AIR CLEANER FILTEREM-19
< PERIODIC MAINTENANCE > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
AIR CLEANER FILTER
Exploded ViewINFOID:0000000012431697
Removal and InstallationINFOID:0000000012431698
REMOVAL
1. Unhook clips (A) and pull the air cleaner cover (1) upward.
1. Air cleaner cover
2. Mass air flow sensor 3. Gasket
4. Clamp 5. Air duct 6. Clamp
7. Hose 8. Clamp 9. Grommet
10. Grommet insert 11. Grommet 12. Grommet insert
13. Air duct inlet 14. Air cleaner body 15. Air cleaner filter
A. To electric throttle contro l actuator B. To rocker cover
AWBIA2082ZZ
JSBIA1092ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

EM-20
< PERIODIC MAINTENANCE >[HR16DE]
AIR CLEANER FILTER
2. Remove the air cleaner filter (1) from the air cleaner body.
INSTALLATION
Installation is in the reverse order of removal.
NOTE:
Check that the air cleaner filter is securely placed in the air cleaner body.
JSBIA1093ZZ
Revision: August 2015
2016 Versa Note

cardiagn.com

EM-26
< REMOVAL AND INSTALLATION >[HR16DE]
AIR CLEANER AND AIR DUCT
AIR CLEANER AND AIR DUCT
Exploded ViewINFOID:0000000012431703
Removal and InstallationINFOID:0000000012431704
REMOVAL
NOTE:
Mass air flow sensor is removable as an assembly with the air cleaner cover.
1. Remove air duct (inlet) from the air cleaner body.
2. Disconnect PCV hose from the air duct.
3. Remove the air duct (between air cleaner case and electric throttle control actuator).
• Add matching marks if necessary for easier installation.
4. Remove air cleaner assembly with the following steps:
a. Disconnect the mass air flow sensor harness connector.
b. Remove the air cleaner body bolts.
c. Pull up on the air cleaner assembly to disengage it from the grommet and remove the air cleaner assem- bly.
CAUTION:
• Do not shock the mass air flow sensor.
• Do not disassemble the mass air flow sensor.
• Do not touch the sensor of the mass air flow sensor.
INSPECTION AFTER REMOVAL
1. Air cleaner cover 2. Mass air flow sensor 3. Gasket
4. Clamp 5. Air duct 6. Clamp
7. Hose 8. Clamp 9. Grommet
10. Grommet insert 11. Grommet 12. Grommet insert
13. Air duct inlet 14. Air cleaner body 15. Air cleaner filter
A. To electric throttle control actuator B. To rocker cover
AWBIA2082ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

EM-68
< REMOVAL AND INSTALLATION >[HR16DE]
CAMSHAFT
• Before starting engine, check oil/fluid levels, including engine coolant and engine oil. If less than required
quantity, fill to the specified level. Refer to MA-11, "
Fluids and Lubricants".
• Use procedure below to check for fuel leaks.
• Turn ignition switch ON (with engine stopped). With fuel pressure applied to fuel piping, check for fuel leaks
at connection points.
• Start engine. With engine speed increased, che ck again for fuel leaks at connection points.
• Run engine to check for unusual noise and vibration. NOTE:
If hydraulic pressure inside timing chain tensioner drops after removal and installation, slack in the guide
may generate a pounding noise during and just after engine start. However, this is normal. Noise will stop
after hydraulic pressure rises.
• Warm up engine thoroughly to make sure there is no leak s of fuel, exhaust gas, or any oils/fluids including
engine oil and engine coolant.
• Bleed air from passages in lines and hoses, such as in cooling system.
• After cooling down engine, again check oil/fluid levels including engine oil and engine coolant. Refill to spec- ified level, if necessary.
• Summary of the inspection items:
*Power steering fluid, brake fluid, etc.
InspectionINFOID:0000000012431722
INSPECTION AFTER REMOVAL
Oil Filter
• Check that there is no foreign material on the oil filter (1) and check it for clogging.
• Check the oil filter for damage.
• If there is some damage, replace the oil filter, the plug, and the washer as a set.
CAUTION:
Do not reuse the washer.
Camshaft Runout
1. Put V-block on a precise flat table, and support No. 2 and 5 jour- nals of camshaft.
CAUTION:
Do not support No. 1 journal (on the side of camshaft
sprocket) because it has a differe nt diameter from the other
four locations.
2. Set a suitable tool vertically to No. 3 journal.
3. Turn camshaft to one direction, and measure the camshaft runout using suitable tool. (Total indicator reading)
Item Before starting engine Engine runningAfter engine stopped
Engine coolant LevelLeaks Level
Engine oil LevelLeaks Level
Transmission/
transaxle fluid CVT Models
LeaksLevel/Leaks Leaks
M/T Models Level/Leaks LeaksLevel/Leaks
Other oils and fluids* LevelLeaks Level
Fuel LeaksLeaksLeaks
Exhaust gas —Leaks —
PBIC3693E
PBIC2499E
Revision: August 2015 2016 Versa Note

