NISSAN NOTE 2016 Service Repair Manual WCS-38
< DTC/CIRCUIT DIAGNOSIS >
METER BUZZER CIRCUIT
METER BUZZER CIRCUIT
Component Function CheckINFOID:0000000012432690
1.CHECK OPERATION OF METER BUZZER
1. Select “BUZZER” of “BCM” using C

Page 3554 of 3641

NISSAN NOTE 2016 Service Repair Manual WCS
SEAT BELT BUCKLE SWITCH SIGNAL CIRCUIT
WCS-39
< DTC/CIRCUIT DIAGNOSIS >
C
D E
F
G H
I
J
K L
M B A
O P
SEAT BELT BUCKLE SW ITCH SIGNAL CIRCUIT
TYPE A
TYPE A : DescriptionINFOID:0000000012432692
Tra

Page 3555 of 3641

NISSAN NOTE 2016 Service Repair Manual WCS-40
< DTC/CIRCUIT DIAGNOSIS >
SEAT BELT BUCKLE SWITCH SIGNAL CIRCUIT
YES >> GO TO 3.
NO >> Repair or replace harness or connector.
3.CHECK SEAT BELT BUCKLE SWITCH LH GROUND CIRCUIT
Check continuity

Page 3556 of 3641

NISSAN NOTE 2016 Service Repair Manual WCS
SEAT BELT BUCKLE SWITCH SIGNAL CIRCUIT
WCS-41
< DTC/CIRCUIT DIAGNOSIS >
C
D E
F
G H
I
J
K L
M B A
O P
Is the inspection result normal?
YES >> Replace combination meter. Refer to MWI-115, "Removal

WCS
SEAT BELT BUCKLE SWITCH SIGNAL CIRCUIT
WCS-41
< DTC/CIRCUIT DIAGNOSIS >
C
D E
F
G H
I
J
K L
M B A
O P
Is the inspection result normal?
YES >> Replace combination meter. Refer to MWI-115, "Removal and Installation" (Type B).
NO >> GO TO 2.
2.CHECK SEAT BELT BUCKLE SWITCH LH CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect combination meter harness connector M24 and seat belt buckle switch LH harness connector
B13.
3. Check continuity between combination meter har ness connector M24 terminal 9 and seat belt buckle
switch LH harness connector B13 terminal 1.
4. Check continuity between combination meter harness connector M24 terminal 9 and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness or connector.
3.CHECK SEAT BELT BUCKLE SWITCH LH GROUND CIRCUIT
Check continuity between seat belt buckle swit ch LH harness connector B13 terminal 2 and ground.
Is the inspection result normal?
YES >> Check the seat belt buckle switch LH. Refer to SR-35, "Removal and Installation".
NO >> Repair or replace harness or connector.
TYPE B : Component InspectionINFOID:0000000012432699
1. CHECK SEAT BELT BUCKLE SWITCH LH
1. Turn ignition switch OFF.
2. Disconnect the seat belt buckle switch LH.
3. Check continuity between the seat belt buckle switch LH terminals 1 and 2.
Is the inspection result normal?
YES >> Inspection End.
NO >> Replace the seat belt buckle switch LH. Refer to SR-35, "
Removal and Installation".
Combination meter
GroundCondition Vo l ta g e
(Approx.)
Connector Terminal
M24 9— When seat belt LH is fastened
Battery voltage
When seat belt LH is unfastened 0 V
Combination meterSeat belt buckle switch LH
Continuity
Connector TerminalConnector Terminal
M24 9B13 1Yes
Combination meter GroundContinuity
Connector Terminal
M24 9— No
Seat belt buckle switch LH
GroundContinuity
Connector Terminal
B13 2—Yes
Terminal ConditionContinuity
12 When seat belt is fastened
No
When seat belt is unfastened Yes
Revision: August 2015 2016 Versa Note

cardiagn.com

Page 3557 of 3641

NISSAN NOTE 2016 Service Repair Manual WCS-42
< DTC/CIRCUIT DIAGNOSIS >
PARKING BRAKE SWITCH SIGNAL CIRCUIT
PARKING BRAKE SWITCH SIGNAL CIRCUIT
TYPE A
TYPE A : Component Function CheckINFOID:0000000012432700
1.CHECK PARKING BRAKE SWITCH OP

WCS-42
< DTC/CIRCUIT DIAGNOSIS >
PARKING BRAKE SWITCH SIGNAL CIRCUIT
PARKING BRAKE SWITCH SIGNAL CIRCUIT
TYPE A
TYPE A : Component Function CheckINFOID:0000000012432700
1.CHECK PARKING BRAKE SWITCH OPERATION
Check that brake warning lamp in combination me ter turns ON/OFF when parking brake is actuated.
Is the inspection result normal?
YES >> Inspection End.
NO >> Proceed to diagnosis procedure. Refer to WCS-42, "
TYPE A : Diagnosis Procedure".
TYPE A : Diagnosis ProcedureINFOID:0000000012432701
Regarding Wiring Diagram information, refer to WCS-26, "Wiring Diagram".
1.CONNECTOR INSPECTION
1. Turn ignition switch OFF.
2. Disconnect combination meter and parking brake switch connectors.
3. Check connectors and terminals for deformation, disconnection, looseness or damage.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace as necessary.
2.CHECK PARKING BRAKE SWITCH
Check parking brake switch. Refer to WCS-42, "
TYPE A : Component Function Check".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace parking brake switch. Refer to PB-6, "
Exploded View".
3.CHECK PARKING BRAKE SWITCH SIGNAL
With CONSULT.
1. Connect combination meter connector and parking brake switch connectors.
2. Turn ignition switch ON.
3. Select “METER/M&A”.
4. Monitor “PKB SW” in “Data Monitor” while applying and releasing the parking brake.
Is the inspection result normal?
YES >> Refer to WCS-32, "Work Flow".
NO >> GO TO 4.
4.CHECK PARKING BRAKE SWITCH CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect combination meter and parking brake switch connectors.
3. Check continuity between combination meter connec tor M82 terminal 10 and parking brake switch con-
nector M17 terminal 1.
4. Check continuity between combination meter connector and ground.
Monitor item Condition Status
PKB SW When parking brake is applied
On
When parking brake is released Off
Combination meterParking brake switch
Continuity
Connector TerminalConnector Terminal
M82 10 M171Yes
Revision: August 2015 2016 Versa Note

cardiagn.com

Page 3558 of 3641

NISSAN NOTE 2016 Service Repair Manual WCS
PARKING BRAKE SWITCH SIGNAL CIRCUITWCS-43
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G H
I
J
K L
M B A
O P
Is the inspection result normal?
YES >> Replace combination meter. Refer to MWI-54, "Removal and I

Page 3559 of 3641

NISSAN NOTE 2016 Service Repair Manual WCS-44
< DTC/CIRCUIT DIAGNOSIS >
PARKING BRAKE SWITCH SIGNAL CIRCUIT
2. Turn ignition switch ON.
3. Select “METER/M&A”.
4. Monitor “PKB SW” in “Data Monitor” while applying and releasing t

Page 3560 of 3641

NISSAN NOTE 2016 Service Repair Manual WCS
KEY SWITCH SIGNAL CIRCUIT (WITHOUT INTELLIGENT KEY)
WCS-45
< DTC/CIRCUIT DIAGNOSIS >
C
D E
F
G H
I
J
K L
M B A
O P
KEY SWITCH SIGNAL CIRCUIT (WITHOUT INTELLIGENT KEY)
DescriptionINFOID:0000000012
