Page 3089 of 3641

NISSAN NOTE 2016 Service Repair Manual SRC-72
< DTC/CIRCUIT DIAGNOSIS >
B0091 FRONT SIDE AIR BAG SATELLITE SENSOR LH
Diagnosis Procedure
INFOID:0000000012430651
1.HARNESS CONNECTOR
Visually inspect all applicable harness connectors for the

Page 3090 of 3641

NISSAN NOTE 2016 Service Repair Manual B0091 FRONT SIDE AIR BAG SATELLITE SENSOR LHSRC-73
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G
I
J
K L
M A
B
SRC
N
O P
NO >> Clear DTC. Inspection End.
7.RELATED HARNESS
Replace the related harness.
>>END
Revi

Page 3091 of 3641

NISSAN NOTE 2016 Service Repair Manual SRC-74
< DTC/CIRCUIT DIAGNOSIS >
B0096 FRONT SIDE AIR BAG SATELLITE SENSOR RH
B0096 FRONT SIDE AIR BAG SATELLITE SENSOR RH
DescriptionINFOID:0000000012430652
DTC B0096 FRONT SATELLITE SENSOR RH
The fr

SRC-74
< DTC/CIRCUIT DIAGNOSIS >
B0096 FRONT SIDE AIR BAG SATELLITE SENSOR RH
B0096 FRONT SIDE AIR BAG SATELLITE SENSOR RH
DescriptionINFOID:0000000012430652
DTC B0096 FRONT SATELLITE SENSOR RH
The front side air bag satellite sensor RH is wired to the air bag diagnosis sensor unit. The air bag diagnosis
sensor unit will monitor the front side air bag satellite sens or RH for internal failures and its circuits for commu-
nication errors.
PA R T L O C AT I O N
Refer to SRC-5, "Component Parts Location".
DTC LogicINFOID:0000000012430653
DTC DETECTION LOGIC
With CONSULT
DTC CONFIRMATION PROCEDURE (With CONSULT)
1.CHECK SELF-DIAG RESULT
1. Turn ignition switch ON.
2. Check for DTC using CONSULT.
Is the DTC detected?
YES (Current DTC)>>Refer to SRC-75, "Diagnosis Procedure".
YES (Past DTC)>>GO TO 2.
NO >> Inspection End.
2.ERASE SELF-DIAG RESULT
Erase the DTC using CONSULT.
Can the DTC be erased?
YES >> Inspection End.
NO >> Refer to SRC-75, "
Diagnosis Procedure".
DTC CONFIRMATION PROCEDURE (Without CONSULT)
1.CHECK SELF-DIAG RESULT
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-14, "
On Board Diagnosis Function".
NOTE:
SRS will not enter diagnosis mode if no malfunction is detected in user mode.
Is the DTC detected?
YES >> Refer to SRC-75, "Diagnosis Procedure".
NO >> Inspection End.
CONSULT name DTC DTC detecting condition Repair order
B-PILLAR SATELLITE SENSOR RH [SENSOR FAIL]
B0096Front side air bag satellite sensor RH
has malfunctioned.
Refer to SRC-75, "
Diagnosis Procedure".
B-PILLAR SATELLITE SENSOR RH [COMM FAIL] Front side air bag satellite sensor RH
communication error.
B-PILLAR SATELLITE SENSOR RH [DISCONNECT] Front side air bag satellite sensor RH is
disconnected.
B-PILLAR SATELLITE SENSOR RH [UNMATCH] Front side air bag satellite sensor RH is
out of specification.
B-PILLAR SATELLITE SENSOR RH [GND-SHORT] Front side air bag satellite sensor RH
circuit is shorted to ground.
Revision: August 2015
2016 Versa Note

cardiagn.com

Page 3092 of 3641

NISSAN NOTE 2016 Service Repair Manual B0096 FRONT SIDE AIR BAG SATELLITE SENSOR RH
SRC-75
< DTC/CIRCUIT DIAGNOSIS >
C
D E
F
G
I
J
K L
M A
B
SRC
N
O P
Diagnosis ProcedureINFOID:0000000012430654
1.HARNESS CONNECTOR
Visually inspect all appl

