Page 1113 of 3641

NISSAN NOTE 2016 Service Repair Manual EM-112 < UNIT DISASSEMBLY AND ASSEMBLY >[HR16DE] HOW TO SELECT PISTON AND BEARING 2. Apply the measured dimension to the “Connecting Rod Bearing Selection Table”. 3. Read the symbol at the cross p

Page 1114 of 3641

NISSAN NOTE 2016 Service Repair Manual HOW TO SELECT PISTON AND BEARINGEM-113 < UNIT DISASSEMBLY AND ASSEMBLY > [HR16DE] C D E F G H I J K L M A EM NP O In grinding crankshaft pin to use undersize bearings, keep the fillet R (A) [0.8 - 1.

Page 1115 of 3641

NISSAN NOTE 2016 Service Repair Manual EM-114 < UNIT DISASSEMBLY AND ASSEMBLY >[HR16DE] HOW TO SELECT PISTON AND BEARING Main Bearing Selection Table Main Bearing Grade Table Use Undersize Bearing Usage Guide • When the specified main

Page 1116 of 3641

NISSAN NOTE 2016 Service Repair Manual HOW TO SELECT PISTON AND BEARINGEM-115 < UNIT DISASSEMBLY AND ASSEMBLY > [HR16DE] C D E F G H I J K L M A EM NP O In grinding crankshaft main jour nal to use undersize bearings, keep fillet (A) [0.8 -

Page 1117 of 3641

NISSAN NOTE 2016 Service Repair Manual EM-116 < SERVICE DATA AND SPECIFICATIONS (SDS) [HR16DE] SERVICE DATA AND SPECIFICATIONS (SDS) SERVICE DATA AND SPECIFICATIONS (SDS) SERVICE DATA AND SPECIFICATIONS (SDS) General SpecificationINFOID:00

Page 1118 of 3641

NISSAN NOTE 2016 Service Repair Manual SERVICE DATA AND SPECIFICATIONS (SDS)EM-117 < SERVICE DATA AND SPECIFICATIONS (SDS) [HR16DE] C D E F G H I J K L M A EM NP O Belt Tension and Frequency *: When engine is cold. Spark PlugINFOID:000000

Page 1119 of 3641

NISSAN NOTE 2016 Service Repair Manual EM-118 < SERVICE DATA AND SPECIFICATIONS (SDS) [HR16DE] SERVICE DATA AND SPECIFICATIONS (SDS) *: Total indicator reading VALVE LIFTER Unit: mm (in) VALVE CLEARANCE Unit: mm (in) 1:Approximately 20 °C

Page 1120 of 3641

NISSAN NOTE 2016 Service Repair Manual SERVICE DATA AND SPECIFICATIONS (SDS)EM-119 < SERVICE DATA AND SPECIFICATIONS (SDS) [HR16DE] C D E F G H I J K L M A EM NP O Cylinder headINFOID:0000000012431747 CYLINDER HEAD Unit: mm (in) VALVE DIM
