NISSAN NOTE 2016 Service Repair Manual SB-12
< REMOVAL AND INSTALLATION >
REAR SEAT BELT
REAR SEAT BELT
Exploded ViewINFOID:0000000012430704
REAR SEAT BELT BUCKLE
REAR SEAT BELT BUCKLE : Removal and InstallationINFOID:0000000012430705
REMO

Page 2810 of 3641

NISSAN NOTE 2016 Service Repair Manual REAR SEAT BELTSB-13
< REMOVAL AND INSTALLATION >
C
DE
F
G
I
J
K L
M A
B
SB
N
O P
2. Release seat belt retractor (center) (1) from seat belt buckle (LH) (2) using a suitable tool (A) as shown.
3. Remov

Page 2811 of 3641

NISSAN NOTE 2016 Service Repair Manual SB-14
< REMOVAL AND INSTALLATION >
REAR SEAT BELT
2. For seat belt retractor (LH) (1).
a. Remove D-ring anchor bolt (A).: Front
CAUTION:
Before removing the D-ring anchor bolt, note the positions
of w

Page 2812 of 3641

NISSAN NOTE 2016 Service Repair Manual LATCH (LOWER ANCHORS AND TETHER FOR CHILDREN) SYSTEMSB-15
< REMOVAL AND INSTALLATION >
C
DE
F
G
I
J
K L
M A
B
SB
N
O P
LATCH (LOWER ANCHORS AND TE THER FOR CHILDREN) SYSTEM
Removal and InstallationINF

Page 2813 of 3641

NISSAN NOTE 2016 Service Repair Manual SB-16
< REMOVAL AND INSTALLATION >
TOP TETHER STRAP CHILD RESTRAINT
TOP TETHER STRAP CHILD RESTRAINT
Removal and InstallationINFOID:0000000012430708
The Top Tether Strap Child Restraint system is not

Page 2814 of 3641

NISSAN NOTE 2016 Service Repair Manual SE-1
BODY INTERIOR
C
DE
F
G H
I
K L
M
SECTION SE
A
B
SE
N
O P
CONTENTS
SEAT
PRECAUTION ....... ........................................2
PRECAUTIONS .............................................. ....

SE-1
BODY INTERIOR
C
DE
F
G H
I
K L
M
SECTION SE
A
B
SE
N
O P
CONTENTS
SEAT
PRECAUTION ....... ........................................2
PRECAUTIONS .............................................. .....2
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ............................................................. ......
2
Precaution for Work ..................................................2
PREPARATION ............................................3
PREPARATION .............................................. .....3
Special Service Tools .......................................... ......3
Commercial Service Tools ........................................3
CLIP LIST ............................................................4
Descriptions for Clips ................................................4
SYMPTOM DIAGNOSIS ...............................8
SQUEAK AND RATTLE TROUBLE DIAG-
NOSES ........................ ........................................
8
Work Flow ........................................................... ......8
Generic Squeak and Rattle Troubleshooting ............9
Diagnostic Worksheet .............................................12
WIRING DIAGRAM ......................................14
HEATED SEAT SYSTEM ...................................14
Wiring Diagram ................................................... ....14
REMOVAL AND INSTALLATION ...............18
FRONT SEAT ................................................. ....18
DRIVER SIDE ........................................................ ....18
DRIVER SIDE : Exploded View ..............................18
DRIVER SIDE : Removal and Installation ...............20
PASSENGER SIDE ...................................................20
PASSENGER SIDE : Exploded View .................. ....21
PASSENGER SIDE : Removal and Installation ......22
REAR SEAT ......................................................23
Exploded View ..................................................... ....23
SEAT CUSHION .................................................... ....26
SEAT CUSHION : Removal and Installation ...........26
SEATBACK ............................................................ ....26
SEATBACK : Removal and Installation ...................26
SEATBACK HINGE ............................................... ....27
SEATBACK HINGE : Removal and Installation .......27
SEATBACK STRIKER ........................................... ....27
SEATBACK STRIKER : Removal and Installation ....27
SEAT CUSHION HOOK ......................................... ....27
SEAT CUSHION HOOK : Removal and Installa-
tion ...........................................................................
27
FRONT HEATED SEAT SWITCH .....................29
Removal and Installation .........................................29
UNIT DISASSEMBLY AND ASSEMBLY ....30
FRONT SEAT ....................................................30
DRIVER SIDE ......................................................... ....30
DRIVER SIDE : Exploded View ...............................30
DRIVER SIDE : Seatback ........................................32
DRIVER SIDE : Seat Cushion .................................33
PASSENGER SIDE ....................................................34
PASSENGER SIDE : Explode d View ......................35
PASSENGER SIDE : Seatback ...............................36
PASSENGER SIDE : Seat Cushion ........................36
REAR SEAT ......................................................38
Exploded View ..................................................... ....38
Seat Cushion ...........................................................41
Seatback ..................................................................42
Revision: August 2015 2016 Versa Note

cardiagn.com

Page 2815 of 3641

NISSAN NOTE 2016 Service Repair Manual SE-2
< PRECAUTION >
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000012432026
The Supplemental Restraint Sy

SE-2
< PRECAUTION >
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000012432026
The Supplemental Restraint System such as “A IR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the SR and SB section of
this Service Manual.
WARNING:
• To avoid rendering the SRS inopera tive, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
• Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintent ional activation of the system. For re moval of Spiral Cable and Air Bag
Module, see the SR section.
• Do not use electrical test equipmen t on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harn esses can be identified by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
• When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Igni-
tion ON or engine running, DO NOT use air or electri c power tools or strike near the sensor(s) with a
hammer. Heavy vibration could activate the sensor( s) and deploy the air bag(s), possibly causing
serious injury.
• When using air or electric power tools or hammers , always switch the Ignition OFF, disconnect the
battery and wait at least three minutes before performing any service.
Precaution for WorkINFOID:0000000012432027
• When removing or disassembling each component, be careful not to damage or deform it. If a component may be subject to interference, be sure to protect it with a shop cloth.
• When removing (disengaging) components with a screwdriver or similar tool, be sure to wrap the component with a shop cloth or vinyl tape to protect it.
• Protect the removed parts with a shop cloth and prevent them from being dropped.
• Replace a deformed or damaged clip.
• If a part is specified as a non-reusable part, always replace it with a new one.
• Be sure to tighten bolts and nuts securely to the specified torque.
• After installation is complete, be sure to check that each part works properly.
• Follow the steps below to clean components:
- Water soluble dirt:
• Dip a soft cloth into lukewarm water, wring the water out of the cloth and wipe the dirty area.
• Then rub with a soft, dry cloth.
- Oily dirt:
• Dip a soft cloth into lukewarm water with mild detergent (concentration: within 2 to 3%) and wipe the dirty area.
• Then dip a cloth into fresh water, wring the water out of the cloth and wipe the detergent off.
• Then rub with a soft, dry cloth.
- Do not use organic solvent such as thinner, benzene, alcohol or gasoline.
- For genuine leather seats, use a genuine leather seat cleaner.
Revision: August 2015 2016 Versa Note

cardiagn.com

Page 2816 of 3641

NISSAN NOTE 2016 Service Repair Manual PREPARATIONSE-3
< PREPARATION >
C
DE
F
G H
I
K L
M A
B
SE
N
O P
PREPARATION
PREPARATION
Special Service ToolsINFOID:0000000012432028
The actual shape of the tools may di ffer from those illustrated he
