2016 NISSAN NOTE AUDIO SET UP

AV
PREPARATIONAV-7
< PREPARATION > [BASE AUDIO]
C
D
E
F
G H
I
J
K L
M B A
O P
PREPARATION
PREPARATION
Special Service ToolsINFOID:0000000012432860
The actual shape of the tools may di ffer from those illustrated here.
Commercial Service ToolsINFOID:0000000012432861
Tool number
(TechMate No.)
Tool name Description
—
(J-46534)
Trim Tool Set Removing trim components
AWJIA0483ZZ
Tool name
Description
Power tool Loosening nuts, screws and bolts
PIIB1407E
Revision: August 2015 2016 Versa Note

cardiagn.com

AV-12
< SYSTEM DESCRIPTION >[BASE AUDIO]
SYSTEM
SYSTEM
System DescriptionINFOID:0000000012432870
SYSTEM DIAGRAM
AUDIO SYSTEM
The audio system consists of the following components
• Audio unit
• Front door speakers
• Rear door speakers
• Steering wheel audio control switches
• Antenna base (antenna amp.)
• Rod antenna
When the audio system is on, AM/FM signals received
by the rod antenna are amplified by the antenna amp.
and sent to the audio unit. The audio unit then sends audio signals to the front door speakers and rear door
speakers.
Refer to Owner's Manual for audio system operating instructions.
HANDS-FREE PHONE SYSTEM
System Operation
NOTE:
Cellular telephones must have their wireless connec tion set up (paired) before using the Bluetooth
® telephone
system.
The Bluetooth
® telephone system allows users who have a Bluetooth® cellular telephone to make a wireless
connection between their cellular telephone and the Bluetooth
® control unit. Hands-free cellular telephone
calls can be sent and received. Some Bluetooth
® cellular telephones may not be recognized by the Bluetooth®
control unit. When a cellular telephone or the Bluetooth® control unit is replaced, the telephone must be paired
with the Bluetooth
® control unit. Different cellular telephones may have different pairing procedures, refer to
the cellular telephone operating manual.
Refer to the Owner's Manual for Bluetooth
® telephone system operating instructions.
Bluetooth® Control Unit
When the ignition switch is turned to ACC or ON, the Bluetooth® control unit will power up. During power up,
the Bluetooth
® control unit is initialized and performs various self-checks. Initialization may take up to 20 sec-
onds.
Steering Wheel Audio Control Switches
When buttons on the steering wheel audio control switches are pushed, the resistance in steering wheel audio
control switch circuit changes, depending on which button is pushed.
The following functions can be performed using the steering wheel audio control switches:
• Initiate self-diagnosis of the Bluetooth
® telephone system
• Answer and end telephone calls
AWNIA4134GB
Revision: August 2015 2016 Versa Note

cardiagn.com

AV-14
< SYSTEM DESCRIPTION >[BASE AUDIO]
DIAGNOSIS SYSTEM (AUDIO UNIT)
DIAGNOSIS SYSTEM (AUDIO UNIT)
Diagnosis DescriptionINFOID:0000000012432871
The audio unit on board diagnosis performs the functions listed in the table below:
On Board Diagn
osis FunctionINFOID:0000000012432872
METHOD OF STARTING
Hardware/Software Versions and Speaker Channel Check
1. Turn the ignition ON.
2. Turn the audio system OFF.
3. While pressing the preset 1 butt on, turn the volume control dial
clockwise or counterclockwise 30 clicks or more.
4. Initially, all display segments will be illuminated.
5. To exit hardware/software versions and speaker channel check, turn the ignition OFF.
Communication Diagnosis
1. Turn the ignition ON.
2. Turn the audio system OFF.
Mode Description
Hardware/Software Versions The following information is available for the audio unit:
• hardware version.
• software version.
• EQ pin info.
Speaker Channel Check The connection of the speakers to the audio unit can be confirmed.
Communication Diagnosis The AV communication (M-CAN) message history can be monitored.
AWNIA3042ZZ
ALNIA1382GB
Revision: August 2015 2016 Versa Note

cardiagn.com

AV
DIAGNOSIS SYSTEM (AUDIO UNIT)AV-15
< SYSTEM DESCRIPTION > [BASE AUDIO]
C
D
E
F
G H
I
J
K L
M B A
O P
3. While pressing the preset 6 button, turn the volume control dial clockwise or counterclockwise 30 clicks or more.
4. Initially, the communication diagnosis mode is displayed.
5. To exit communication diagnosis, turn the ignition OFF.
SELF DIAGNOSIS MODE
Hardware/Software Versions
1. Press the DISP button to enter versions display, and the audio head unit software version is displayed.
2. With each additional press of the DISP button, the following information is available:
- HARD V###### (hardware version)
- EEP V###### (EEPROM version)
- @@@@ EQ1-4 # (EQ pin info) If an EQ error is present, INVALID EQ is displayed
3. Hold the DISP button down to return to all display segments screen.
Speaker Channel Check
ALNIA1516ZZ
ALNIA1387GB
ALNIA1383GB
Revision: August 2015 2016 Versa Note