cardiagn.com

EC-7
C
DE
F
G H
I
J
K L
M
EC A
N
O P
DTC Logic ...........................................................
..
416
Diagnosis Procedure .............................................416
Component Inspection ..........................................418
P2135 TP SENSOR ..........................................419
DTC Logic ........................................................... ..419
Diagnosis Procedure .............................................419
Component Inspection ..........................................420
P2138 APP SENSOR .......................................422
DTC Logic .............................................................422
Diagnosis Procedure .............................................422
Component Inspection ..........................................424
P219A AIR FUEL RATIO .................................426
DTC Logic ........................................................... ..426
Diagnosis Procedure .............................................427
P219C, P219D, P219E, P219F AIR FUEL RA-
TIO ....................................................................
431
DTC Logic ........................................................... ..431
Diagnosis Procedure .............................................433
ASCD BRAKE SWITCH ...................................437
Component Function Check ................................ ..437
Diagnosis Procedure .............................................437
Component Inspection (ASCD Brake Switch) .......438
CLUTCH PEDAL POSITION SWITCH .............439
Component Function Check ................................ ..439
Diagnosis Procedure .............................................439
Component Inspection (Clutch Pedal Position
Switch) ..................................................................
440
COOLING FAN .................................................441
Component Function Check ................................ ..441
Diagnosis Procedure .............................................441
Component Inspection (Cooling Fan Motor) .........443
Component Inspection (Cooling Fan Relay) .........443
ELECTRICAL LOAD SIGNAL .........................444
Description .......................................................... ..444
Component Function Check ..................................444
Diagnosis Procedure .............................................444
FUEL INJECTOR .............................................446
Component Function Check ................................ ..446
Diagnosis Procedure .............................................446
Component Inspection ..........................................447
FUEL PUMP .....................................................448
Component Function Check ................................ ..448
Diagnosis Procedure .............................................448
Component Inspection ..........................................450
IGNITION SIGNAL ...........................................451
Component Function Check ................................ ..451
Diagnosis Procedure .............................................451
Component Inspection (Ignition Coil with Power
Transistor) ........................................................... ..
454
Component Inspection (Condenser) ......................455
MALFUNCTION INDICATOR LAMP ..............456
Component Function Check ..................................456
Diagnosis Procedure .............................................456
ON BOARD REFUELING VAPOR RECOV-
ERY (ORVR) ....................................................
457
Component Function Check ..................................457
Diagnosis Procedure .............................................457
Component Inspection (Refueling EVAP vapor cut
valve) ................................................................... ..
459
Component Inspection (Drain filter) .......................461
REFRIGERANT PRESSURE SENSOR ..........462
Component Function Check ..................................462
Diagnosis Procedure .............................................462
SYMPTOM DIAGNOSIS ............................464
ENGINE CONTROL SYSTEM SYMPTOMS ...464
Symptom Table ................................................... ..464
NORMAL OPERATING CONDITION .............470
Description .............................................................470
PERIODIC MAINTENANCE ......................471
IDLE SPEED .... ...............................................471
Inspection ............................................................ ..471
IGNITION TIMING ...........................................472
Inspection ..............................................................472
EVAPORATIVE EMISSION SYSTEM .............473
Inspection ..............................................................473
EVAP LEAK CHECK ......................................474
Inspection ..............................................................474
POSITIVE CRANKCASE VENTILATION .......476
Inspection ..............................................................476
REMOVAL AND INSTALLATION .............477
ECM .................................................................477
Exploded View ..................................................... ..477
Removal and Installation .......................................477
SERVICE DATA AND SPECIFICATIONS
(SDS) ............... .......................................... .
478
SERVICE DATA AND SPECIFICATIONS
(SDS) ...............................................................
478
Idle Speed ........................................................... ..478
Ignition Timing .......................................................478
Calculated Load Value ..........................................478
Mass Air Flow Sensor ............................................478
Revision: August 2015 2016 Versa Note

