NISSAN NOTE 2016 Service Repair Manual FAX-16
< REMOVAL AND INSTALLATION >
FRONT DRIVE SHAFT BOOT
INSTALLATION
1. Clean the old grease from the joint sub-assembly using paper waste.
2. Fill the serration slot on the joint sub-assembly (1)

Page 1834 of 3641

NISSAN NOTE 2016 Service Repair Manual FRONT DRIVE SHAFT BOOTFAX-17
< REMOVAL AND INSTALLATION >
CEF
G H
I
J
K L
M A
B
FA X
N
O P
9. Install the boot securely into the grooves (indicated by “*” marks) as shown.
CAUTION:
If there is gre

FRONT DRIVE SHAFT BOOTFAX-17
< REMOVAL AND INSTALLATION >
CEF
G H
I
J
K L
M A
B
FA X
N
O P
9. Install the boot securely into the grooves (indicated by “*” marks) as shown.
CAUTION:
If there is grease on the bo ot mounting surfaces (indicated
by “*” marks) on the shaft or the joint sub-assembly, the
boot may come off. Remo ve all grease from the boot
mounting surfaces.
10. To prevent the deformation of the boot, adjust the boot installa- tion length to the specified value by inserting a suitable tool into
the inside of the boot from the large diameter side of the boot
and discharging the inside air.
CAUTION:
• The boot may break if the boot in stallation length is not correct.
• Be careful not to touch the inside of the boot with the tip of the suitable tool.
11. Install new large and small boot bands securely using Tool (A). CAUTION:
Do not reuse the boot bands.
12. Secure the boot band so that dimension (A) meets the specifica- tion.
13. Attempt to rotate the boot to check whether or not the boot bands are securing the boot. If the boot is not secure, remove
the boot bands, reposition the boot, and install new boot bands.
14. Clean the mating surfaces of wheel hub lock nut and wheel hub. CAUTION:
Do not apply lubricating oil to these mating surfaces.
15. Clean the mating surfaces of the drive shaft, wheel hub, and wheel bearing. Apply Molykote M77 lubricant to the surface (A)
of the joint sub-assembly.
CAUTION:
Apply Molykote M77 to cover the entire flat mating surface
of the joint sub-assembly.
NOTE:
Always check with the Parts Department for the latest parts
information.
16. Install the drive shaft to the wheel hub. Temporaril y install, but do not tighten, the wheel hub lock nut.
CAUTION:
• Do not damage the wheel bearing seal. If damage has occurred, replace wheel bearing.
• Do not allow paint to adhere to the wheel bearing seal.
Boot installation length (L) : Refer to
FAX-27, "
Drive Shaft".
Tool number (A) : KV40107300 ( – )
JSDIA2261ZZ
JPDIF0012ZZ
Dimension (A) : Refer to FAX-27, "Drive Shaft".
JPDIF0268ZZ
Molykote M77 quantity Refer to FAX-27, "Drive Shaft".
JSDIA2844ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

Page 1835 of 3641

NISSAN NOTE 2016 Service Repair Manual FAX-18
< REMOVAL AND INSTALLATION >
FRONT DRIVE SHAFT BOOT
• Check each mating surface for water and foreign matter. If there is any water or foreign matter,
clean the mating surface.
17. Install th

FAX-18
< REMOVAL AND INSTALLATION >
FRONT DRIVE SHAFT BOOT
• Check each mating surface for water and foreign matter. If there is any water or foreign matter,
clean the mating surface.
17. Install the transverse link to the steering knuckle with the nut and bolt. Refer to FSU-10, "
Exploded View".
18. Hold the wheel hub using a Tool. Tighten the wheel hub lock nut. CAUTION:
• Since the drive shaft is assembled by press-fitting, use a torque wrench to tighten the wheel hub
lock nut. Do not use a power tool.
• Too much torque causes axle noise. Too little torque causes wheel bearing looseness. Tighten the wheel hub lock nut to the specification.
19. Install the cotter pin. Securely bend the cotter pin to prevent rattles. CAUTION:
Do not reuse the cotter pin.
20. Install the wheel sensor, the wheel sensor bolt, and the wheel sensor harness. Refer to BRC-140,
"FRONT WHEEL SENSOR : Removal and Installation".
21. Align the matching marks on the disc brake roto r and on the wheel hub. Install the disc brake rotor.
CAUTION:
Do not drop the disc brake rotor.
22. Remove the wire from the brake caliper. Install the brake caliper and the brake caliper torque member
bolts. Refer to BR-37, "
BRAKE CALIPER ASSEMBLY : Removal and Installation".
CAUTION:
Do not twist the brake hose.
23. Install the wheel and tire. Refer to WT-48, "
Removal and Installation".
24. Complete the inspection. Refer to FAX-18, "
Inspection".
TRANSAXLE SIDE
TRANSAXLE SIDE : Removal and InstallationINFOID:0000000012431896
Remove boot after drive shaft is removed from the vehicle.
• For drive shaft removal and installation, refer to FAX-19, "
Removal and Installation".
• For drive shaft disassembly and assembly, refer to FAX-22, "
Disassembly and Assembly".
InspectionINFOID:0000000012431897
INSPECTION AFTER INSTALLATION
1. Check the wheel sensor harness to be sure the connectors are fully seated.
2. Check the wheel alignment. Refer to FSU-7, "
Inspection".
Tool number : KV4010104000 ( — )
Revision: August 2015
2016 Versa Note