cardiagn.com

AV-64
< PREPARATION >[DISPLAY AUDIO]
PREPARATION
PREPARATION
PREPARATION
Special Service ToolsINFOID:0000000012432949
The actual shape of the tools may differ from those illustrated here.
Commercial Service ToolsINFOID:0000000012432950
Tool number
(TechMate No.)
Tool name Description
—
(J-46534)
Trim Tool Set Removing trim components
AWJIA0483ZZ
Tool name
Description
Power tool Loosening nuts, screws and bolts
PIIB1407E
Revision: August 2015 2016 Versa Note

cardiagn.com

AV
DIAGNOSIS SYSTEM (AUDIO UNIT)AV-71
< SYSTEM DESCRIPTION > [DISPLAY AUDIO]
C
D
E
F
G H
I
J
K L
M B A
O P
DIAGNOSIS SYSTEM (AUDIO UNIT)
DescriptionINFOID:0000000012432960
The audio unit on board diagnosis performs the functions listed in the table below:
On Board Diagnosis FunctionINFOID:0000000012432961
METHOD OF STARTING
1. Turn the ignition ON.
2. Turn the audio unit OFF.
3. While pressing the preset 1 button, turn the volume control dial clockwise and counterclockwise quickly approximately 15 times
or more. Shifting from current screen to previous screen is per-
formed by pressing BACK button.
4. The trouble diagnosis initial screen is displayed, and Self Diag- nosis or Confirmation/Adjustment can be selected.
SELF DIAGNOSIS MODE
Audio Unit Self Diagnosis
1. Select Self Diagnosis.
Mode Description
Self Diagnosis Audio unit diagnosis.
Confirmation/ Adjustment Display Diagnosis
The following check functions are available: color tone check by color
spectrum bar display and gray scale check by gradation bar display.
Vehicle Signals Diagnosis of signals can be performed for vehicle speed, lights, reverse,
EQ pin, ignition, destination and camera type.
Speaker Test The connection of a speaker can be confirmed by test tone.
Error History The system malfunction and the frequency when occurring in the past are
displayed. When the malfunctioning item is selected, the time and place
that the selected malfunction last occurred are displayed.
Camera System Guiding line position that overlaps rear view camera image can be adjust-
ed.
AV COMM Diagnosis Displayed but not used.
Delete Unit Connection Log Erase the connection history of unit and error history.
Version Information Displays the audio system version information.
Initialize Setting Initializes the audio unit memory.
ALNIA1710ZZ
JSNIA0138GB
Revision: August 2015 2016 Versa Note

cardiagn.com

AV-74
< SYSTEM DESCRIPTION >[DISPLAY AUDIO]
DIAGNOSIS SYSTEM (AUDIO UNIT)
Select Speaker Test to display the Speaker Diagnosis screen. Press
Start to generate a test tone in a speaker. Press Start again to gener-
ate a test tone in the next speaker.
Press End to stop the test tones.
Error History
The self diagnosis results are judged depending on whether any error occurs from when Self Diagnosis is
selected until the self diagnosis results are displayed.
However, the diagnosis results are judged normal if an error has occurred before the ignition switch is turned
ON and then no error has occurred until the self diagnosis start. Check the Error Record to detect any error
that may have occurred before the self di agnosis start because of this situation.
The frequency of occurrence is displayed in a count up manner. The actual count up method differs depending
on the error item.
Count up method A
• The counter is set to 40 if an error occurs. 1 is subtracted from the counter if the condition is normal at a next ignition ON cycle.
• The counter lower limit is 1. The counter can be reset (no error record display) with the Delete log switch.
Count up method B• The counter increases by 1 if an error occurs when i gnition switch is ON. The counter will not decrease even
if the condition is normal at the next ignition ON cycle.
• The counter upper limit is 50. Any counts exceeding 50 are ignored. The counter can be reset (no error
record display) with the Delete log switch.
Error item
Some error items may be displayed simultaneously according to the cause. If some error items are displayed
simultaneously, the detection of the cause can be performed by the combination of display items
Camera System
Use this mode to adjust the guide line display position of the rear
view monitor if necessary after removing the rear view camera.
Delete Unit Connection Log
AWNIA2634GB
Display type of occurrence frequency Error history display item
Count up method A AV communication line, control unit (AV)
Count up method B Other than the above
Error item DescriptionPossible cause
CONTROL UNIT (AV) AV communication circuit initial diagnosis
malfunction is detected.Replace the audio unit if the malfunction
occurs constantly.
Refer to
AV- 11 3 , "
Removal and Installation"
JSNIA1876ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

AV
DIAGNOSIS SYSTEM (AUDIO UNIT)AV-75
< SYSTEM DESCRIPTION > [DISPLAY AUDIO]
C
D
E
F
G H
I
J
K L
M B A
O P
Deletes any unit connection records and error records from the
audio unit memory (clears the records of the unit that has been
removed).
Version Information
Displays audio system version numbers.
Initialize Settings
Deletes data stored from the audio unit.
AWNIA2637GB
AWNIA3563ZZ
JSNIA0155GB