Page 3093 of 3641

NISSAN NOTE 2016 Service Repair Manual SRC-76
< DTC/CIRCUIT DIAGNOSIS >
B0096 FRONT SIDE AIR BAG SATELLITE SENSOR RH
YES >> GO TO 7.
NO >> Clear DTC. Inspection End.
7.RELATED HARNESS
Replace the related harness.
>>END
Revision: August 201

Page 3094 of 3641

NISSAN NOTE 2016 Service Repair Manual B0092 REAR SIDE AIR BAG SATELLITE SENSOR LH
SRC-77
< DTC/CIRCUIT DIAGNOSIS >
C
D E
F
G
I
J
K L
M A
B
SRC
N
O P
B0092 REAR SIDE AIR BAG SATELLITE SENSOR LH
DescriptionINFOID:0000000012430655
DTC B0092

B0092 REAR SIDE AIR BAG SATELLITE SENSOR LH
SRC-77
< DTC/CIRCUIT DIAGNOSIS >
C
D E
F
G
I
J
K L
M A
B
SRC
N
O P
B0092 REAR SIDE AIR BAG SATELLITE SENSOR LH
DescriptionINFOID:0000000012430655
DTC B0092 REAR SATELLITE SENSOR LH
The rear side air bag satellite sensor LH is wired to the air bag diagnosis sensor unit. The air bag diagnosis
sensor unit will monitor the rear side air bag satellite sens or LH for internal failures and its circuits for commu-
nication errors.
PA R T L O C AT I O N
Refer to SRC-5, "Component Parts Location".
DTC LogicINFOID:0000000012430656
DTC DETECTION LOGIC
With CONSULT
DTC CONFIRMATION PROCEDURE (With CONSULT)
1.CHECK SELF-DIAG RESULT
1. Turn ignition switch ON.
2. Check for DTC using CONSULT.
Is the DTC detected?
YES (Current DTC)>>Refer to SRC-78, "Diagnosis Procedure".
YES (Past DTC)>>GO TO 2.
NO >> Inspection End.
2.ERASE SELF-DIAG RESULT
Erase the DTC using CONSULT.
Can the DTC be erased?
YES >> Inspection End.
NO >> Refer to SRC-78, "
Diagnosis Procedure".
DTC CONFIRMATION PROCEDURE (Without CONSULT)
1.CHECK SELF-DIAG RESULT
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-14, "
On Board Diagnosis Function".
NOTE:
SRS will not enter diagnosis mode if no malfunction is detected in user mode.
Is the DTC detected?
YES >> Refer to SRC-78, "Diagnosis Procedure".
NO >> Inspection End.
CONSULT name DTCDTC detecting condition Repair order
C-PILLAR SATELLITE SENSOR LH [SENSOR FAIL]
B0092Rear side air bag satellite sensor LH has
malfunctioned.
Refer to SRC-78, "
Diagnosis Procedure".
C-PILLAR SATELLITE SENSOR LH [COMM FAIL] Rear side air bag satellite sensor LH
communication error.
C-PILLAR SATELLITE SENSOR LH [DISCONNECT] Rear side air bag satellite sensor LH is
disconnected.
C-PILLAR SATELLITE SENSOR LH [UNMATCH] Rear side air bag satellite sensor LH is
out of specification.
C-PILLAR SATELLITE SENSOR LH [GND-SHORT] Rear side air bag satellite sensor LH cir-
cuit is shorted to ground.
Revision: August 2015
2016 Versa Note

cardiagn.com

Page 3095 of 3641

NISSAN NOTE 2016 Service Repair Manual SRC-78
< DTC/CIRCUIT DIAGNOSIS >
B0092 REAR SIDE AIR BAG SATELLITE SENSOR LH
Diagnosis Procedure
INFOID:0000000012430657
1.HARNESS CONNECTOR
Visually inspect all applicable harness connectors for the

Page 3096 of 3641

NISSAN NOTE 2016 Service Repair Manual B0092 REAR SIDE AIR BAG SATELLITE SENSOR LH
SRC-79
< DTC/CIRCUIT DIAGNOSIS >
C
D E
F
G
I
J
K L
M A
B
SRC
N
O P
NO >> Clear DTC. Inspection End.
7.RELATED HARNESS
Replace the related harness.
>>END
Rev