cardiagn.com

EC-138
< BASIC INSPECTION >[HR16DE]
FUEL PRESSURE CHECK
4. Connect fuel hose for fuel pressure check (1) to fuel tube
(engine side) with clamp (2) as shown in the figure.
CAUTION:
• Wipe off oil or dirt from hose insertion part using clothmoistened with gasoline.
• Apply proper amount of gasoli ne between top of the fuel
tube (3) and No.1 spool (4).
• Insert fuel hose for fuel pressure check until it touches the No.1 spool on fuel tube.
• Use NISSAN genuine hose clamp (part number: 16439
N4710 or 16439 40U00).
• When reconnecting fuel line, always use new clamps.
• Use a torque driver to tighten clamps.
• Install hose clamp to the position within 1 - 2 mm (0.04 - 0.08 in).
• Make sure that clamp screw does not contact adjacent parts.
5. Connect fuel tube adapter to quick connector (1).
6. After connecting fuel hose for fuel pressure check, pull the hose
with a force of approximately 98 N (10 kg, 22 lb) to confirm fuel
tube does not come off.
7. Turn ignition switch ON and check for fuel leakage.
8. Start engine and check for fuel leakage.
9. Read the indication of fuel pressure gauge. CAUTION:
• Do not perform fuel pressure check with system operat-ing. Fuel pressure gauge may indicate false readings.
• During fuel pressure check, confirm for fuel leakage from fuel connection every 3 minutes.
Is the inspection result normal?
YES >> INSPECTION END
NO >> GO TO 2.
2.CHECK FUEL HOSE AND FUEL TUBE
If result is unsatisfactory, check fuel hoses and fuel tubes for clogging.
Is the inspection result normal?
YES >> Replace “fuel filter and fuel pump assembly”. Refer to FL-6, "Exploded View".
NO >> Repair or replace. 5 : No.2 spool
Tightening torque : 1 - 1.5 N·m
(0.1 - 0.15 kg-m, 9 - 13 in-lb)
A : Fuel pressure gauge
At idling : Approximately 350 kPa (3.57 kg/cm
2, 51 psi)
PBIB2983E
ALBIA1073ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

EC-154
< DTC/CIRCUIT DIAGNOSIS >[HR16DE]
TROUBLE DIAGNOSIS - SPECIFICATION VALUE
NOTE:
Check “A/F ALPHA-B1” for approximately 1 minute because
it may fluctuate. It is NG if the indication is
out of the SP value even a little.
Is the measurement value within the SP value?
YES >> GO TO 17.
NO-1 >> Less than the SP value: GO TO 2.
NO-2 >> More than the SP value: GO TO 3.
2.CHECK “B/FUEL SCHDL”
Select “B/FUEL SCHDL” in “SPEC” of “DATA MONITOR” mode, and make sure that the indication is within the
SP value.
Is the measurement value within the SP value?
YES >> GO TO 4.
NO >> More than the SP value: GO TO 19.
3.CHECK “B/FUEL SCHDL”
Select “B/FUEL SCHDL” in “SPEC” of “DATA MONITOR” mode, and make sure that the indication is within the
SP value.
Is the measurement value within the SP value?
YES >> GO TO 6.
NO-1 >> More than the SP value: GO TO 6.
NO-2 >> Less than the SP value: GO TO 25.
4.CHECK “A/F ALPHA-B1”
1. Stop the engine.
2. Disconnect PCV hose, and then plug it.
3. Start engine.
4. Select “A/F ALPHA-B1” in “SPEC” of “DATA MONITO R” mode, and make sure that the indication is within
the SP value.
Is the measurement value within the SP value?
YES >> GO TO 5.
NO >> GO TO 6.
5.CHANGE ENGINE OIL
1. Stop the engine.
2. Change engine oil. NOTE:
This symptom may occur when a large amount of gasoline is mixed with engine oil because of driving
conditions (such as when engine oil temperature does not rise enough since a journey distance is too
short during winter). The symptom will not be detected after changing engine oil or changing driving con-
dition.
>>INSPECTION END
6.CHECK FUEL PRESSURE
Check fuel pressure. (Refer to EC-137, "
Work Procedure".)
Is the inspection result normal?
YES >> GO TO 9.
NO-1 >> Fuel pressure is too high: Replace f uel filter and fuel pump assembly (Refer to FL-6, "
Exploded
View"), and then GO TO 8.
NO-2 >> Fuel pressure is too low: GO TO 7.
7.DETECT MALFUNCTIONING PART
Check fuel hoses and fuel tubes for clogging
Is the inspection result normal?
YES >> Replace fuel filter and fuel pump assembly (Refer to FL-6, "Exploded View"), and then GO TO 8.
NO >> Repair or replace and then GO TO 8.
Revision: August 2015 2016 Versa Note

cardiagn.com
