PWC-36
< DTC/CIRCUIT DIAGNOSIS >
POWER WINDOW MOTOR
Is the inspection result normal?
YES >> Replace power window and door lock/unlock switch RH. Refer to PWC-56, "Removal and Installa-
tion".
NO >> Repair or replace harness.
REAR LH
REAR LH : Componen t Function CheckINFOID:0000000012431823
1.CHECK FUNCTION
Check rear power window motor LH operation with main power window and door lock/unlock switch or rear
power window switch LH.
Is the inspection result normal?
YES >> Inspection End.
NO >> Refer to PWC-36, "
REAR LH : Diagnosis Procedure".
REAR LH : Diagnosis ProcedureINFOID:0000000012431824
Regarding Wiring Diagram information, refer to PWC-16, "Wiring Diagram".
1.CHECK REAR POWER WINDOW MOTOR LH INPUT SIGNAL
1. Turn ignition switch OFF.
2. Disconnect rear power window motor LH connector.
3. Turn ignition switch ON.
4. Check voltage between rear power window motor LH harness connector and ground.
Is the inspection result normal?
YES >> Replace rear power window motor LH.
NO >> GO TO 2.
2.CHECK REAR POWER WINDOW MOTOR LH CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect rear power window switch LH connector.
3. Check continuity between rear power window switch LH harness connector and rear power window motor LH harness connector.
4. Check continuity between rear power window switch LH connector and ground.
(+) (-)Condition Voltage (V)
(Approx.)
Rear power window motor LH
Connector Terminal
D204 1
GroundRear power window
switch LH NEUTRAL
0
UP Battery voltage
2 NEUTRAL
0
DOWN Battery voltage
Rear power window switch LH Rear power window motor LH
Continuity
Connector TerminalConnector Terminal
D203 6
D204 2
Ye s
51
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2698 of 3641

POWER WINDOW MOTORPWC-37
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G H
I
J
L
M A
B
PWC
N
O P
Is the inspection result normal?
YES >> Replace rear power window switch LH. Refer to PWC-57, "Removal and Installation".
NO >> Repair or replace harness.
REAR RH
REAR RH : Component Function CheckINFOID:0000000012431825
1. CHECK FUNCTION
Check rear power window motor RH operation with main power window and door lock/unlock switch or rear
power window switch RH.
Is the inspection result normal?
YES >> Inspection End.
NO >> Refer to PWC-37, "
REAR RH : Diagnosis Procedure".
REAR RH : Diagnosis ProcedureINFOID:0000000012431826
Regarding Wiring Diagram information, refer to PWC-16, "Wiring Diagram".
1.CHECK REAR POWER WINDOW MOTOR RH INPUT SIGNAL
1. Turn ignition switch OFF.
2. Disconnect rear power window motor RH connector.
3. Turn ignition switch ON.
4. Check voltage between rear power window motor RH harness connector and ground.
Is the inspection result normal?
YES >> Replace rear power window motor RH.
NO >> GO TO 2.
2.CHECK REAR POWER WINDOW MOTOR RH CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect rear power window switch RH connector.
3. Check continuity between rear power window swit ch RH harness connector and rear power window motor
RH harness connector.
4. Check continuity between rear power window switch RH harness connector and ground.
Rear power window switch LH GroundContinuity
Connector Terminal
D203 6
No
5
(+)
(-)Condition Voltage (V)
(Approx.)
Rear power window motor RH
Connector Terminal
D304 1
GroundRear power window
switch RH NEUTRAL
0
UP Battery voltage
2 NEUTRAL
0
DOWN Battery voltage
Rear power window switch RH Rear power window motor RH
Continuity
Connector TerminalConnector Terminal
D303 6
D304 2
Ye s
51
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2699 of 3641
PWC-38
< DTC/CIRCUIT DIAGNOSIS >
POWER WINDOW MOTOR
Is the inspection result normal?
YES >> Replace rear power window switch RH. Refer to PWC-57, "Removal and Installation".
NO >> Repair or replace harness.
Rear power window switch RH
GroundContinuity
Connector Terminal
D303 6
No
5
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2700 of 3641

