Page 1585 of 3641

NISSAN NOTE 2016 Service Repair Manual EC-458
< DTC/CIRCUIT DIAGNOSIS >[HR16DE]
ON BOARD REFUELING VAPOR RECOVERY (ORVR)
Check the EVAP hose between EVAP canister and
vehicle frame for clogging or poor connection.
>> Repair or replace EVA

Page 1586 of 3641

NISSAN NOTE 2016 Service Repair Manual ON BOARD REFUELING VAPOR RECOVERY (ORVR)EC-459
< DTC/CIRCUIT DIAGNOSIS > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
Check recirculation line for clogging, dents and cracks.
Is the inspection result nor

ON BOARD REFUELING VAPOR RECOVERY (ORVR)EC-459
< DTC/CIRCUIT DIAGNOSIS > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
Check recirculation line for clogging, dents and cracks.
Is the inspection result normal?
YES >> GO TO 15.
NO >> Replace fuel filler tube.
15.CHECK REFUELING EVAP VAPOR CUT VALVE
Refer to EC-459, "
Component Inspection (Refueling EVAP vapor cut valve)".
Is the inspection result normal?
YES >> GO TO 16.
NO >> Replace refueling EVAP vapor cut valve with fuel tank.
16.CHECK FUEL FILLER TUBE
Check fuel filler tube and hose connected to the fuel tank for clogging, dents and cracks.
Is the inspection result normal?
YES >> GO TO 17.
NO >> Replace fuel filler tube.
17.CHECK ONE-WAY FUEL VALVE-I
Check one-way valve for clogging.
Is the inspection result normal?
YES >> GO TO 18.
NO >> Repair or replace one-way fuel valve with fuel tank.
18.CHECK ONE-WAY FUEL VALVE-II
1. Make sure that fuel is drained from the tank.
2. Remove fuel filler tube and hose.
3. Check one-way fuel valve for operation as per the following. When a stick is inserted, the valve should open, when removing
stick it should close.
Do not drop any material into the tank.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace fuel filler tube or replace one-way fuel valve with fuel tank.
Component Inspection (Refuel ing EVAP vapor cut valve)INFOID:0000000012431662
1.INSPECTION START
Do you have CONSULT?
Do you have CONSULT?
YES >> GO TO 2.
NO >> GO TO 3.
2.CHECK REFUELING EVAP VAPOR CUT VALVE
With CONSULT
1. Remove fuel tank. Refer to FL-10, "
Removal and Installation".
2. Drain fuel from the tank as per the following:
- Remove fuel feed hose located on the fuel gauge retainer.
- Connect a spare fuel hose, one side to fuel gauge retainer where the hose was removed and the other side to a fuel container.
- Drain fuel using “FUEL PUMP RELAY” in “ACTIVE TEST” mode of “ENGINE” using CONSULT.
3. Check refueling EVAP vapor cut valve for being stuck to close as per the following. Blow air into the refueling EVAP vapor cut valv e (from the end of EVAP/ORVR line hose), and check that
the air flows freely into the tank.
4. Check refueling EVAP vapor cut valve for being stuck to open as per the following.
SEF665U
Revision: August 2015 2016 Versa Note

cardiagn.com

Page 1587 of 3641

NISSAN NOTE 2016 Service Repair Manual EC-460
< DTC/CIRCUIT DIAGNOSIS >[HR16DE]
ON BOARD REFUELING VAPOR RECOVERY (ORVR)
- Connect vacuum pump to hose end.
- Remove fuel gauge retainer with fuel gauge unit.
Always replace O-ri ng with new

Page 1588 of 3641

NISSAN NOTE 2016 Service Repair Manual ON BOARD REFUELING VAPOR RECOVERY (ORVR)EC-461
< DTC/CIRCUIT DIAGNOSIS > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace refueling EVAP va

Page 1589 of 3641

NISSAN NOTE 2016 Service Repair Manual EC-462
< DTC/CIRCUIT DIAGNOSIS >[HR16DE]
REFRIGERANT PRESSURE SENSOR
REFRIGERANT PRESSURE SENSOR
Component Function CheckINFOID:0000000012431664
1.CHECK REFRIGERANT PRESSURE SENSOR OVERALL FUNCTION
1.

Page 1590 of 3641

NISSAN NOTE 2016 Service Repair Manual REFRIGERANT PRESSURE SENSOREC-463
< DTC/CIRCUIT DIAGNOSIS > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES

Page 1591 of 3641

NISSAN NOTE 2016 Service Repair Manual EC-464
< SYMPTOM DIAGNOSIS >[HR16DE]
ENGINE CONTROL SYSTEM SYMPTOMS
SYMPTOM DIAGNOSIS
ENGINE CONTROL SYSTEM SYMPTOMS
Symptom TableINFOID:0000000012431666
SYSTEM — BASIC ENGINE CONTROL SYSTEM
SYMPTOM

Page 1592 of 3641

NISSAN NOTE 2016 Service Repair Manual ENGINE CONTROL SYSTEM SYMPTOMSEC-465
< SYMPTOM DIAGNOSIS > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
Mass air flow sensor circuit
1
12 2
222 2 EC-190, "DTC Log-
ic"
Engine coolant temperature sensor
c
