AV
INSPECTION AND ADJUSTMENTAV-93
< BASIC INSPECTION > [DISPLAY AUDIO]
C
D
E
F
G H
I
J
K L
M B A
O P
INSPECTION AND ADJUSTMENT
REGISTRATION (AUDIO UNIT)
REGISTRATION (AUDIO UNIT) : DescriptionINFOID:0000000012432965
AFTER REPLACEMENT
If the audio unit is replaced with a new audio unit, the new audio unit must be registered using the Bluetooth D/
C(serial #).
CAUTION:
If the new audio unit Bluetooth D/C(serial #) is not registered, the “APPS” mode will not function.
REGISTRATION (AUDIO UN IT) : Work ProcedureINFOID:0000000012432966
1.RECORD BLUETOOTH D/C(SERIAL #) FOR REPLACEMENT AUDIO UNIT
1. Turn ignition switch ON.
2. Turn audio unit OFF.
3. Access the diagnostic menu as follows:
- Press and hold preset buttons 2 and 3.
- While holding preset buttons 2 and 3, press preset button 5 three times.
4. Select Version Information from the Diagnostic Menu.
AWNIA3612ZZ
AWNIA3613ZZ
ALNIA1652ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

DIAGNOSIS SYSTEM [ABS ACTUATOR AND ELECTRIC UNIT (CONTROL
UNIT)]
BRC-31
< SYSTEM DESCRIPTION > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
DIAGNOSIS SYSTEM [ABS ACTUATOR AND ELECTRIC UNIT (CONTROL
UNIT)]
CONSULT Function (ABS)INFOID:0000000012430842
APPLICATION ITEMS
CONSULT can display each diagnostic item us ing the following direct diagnostic modes.
ECU IDENTIFICATION
ABS actuator and electric unit (control unit) part number is displayed.
SELF DIAGNOSTIC RESULT
Operation Procedure
1. Before performing the “Self Diagnostic Result”, st art engine and drive vehicle at 30 km/h (19 MPH) or
more for approximately 1 minute.
How To Erase Self Diagnostic Result
1. After erasing DTC memory, start engine and drive vehicle at 30 km/h (19 MPH) or more for approximately 1 minute as the final inspection, and make sure t hat the ABS warning lamp, VDC OFF indicator lamp,
SLIP indicator lamp and brake warning lamp turn OFF.
CAUTION:
If memory cannot be erased, perform applicable diagnosis.
NOTE:
• When the wheel sensor malfunctions, after inspecting the wheel sensor system, the ABS warning lamp,
SLIP indicator lamp and brake warning lamp will not turn OFF even when the system is normal, unless
the vehicle is driven at approximately 30 km/h (19 MPH) or more for approximately 1 minute.
• Brake warning lamp will turn ON in case of parking brake operation (when switch is ON) or of brake fluid
level switch operation (when brake fluid is insufficient).
• VDC OFF switch should not stay in ON position.
Display Item List
Refer to BRC-43, "DTC Index".
DATA MONITOR
Direct Diagnostic Mode Description
ECU Identification The ABS actuator and electric unit (control unit) part number is displayed.
Self Diagnostic Result The ABS actuator and electric unit (control unit) self diagnostic results are displayed.
Data Monitor The ABS actuator and electric unit (control unit) input/output data is displayed in real time.
Active Test The ABS actuator and electric unit (control unit) activates outputs to test components.
Work support The settings for ABS actuator and electric unit (control unit) functions can be changed.
CAN DIAG SUPPORT MNTR The result of transmit/receive diagnosis of CAN communication is displayed.
Item
(Unit) Data monitor item selection
Remarks
ECU INPUT
SIGNALS MAIN
SIGNALS SELECTION
FROM MENU
FR LH SENSOR
(km/h, mph) ×× × Wheel speed (km/h, mph) calculated by front wheel
sensor LH signal is displayed.
FR RH SENSOR
(km/h, mph) ×× × Wheel speed (km/h, mph) calculated by front wheel
sensor RH signal is displayed.
RR LH SENSOR
(km/h, mph) ×× ×
Wheel speed (km/h, mph) calculated by rear wheel
sensor LH signal is displayed.
RR RH SENSOR
(km/h, mph) ×× × Wheel speed (km/h, mph) calculated by rear wheel
sensor RH signal is displayed.