DOOR SWITCHPWC-39
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G H
I
J
L
M A
B
PWC
N
O P
DOOR SWITCH
WITH INTELLIGENT KEY SYSTEM
WITH INTELLIGENT KEY SYST EM : Component Function CheckINFOID:0000000012431827
1.CHECK FUNCTION
1. Select “DOOR LOCK” of “BCM” using CONSULT.
2. Select “DOOR SW-DR” and “DOOR SW-AS” in “Data Monitor”.
3. Check that the function operates normall y according to the following conditions:
Is the inspection result normal?
YES >> Door switch is OK.
NO >> Refer to PWC-39, "
WITH INTELLIGENT KEY SYSTEM : Diagnosis Procedure".
WITH INTELLIGENT KEY SYST EM : Diagnosis ProcedureINFOID:0000000012431828
Regarding Wiring Diagram information, refer to PWC-16, "Wiring Diagram".
1.CHECK DOOR SWITCH INPUT SIGNAL
1. Turn ignition switch OFF.
2. Disconnect malfunctioning door switch connector.
3. Check signal between malfunctioning door switch harness connector and ground using oscilloscope.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.CHECK DOOR SWITCH CIRCUIT
1. Disconnect BCM connector.
2. Check continuity between door switch harness connector and BCM harness connector.
Monitor item Condition Status
DOOR SW-DR Front door LH Open
ON
Closed OFF
DOOR SW-AS Front door RHOpen
ON
Closed OFF
(+)
(–)Signal
(Reference value)
Door switch
Connector Terminal
Front door switch
LH B8
3
Ground
7.0 - 8.0 V
Front door switch
RH
B16
3
PKIB4960J
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2701 of 3641

PWC-40
< DTC/CIRCUIT DIAGNOSIS >
DOOR SWITCH
3. Check continuity between door switch harness connector and ground.
Is the inspection result normal?
YES >> Replace BCM. Refer to BCS-74, "Removal and Installation".
NO >> Repair or replace harness.
3.CHECK DOOR SWITCH
Refer to PWC-40, "
WITH INTELLIGENT KEY SYSTEM : Component Inspection".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Replace malfunctioning door switch. Refer to DLK-181, "
Removal and Installation".
4.CHECK INTERMITTENT INCIDENT
Refer to GI-42, "
Intermittent Incident".
>> Inspection End.
WITH INTELLIGENT KEY SYST EM : Component InspectionINFOID:0000000012431829
1.CHECK DOOR SWITCH
1. Turn ignition switch OFF.
2. Disconnect malfunctioning door switch connector.
3. Check continuity between door switch terminals.
Is the inspection result normal?
YES >> Inspection End.
NO >> Replace malfunction door switch. Refer to DLK-181, "
Removal and Installation".
WITHOUT INTELLIGENT KEY SYSTEM
WITHOUT INTELLIGENT KEY SYSTEM : DescriptionINFOID:0000000012431830
Detects door open/close condition.
WITHOUT INTELLIGENT KEY SYSTEM : Component Function CheckINFOID:0000000012431831
1.CHECK FUNCTION
Door switch BCM
Continuity
Connector TerminalConnector Terminal
Front door switch
LH B8
3M100 47
Ye s
Front door switch
RH B16
45
Door switch GroundContinuity
Connector Terminal
Front door switch LH B8
3N o
Front door switch RH B16
Door switch
Condition Continuity
Te r m i n a l
Front door switch
LH 3Ground part of door
switch Door switch Pressed
No
Released Yes
Front door switch
RH Pressed
No
Released Yes
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2702 of 3641

DOOR SWITCHPWC-41
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G H
I
J
L
M A
B
PWC
N
O P
With CONSULT
Check door switches “DOOR SW-DR” and “DOOR SW-AS” in “Data Monitor”.
Is the inspection result normal?
YES >> Door switch is OK.
NO >> Refer to PWC-41, "
WITHOUT INTELLIGENT KEY SY STEM : Diagnosis Procedure".
WITHOUT INTELLIGENT KEY SYSTEM : Diagnosis ProcedureINFOID:0000000012431832
Regarding Wiring Diagram information, refer to PWC-16, "Wiring Diagram".
1.CHECK DOOR SWITCH INPUT SIGNAL
1. Turn ignition switch OFF.
2. Check signal between BCM connector and ground with oscilloscope.
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 2.
2.CHECK DOOR SWITCH CIRCUIT
1. Disconnect BCM connector.
2. Check continuity between BCM connector and door switch connector.
Monitor item Condition
DOOR SW-DR CLOSE → OPEN: OFF → ON
DOOR SW-AS
Te r m i n a l s
Door condition Voltage (V)
(Approx.)
(+)
(–)
BCM
connector Te r m i n a l
M20 60
Ground Front RH
OPEN
0
CLOSE
59 Front LHOPEN
0
CLOSE
PKIB4960J
PKIB4960J
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2703 of 3641

