NISSAN NOTE 2016 Service Repair Manual PG-54
< WIRING DIAGRAM >
HARNESS
FRONT DOOR RH HARNESS
AAMIA0192ZZ
D101 Y/4 : To M75D112 W/2 : Front door speaker RH
D104 B/2 : Front power window motor RH D113 GR/2 : Fr

Page 2642 of 3641

NISSAN NOTE 2016 Service Repair Manual PG
HARNESSPG-55
< WIRING DIAGRAM >
C
DE
F
G H
I
J
K L
B A
O P
N
REAR DOOR LH HARNESS
AAMIA0193ZZ
D201 W/10 : To B4
D205 GR/6 : Rear door lock actuator LH
D203 W/8 : Rear pow

Page 2643 of 3641

NISSAN NOTE 2016 Service Repair Manual PG-56
< WIRING DIAGRAM >
HARNESS
REAR DOOR RH HARNESS
AAMIA0194ZZ
D301 W/10 : To B11D305 GR/6 : Rear door lock actuator RH
D303 W/8 : Rear power window switch RHD307 W/2 :

Page 2644 of 3641

NISSAN NOTE 2016 Service Repair Manual PG
HARNESSPG-57
< WIRING DIAGRAM >
C
DE
F
G H
I
J
K L
B A
O P
N
BACK DOOR HARNESS
AAMIA0384ZZ
D3 D501 B/6 : Rear view camera
C3 D506 BR/2 : Back door request switch
D3 D502 W/

Page 2645 of 3641

NISSAN NOTE 2016 Service Repair Manual PG-58
< WIRING DIAGRAM >
FUSE BLOCK - JUNCTION BOX (J/B)
FUSE BLOCK - JUNCTION BOX (J/B)
Terminal ArrangementINFOID:0000000012433124
AAMIA2767GB
Revision: August 20152016 Versa Note

cardiagn.com

Page 2646 of 3641

NISSAN NOTE 2016 Service Repair Manual PG
FUSE AND FUSIBLE LINK BOXPG-59
< WIRING DIAGRAM >
C
DE
F
G H
I
J
K L
B A
O P
N
FUSE AND FUSIBLE LINK BOX
Terminal ArrangementINFOID:0000000012433125
FUSE AND FUSIBLE LINK BOX
ABMIA7435GB
Revision:

Page 2647 of 3641

NISSAN NOTE 2016 Service Repair Manual PG-60
< WIRING DIAGRAM >
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE
ROOM)
IPDM E/R Terminal Arrangement INFOID:000000001243312

Page 2648 of 3641

NISSAN NOTE 2016 Service Repair Manual PG
BATTERYPG-61
< BASIC INSPECTION >
C
DE
F
G H
I
J
K L
B A
O P
N
BASIC INSPECTION
BATTERY
How to Handle BatteryINFOID:0000000012433127
CAUTION:
• If it becomes necessary to start the engine with
a

PG
BATTERYPG-61
< BASIC INSPECTION >
C
DE
F
G H
I
J
K L
B A
O P
N
BASIC INSPECTION
BATTERY
How to Handle BatteryINFOID:0000000012433127
CAUTION:
• If it becomes necessary to start the engine with
a booster battery and jumper cables, use a 12-volt
booster battery.
• After connecting battery cables, ensure that they are tightly clamped to battery terminals for good
contact.
• Never add distilled water through the hole used to check specific gravity.
METHODS OF PREVENTING OVER-DISCHARGE
The following precautions must be taken to prevent over-discharging a battery.
• The battery surface (particularly its top) should always be kept
clean and dry.
• The terminal connections should be clean and tight.
• At every routine maintenance, check the electrolyte level. This also applies to batteries designated as “low maintenance” and
“maintenance-free”.
• When the vehicle is not going to be used over a long period of time, disconnect the battery cable from the negative terminal. (If
the vehicle has an extended storage switch, turn it off.)
Work FlowINFOID:0000000012433128
BATTERY DIAGNOSIS WITH EXP-800 NI OR GR8-1200 NI
To diagnose and confirm the condition of the batte ry, use the following special service tools:
• EXP-800 NI Battery and electrical diagnostic analyzer
• GR8-1200 NI Multitasking battery and electrical diagnostic station
NOTE:
Refer to the applicable Instruction Manual for proper battery diagnosis procedures.
BATTERY DIAGNOSIS WITHOUT EXP-800 NI OR GR8-1200 NI
Checking Electrolyte Level
WARNING:
Never allow battery fluid to come in contact with skin, eyes, fabrics, or painted surfaces. After touch-
ing a battery, never touch or rub your eyes until you have thoroughly washed your hands. If acid con-
tacts eyes, skin or clothing, imme diately flush with water for 15 minutes and seek medical attention.
Failure to do this may cause personal injury or damage to clothing or the painted surfaces.
MEL040F
ELA0349D
Revision: August 2015 2016 Versa Note
