLATION
Installation is in the reverse order of removal.
JMKIA8030ZZ
ALKIA3181ZZ
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 836 of 3641
FRONT FENDERDLK-147
< REMOVAL AND INSTALLATION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
FRONT FENDER
Exploded ViewINFOID:0000000012430093
Removal and InstallationINFOID:0000000012430094
CAUTION:
Use a shop cloths to protect the body from being damaged during removal and installation.
REMOVAL
1. Remove the front combination lamp. Refer to EXL-102, "Removal and Installation".
2. Remove cowl top side cover. Refer to DLK-147, "
Exploded View".
3. Remove front fender bolts.
1. Front fender 2. Cowl top side cover3. Front fender insulator
4. Front fender stiffener PawlClip
AWKIA2569ZZ
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 837 of 3641
DLK-148
< REMOVAL AND INSTALLATION >[WITH INTELLIGENT KEY SYSTEM]
FRONT FENDER
4. Remove front fender stiffener (2) by carefully pulling upper por-
tion of front fender (1) away from body.
: Front
CAUTION:
Use care when removing the fr ont fender. The front fender
stiffener foam adheres the front fender to the body. Care-
fully release the stiffener foam or damage to front fender
may occur.
5. Remove front fender.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
• After installation, apply touc h-up paint (body color) to the head of front fender bolts.
• After installation, adjust th e following components as necessary:
- Hood assembly: Refer to DLK-141, "
HOOD ASSEMBLY : Adjustment".
- Front door assembly: Refer to DLK-150, "
DOOR ASSEMBLY : Adjustment".
JMKIA5633ZZ
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 838 of 3641
![NISSAN NOTE 2016 Service Repair Manual FRONT DOORDLK-149
< REMOVAL AND INSTALLATION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
FRONT DOOR
Exploded ViewINFOID:0000000012430095
DOOR ASSEMBLY
DOOR ASSEMBLY : Removal and NISSAN NOTE 2016 Service Repair Manual FRONT DOORDLK-149
< REMOVAL AND INSTALLATION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
FRONT DOOR
Exploded ViewINFOID:0000000012430095
DOOR ASSEMBLY
DOOR ASSEMBLY : Removal and](/manual-img/5/57363/w960_57363-837.png)
FRONT DOORDLK-149
< REMOVAL AND INSTALLATION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
FRONT DOOR
Exploded ViewINFOID:0000000012430095
DOOR ASSEMBLY
DOOR ASSEMBLY : Removal and InstallationINFOID:0000000012430096
CAUTION:
• Use two people when removing or inst alling front door due to its heavy weight
• When removing and installing front door assembl y, support the door using a suitable tool.
• Do not use air tools or electric tools for servicing.
• Before servicing, turn ignition sw itch off, disconnect both battery terminals and wait at least three
minutes.
REMOVAL
1. Disconnect the battery positive and negative terminal s and wait at least three minutes. Refer to PG-70,
"Removal and Installation (Battery)".
2. Remove dash side finisher. Refer to INT-24, "
DASH SIDE FINISHER : Removal and Installation".
3. Disconnect the harness connectors from the front door.
4. Remove door check link bolt (body side).
5. Remove door hinge nuts (door side) and front door assembly.
INSTALLATION
1. Inside seal 2. Door sash front tape 3. Grommet (driver side only)
4. Door upper hinge 5. Door lower hinge6. Door check link
7. Front door panel 8. Lower grommet9. Upper grommet
10. Door striker 11. Body panel plug12. Door sash rear tape
AWKIA2492ZZ
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 839 of 3641
DLK-150
< REMOVAL AND INSTALLATION >[WITH INTELLIGENT KEY SYSTEM]
FRONT DOOR
Installation is in the reverse order of removal.
CAUTION:
• After installation, perform the front
door adjustment procedure. Refer to DLK-150, "
DOOR ASSEM-
BLY : Adjustment".
• Perform camera image calibration (if equipp ed with around view camera). Refer to AV-179, "
CALI-
BRATING CAMERA IMAGE (AROUND VIEW MONITOR) : Description".
• Apply anticorrosive agent to the door hinge mating surface.
• Check door hinge rota ting point for poor lubrication. If neces-
sary, apply a suitable multi-purpose grease.
DOOR ASSEMBLY : AdjustmentINFOID:0000000012430097
JMKIA8072ZZ
1. Front fender 2. Front door 3. Rear door
AWKIA2493ZZ
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 840 of 3641
![NISSAN NOTE 2016 Service Repair Manual FRONT DOORDLK-151
< REMOVAL AND INSTALLATION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
Check the clearance and surface height between front door and each part by visual inspect NISSAN NOTE 2016 Service Repair Manual FRONT DOORDLK-151
< REMOVAL AND INSTALLATION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
Check the clearance and surface height between front door and each part by visual inspect](/manual-img/5/57363/w960_57363-839.png)
FRONT DOORDLK-151
< REMOVAL AND INSTALLATION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
Check the clearance and surface height between front door and each part by visual inspection and tactile feel.
If the clearance and the surface height are out of specific ation, adjust them according to the adjustment proce-
dure.
Unit: mm (in)
1. Remove front fender. Refer to DLK-147, "Removal and Installation".
2. Loosen front door hinge nuts (door side).
3. Adjust the surface height of front door according to the specifications provided.
4. Temporarily tighten front door hinge nuts (door side).
5. Loosen front door hinge bolts (body side).
6. Raise or lower the front door at rear end to adjust clearance of the front door according to the specifica-
tions provided.
7. After adjustment tighten bolts and nuts to the specified torque. CAUTION:
Check door hinge rotating po int for poor lubrication. If necessary, apply a suitable multi-purpose
grease.
8. Install front fender. Refer to refer to DLK-147, "
Removal and Installation".
DOOR STRIKER
DOOR STRIKER : Removal and InstallationINFOID:0000000012430098
REMOVAL
Remove bolts and door striker.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
• Do not reuse door striker bolts.
• Tighten bolts to specification. Refer to DLK-149, "
Exploded View".
• After installation, check front door open/close operation. If necessary, perform the door striker
adjustment procedure. Refer to DLK-151, "
DOOR STRIKER : Adjustment".
DOOR STRIKER : AdjustmentINFOID:0000000012430099
DOOR STRIKER ADJUSTMENT
1. Loosen door striker bolts
4. Body side outer 5. Door striker 6. Striker bolt
7. Front door hinge 8. Rear door upper hinge9. Rear door lower hinge
Section Measurement Standard
A – A Clearance
4.6 ± 1.0 (0.18 ± 0.04)
Surface height 0.0 ± 1.0 (0.0 ± 0.04)
B – B Clearance
4.6 ± 2.0 (0.18 ± 0.08)
Surface height 0.0 ± 1.5 (0.0 ± 0.06)
C – C Clearance
4.6 ± 1.0 (0.18 ± 0.04)
Surface height 0.0 ± 1.0 (0.0 ± 0.04)