PWC-42
< DTC/CIRCUIT DIAGNOSIS >
DOOR SWITCH
3. Check continuity between BCM connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness between BCM and door switch.
3.CHECK DOOR SWITCH
Refer to PWC-42, "
WITHOUT INTELLIGENT KEY SY STEM : Component Inspection".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Replace malfunctioning door switch. Refer to DLK-308, "
Removal and Installation".
4.CHECK INTERMITTENT INCIDENT
Refer to GI-42, "
Intermittent Incident".
>> Inspection End.
WITHOUT INTELLIGENT KEY SYSTEM : Component InspectionINFOID:0000000012431833
1.CHECK DOOR SWITCH
1. Turn ignition switch OFF.
2. Disconnect door switch connector.
3. Check door switch.
Is the inspection result normal?
YES >> Inspection End.
NO >> Replace malfunctioning door switch. Refer to DLK-308, "
Removal and Installation".
BCM connectorTerminal Door switch
connector Terminal Continuity
M20 60
B16 (Front RH)
3Yes
59 B8 (Front LH)
BCM connector Terminal
GroundContinuity
M20 60
No
59
Te r m i n a l Door switch condition Continuity
Door switch
3 Ground part of door switch Pressed
No
Released Yes
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2704 of 3641

POWER WINDOW CONTROL SYSTEM SYMPTOMS
PWC-43
< SYMPTOM DIAGNOSIS >
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
SYMPTOM DIAGNOSIS
POWER WINDOW CONTROL SYSTEM SYMPTOMS
Symptom TableINFOID:0000000012431834
Symptom Reference page
None of the power windows can be operated using any switch. Refer to PWC-44, "
Diagnosis Proce-
dure".
Driver side power window does not operate. Refer to PWC-45, "
Diagnosis Proce-
dure".
Front passenger side power window does not operate (When both main power window and
door lock/unlock switch and power window and door lock/unlock switch RH are
operated). Refer to PWC-46, "
WHEN BOTH POW-
ER WINDOW MAIN SWITCH AND
FRONT POWER WINDOW SWITCH
ARE OPERATED :
Diagnosis Proce-
dure".
Front passenger side power window does not operate (when power window and door lock/
unlock switch RH is operated). Refer to PWC-46, "
WHEN FRONT
POWER WINDOW SWITCH (PASSEN-
GER SIDE) IS OPERATED : Diagnosis
Procedure".
Front passenger side power window does not operate (when power window main switch
is operated). Refer to PWC-47, "
WHEN POWER WIN-
DOW MAIN SWITCH IS OPERATED :
Diagnosis Procedure".
Rear (LH) side power window does not operate (when both main power window and door
lock/unlock switch and rear power window switch LH are operated). Refer to PWC-48, "
WHEN BOTH POW-
ER WINDOW MAIN SWITCH AND
REAR POWER WINDOW SWITCH LH
ARE OPERATED :
Diagnosis Proce-
dure".
Rear (LH) side power window does not operate (when rear power window switch LH is op-
erated). Refer to PWC-48, "
WHEN REAR POW-
ER WINDOW SWITCH LH IS OPERAT-
ED : Diagnosis Procedure".
Rear (LH) side power window does not operate (when main power window and door lock/
unlock switch is operated). Refer to
PWC-49, "
WHEN POWER WIN-
DOW MAIN SWITCH IS OPERATED :
Diagnosis Procedure".
Rear (RH) side power window does not operate (when both main power window and door
lock/unlock switch and rear power window switch RH are operated). Refer to PWC-50, "
WHEN BOTH POW-
ER WINDOW MAIN SWITCH AND
REAR POWER WINDOW SWITCH RH
ARE OPERATED :
Diagnosis Proce-
dure".
Rear (RH) side power window does not operate (when rear power window switch RH is
operated). Refer to PWC-50, "
WHEN REAR POW-
ER WINDOW SWITCH RH IS OPERAT-
ED : Diagnosis Procedure".
Rear (RH) side power window does not operate (when main power window and door lock/
unlock switch is operated) Refer to PWC-51, "
WHEN POWER WIN-
DOW MAIN SWITCH IS OPERATED :
Diagnosis Procedure".
Power window lock switch does not function. Refer to PWC-54, "
Diagnosis Proce-
dure".
Revision: August 2015
2016 Versa Note
cardiagn.com