cardiagn.com

Page 1836 of 3641

NISSAN NOTE 2016 Service Repair Manual FRONT DRIVE SHAFTFAX-19
< REMOVAL AND INSTALLATION >
CEF
G H
I
J
K L
M A
B
FA X
N
O P
FRONT DRIVE SHAFT
Exploded ViewINFOID:0000000012431898
Removal and InstallationINFOID:0000000012431899
NOTE:
When

Page 1837 of 3641

NISSAN NOTE 2016 Service Repair Manual FAX-20
< REMOVAL AND INSTALLATION >
FRONT DRIVE SHAFT
11. Insert the Tool (A) between the drive shaft and the transaxle.
Insert the suitable tool (B) to the Tool (A). Remove the drive
shaft from the t

FAX-20
< REMOVAL AND INSTALLATION >
FRONT DRIVE SHAFT
11. Insert the Tool (A) between the drive shaft and the transaxle.
Insert the suitable tool (B) to the Tool (A). Remove the drive
shaft from the transaxle.
CAUTION:
• Do not place drive shaft joint at an extreme angle when removing drive shaft. Also be careful not to overextend
slide joint.
• Confirm that the circular clip is attached to the drive shaft.
12. Remove the differential side oil seal. Refer to TM-18, "
Removal
and Installation" (5MT:RS5F91R), or TM-249, "Removal and Installation" (CVT:RE0F11A).
INSTALLATION
Installation is in the reverse order of removal.
Transaxle Side
• Install a new differential side oil seal. Refer to TM-18, "Removal and Installation" (5MT:RS5F91R), or TM-
249, "Removal and Installation" (CVT:RE0F11A).
CAUTION:
Do not reuse the differential side oil seal.
• Place the Tool (A) onto transaxle to prevent damage to the oil seal while inserting drive shaft. Slide drive shaft sliding joint and tap
with a hammer to install securely.
CAUTION:
• Check that circular clip is completely engaged.
• Check the transaxle fluid level. Refer to TM-17, "
Inspection"
(5MT), or TM-228, "Inspection" (CVT).
Wheel Hub Side
CAUTION:
• Do not damage the wheel bearing seal. If damage has occurred, replace wheel bearing with a new
one.
• Do not allow paint to adhere to the wheel bearing seal.
• Check each mating surface for water and foreign matter. If there is any water or foreign matter, clean
the mating surface.
• Clean the mating surfaces of wheel hub lock nut and wheel hub.
CAUTION:
Do not apply lubricatin g oil to the mating surface of the wh eel hub lock nut and the wheel hub.
• Clean the mating surfaces of drive shaft, wheel hub, and wheel
bearing. Apply Molykote M77 to surface (A) of joint sub-assembly.
CAUTION:
Apply Molykote M77 to cover entire flat surface of joint sub-
assembly.
NOTE:
Always check with the Parts Department for the latest parts infor-
mation.
When installing a cotter pin, securely bend the cotter pin to prevent
rattles.
CAUTION:
Do not reuse cotter pin. Tool number (A) : KV40107500 ( — )
JPDIF0004ZZ
Tool number (A) : KV38107900 ( — )
JPDIF0023ZZ
Molykote M77 quantity : Refer to
FAX-27, "Drive
Shaft".JSDIA2844ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

Page 1838 of 3641

NISSAN NOTE 2016 Service Repair Manual FRONT DRIVE SHAFTFAX-21
< UNIT DISASSEMBLY AND ASSEMBLY >
CEF
G H
I
J
K L
M A
B
FA X
N
O P
UNIT DISASSEMBLY AND ASSEMBLY
FRONT DRIVE SHAFT
Exploded ViewINFOID:0000000012431900
(LH)
(RH)
JPDIF0266ZZ
1.

Page 1839 of 3641

NISSAN NOTE 2016 Service Repair Manual FAX-22
< UNIT DISASSEMBLY AND ASSEMBLY >
FRONT DRIVE SHAFT
Disassembly and Assembly
INFOID:0000000012431901
DISASSEMBLY (WHEEL SIDE)
1. Mount the drive shaft in a vise. CAUTION:
When mounting the driv

Page 1840 of 3641

NISSAN NOTE 2016 Service Repair Manual FRONT DRIVE SHAFTFAX-23
< UNIT DISASSEMBLY AND ASSEMBLY >
CEF
G H
I
J
K L
M A
B
FA X
N
O P
10. Remove the circular clip from the slide joint housing.
11. Clean the old grease from the slide joint hous
