NISSAN NOTE 2016 Service Repair Manual EC-162
< DTC/CIRCUIT DIAGNOSIS >[HR16DE]
U0101 CAN COMM CIRCUIT
U0101 CAN COMM CIRCUIT
DescriptionINFOID:0000000012431374
CAN (Controller Area Network) is a serial communication line for real time app

Page 1290 of 3641

NISSAN NOTE 2016 Service Repair Manual U0284 ACTIVE GRILLE SHUTTEREC-163
< DTC/CIRCUIT DIAGNOSIS > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
U0284 ACTIVE GRILLE SHUTTER
DTC LogicINFOID:0000000012431377
DTC DETECTION LOGIC
NOTE:
If DTC U0284

U0284 ACTIVE GRILLE SHUTTEREC-163
< DTC/CIRCUIT DIAGNOSIS > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
U0284 ACTIVE GRILLE SHUTTER
DTC LogicINFOID:0000000012431377
DTC DETECTION LOGIC
NOTE:
If DTC U0284 is displayed with another DTC UXXXX, per
form trouble diagnosis for DTC UXXXX first. Refer to
EC-87, "
DTCIndex".
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If another DTC Confirmation Procedure is conducted just before this procedure, always turn ignition switch
OFF and wait at least 10 seconds before conducting the next test.
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is 10 V or more with ignition switch
ON.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON and wait at least 5 seconds.
2. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Proceed to EC-163, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000012431378
1.INSPECTION START
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Disconnect active grille shutter harness connector.
4. Check the continuity between ECM harness connector and active grille shutter harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace the error-detected parts.
2.CHECK INTERMITTENT INCIDENT
Check intermittent incident. Refer to GI-42, "
Intermittent Incident".
Is the inspection result normal?
YES >> Replace active grille shutter. Refer to EXT-33, "Removal and Installation".
NO >> Repair or replace the error-detected parts.
DTC CONSULT screen terms
(Trouble diagnosis content) DTC detecting condition
Possible cause
U0284 LOST COMM (A/GRLL SHTTR
MDL A)
(Lost communication with ac-
tive grille air shutter module A) When ECM cannot receive the engine
communication signal from active grille
shutter. • Harness and connectors
(Engine communication line is open or cir-
cuit shorted.)
• Active grille shutter
+–
Continuity
ECM Active grille shutter
Connector Terminal Connector Terminal F11 70 E303 2 Existed
Revision: August 2015 2016 Versa Note

cardiagn.com

Page 1291 of 3641

NISSAN NOTE 2016 Service Repair Manual EC-164
< DTC/CIRCUIT DIAGNOSIS >[HR16DE]
U1001 CAN COMM CIRCUIT
U1001 CAN COMM CIRCUIT
DescriptionINFOID:0000000012431379
CAN (Controller Area Network) is a serial communication line for real time app

Page 1292 of 3641

NISSAN NOTE 2016 Service Repair Manual U1040 ENG COMM CIRCUITEC-165
< DTC/CIRCUIT DIAGNOSIS > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
U1040 ENG COMM CIRCUIT
DTC LogicINFOID:0000000012431382
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1

Page 1293 of 3641

NISSAN NOTE 2016 Service Repair Manual EC-166
< DTC/CIRCUIT DIAGNOSIS >[HR16DE]
U1044 ENG COMM CIRCUIT
U1044 ENG COMM CIRCUIT
DTC LogicINFOID:0000000012723405
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If another DTC

Page 1294 of 3641

NISSAN NOTE 2016 Service Repair Manual P0011 IVT CONTROLEC-167
< DTC/CIRCUIT DIAGNOSIS > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
P0011 IVT CONTROL
DTC LogicINFOID:0000000012431384
DTC DETECTION LOGIC
NOTE:
If DTC P0011 is displayed with D

P0011 IVT CONTROLEC-167
< DTC/CIRCUIT DIAGNOSIS > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
P0011 IVT CONTROL
DTC LogicINFOID:0000000012431384
DTC DETECTION LOGIC
NOTE:
If DTC P0011 is displayed with DTC P0075, first perform the trouble diagnosis for DTC P0075. Refer to
EC-180, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conducted, always perform the following procedure
before conducting the next test.
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is between 10 V and 16 V at
idle.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE-I
With CONSULT
1. Turn ignition switch ON and select “DATA MONITOR” mode with CONSULT.
2. Start engine and warm it up to the normal operating temperature.
3. Maintain the following conditions for at least 6 c onsecutive seconds. Hold the accelerator pedal as steady
as possible.
4. Let engine idle for 10 seconds.
5. Check 1st trip DTC. With GST
Follow the procedure “With CONSULT” above.
Is 1st trip DTC detected?
YES >> Go to EC-168, "Diagnosis Procedure"
NO >> GO TO 3.
3.PERFORM DTC CONFIRMATION PROCEDURE-II
With CONSULT
1. Maintain the following conditions for at least 20 consecutive seconds.
DTC No. Trouble diagnosis content Detecting condition Possible cause
P0011 Intake valve timing control
performance There is a gap between angle of
target and phase-control angle
degree. • Crankshaft position sensor
• Camshaft position sensor
• Intake valve timing control solenoid valve
• Accumulation of debris to the signal pick-up portion of
the camshaft
• Timing chain installation
• Foreign matter caught in the oil groove for intake valve timing control
ENG SPEED 500 - 2,000 rpm
COOLAN TEMP/S More than 60 °C (140 °F)
Shift lever P or N position (CVT)
Neutral position (M/T)
Revision: August 2015
2016 Versa Note

cardiagn.com

Page 1295 of 3641

NISSAN NOTE 2016 Service Repair Manual EC-168
< DTC/CIRCUIT DIAGNOSIS >[HR16DE]
P0011 IVT CONTROL
CAUTION:
Always drive at a safe speed.
2. Check 1st trip DTC.
With GST
Follow the procedure “With CONSULT” above.
Is 1st trip DTC detecte

Page 1296 of 3641

NISSAN NOTE 2016 Service Repair Manual P0011 IVT CONTROLEC-169
< DTC/CIRCUIT DIAGNOSIS > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
• Accumulation of debris to the signal plate of camshaft rear end
• Chipping signal plate of camshaft rea

P0011 IVT CONTROLEC-169
< DTC/CIRCUIT DIAGNOSIS > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
• Accumulation of debris to the signal plate of camshaft rear end
• Chipping signal plate of camshaft rear end
Is the inspection result normal?
YES >> GO TO 6.
NO >> Remove debris and clean the signal plate of camshaft
rear end or replace camshaft. Refer to EM-60, "
Removal
and Installation".
6.CHECK TIMING CHAIN INSTALLATION
Check service records for any recent repairs that may cause timing chain misaligned.
Are there any service records that may cause timing chain misaligned?
YES >> Check timing chain installation. Refer to EM-51, "Removal and Installation".
NO >> GO TO 7.
7.CHECK LUBRICATION CIRCUIT
Perform “Inspection of Camshaft Sprocket (INT) Oil Groove”. Refer to EM-68, "
Inspection".
Is the inspection result normal?
YES >> GO TO 8.
NO >> Clean lubrication line.
8.CHECK INTERMITTENT INCIDENT
Refer to GI-42, "
Intermittent Incident".
>> INSPECTION END
Component InspectionINFOID:0000000012431386
1.CHECK INTAKE VALVE TIMING CONTROL SOLENOID VALVE-I
1. Turn ignition switch OFF.
2. Disconnect intake valve timing control solenoid valve harness connector.
3. Check resistance between intake valve timing control solenoid valve terminals as follows.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace intake valve timing control solenoid valve. Refer to EM-60, "
Exploded View".
2.CHECK INTAKE VALVE TIMING CONTROL SOLENOID VALVE-II
1. Remove intake valve timing control solenoid valve. Refer to EM-60, "
Exploded View".
2. Apply 12 V between intake valve timing control solenoid valve terminals 1 and 2, and then interrupt it. Make sure that the
plunger moves as shown in the figure.
CAUTION:
Do not apply 12 V continuous ly for 5 seconds or more.
Doing so may result in damage to the coil in intake valve
timing control solenoid valve.
NOTE:
Always replace O-ring when intake valve timing control
solenoid valve is removed.
Is the inspection result normal?
JSBIA0599ZZ
Terminals Resistance [at 20 °C (68 °F)]
1 and 2 7.0 - 7.7 Ω
1 or 2 and ground ∞
Ω
(Continuity should not exist)
JMBIA2108ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com
