DLK-88
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
BACK DOOR LOCK ACTUATOR RELAY
1. Turn ignition switch OFF.
2. Remove back door lock actuator relay.
3. Check continuity between back door
lock actuator relay terminals.
Is the inspection result normal?
YES >> Inspection End.
NO >> Replace back door lock actuator relay.
Back door lock actuator relay Condition Continuity
Te r m i n a l
3 4
12 V direct current supply between terminals 1 and 2
No
No current supply Yes
5 12 V direct current supply between terminals 1 and 2
Yes
No current supply No
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 778 of 3641
![NISSAN NOTE 2016 Service Repair Manual DOOR LOCK AND UNLOCK SWITCHDLK-89
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
DOOR LOCK AND UNLOCK SWITCH
Component Function CheckINFOID:0000000012430027
NISSAN NOTE 2016 Service Repair Manual DOOR LOCK AND UNLOCK SWITCHDLK-89
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
DOOR LOCK AND UNLOCK SWITCH
Component Function CheckINFOID:0000000012430027](/manual-img/5/57363/w960_57363-777.png)
DOOR LOCK AND UNLOCK SWITCHDLK-89
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
DOOR LOCK AND UNLOCK SWITCH
Component Function CheckINFOID:0000000012430027
1.CHECK FUNCTION
1. Select “DOOR LOCK” of “BCM” using CONSULT.
2. Select “CDL LOCK SW”, “CDL UNLOCK SW” in “Data Monitor”.
3. Check that the function operates normall y according to the following conditions:
Is the inspection result normal?
YES >> Main power window and door lock/unlock switch is OK.
NO >> Refer to DLK-89, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000012430028
Regarding Wiring Diagram information, refer to DLK-36, "Wiring Diagram".
1.CHECK DOOR LOCK AND UNLOCK SWITCH INPUT SIGNAL
1. Turn ignition switch OFF.
2. Disconnect main power window and door lock/unlock switch connector.
3. Check signal between main power window and door lock/unlock switch harness connector and ground
using oscilloscope.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.CHECK DOOR LOCK AND UNLOCK SWITCH CIRCUIT
1. Disconnect BCM connector.
2. Check continuity between BCM harness connecto r and main power window and door lock/unlock switch
harness connector.
Monitor item Condition Status
CDL LOCK SW Main power window and door
lock/unlock switch LOCK
ON
UNLOCK OFF
CDL UNLOCK SW LOCK
OFF
UNLOCK ON
(+)
(–)Signal
(Reference value)
Main power window and door lock/unlock switch
Connector Terminal
D7 6
Ground 1.0 - 1.5 V
D8
18
JPMIA0012GB
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 779 of 3641
![NISSAN NOTE 2016 Service Repair Manual DLK-90
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
DOOR LOCK AND UNLOCK SWITCH
3. Check continuity between
BCM harness connector and ground.
Is the inspection result normal?
YES >> Replace NISSAN NOTE 2016 Service Repair Manual DLK-90
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
DOOR LOCK AND UNLOCK SWITCH
3. Check continuity between
BCM harness connector and ground.
Is the inspection result normal?
YES >> Replace](/manual-img/5/57363/w960_57363-778.png)
DLK-90
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
DOOR LOCK AND UNLOCK SWITCH
3. Check continuity between
BCM harness connector and ground.
Is the inspection result normal?
YES >> Replace BCM. Refer to BCS-74, "Removal and Installation".
NO >> Repair or replace harness.
3.CHECK DOOR LOCK AND UNLOCK SWITCH GROUND
Check continuity between main power window and door lock/unlock switch harness connector and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace harness.
4.CHECK DOOR LOCK AND UNLOCK SWITCH
Refer to DLK-90, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Replace main power window and door lock/unlock switch. Refer to PWC-55, "
Removal and Instal-
lation".
5.CHECK INTERMITTENT INCIDENT
Refer to GI-42, "
Intermittent Incident".
>> Inspection End.
Component InspectionINFOID:0000000012430029
1.CHECK MAIN POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH
1. Turn ignition switch OFF.
2. Disconnect main power window and door lock/unlock switch connector.
3. Check continuity between main power window and door lock/unlock switch terminals.
Is the inspection result normal?
YES >> Inspection End
BCM Main power window and door lock/unlock switch
Continuity
Connector TerminalConnector Terminal
M97 12
D8 18
Ye s
13 D7 6
BCM GroundContinuity
Connector Terminal
M97 12
No
13
Main power window and door lock/unlock switch
GroundContinuity
Connector Terminal
D8 17 Yes
Main power window and door lock/unlock switch
Condition Continuity
Te r m i n a l
6 17Main power window
and door lock/ unlock
switch LOCK
No
UNLOCK Yes
18 LOCK
Yes
UNLOCK No
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 780 of 3641
DOOR LOCK AND UNLOCK SWITCHDLK-91
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
NO >> Replace main power window and door lock/unlock switch. Refer to PWC-55, "Removal and Instal-
lation".
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 781 of 3641
![NISSAN NOTE 2016 Service Repair Manual DLK-92
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
UNLOCK SENSOR
UNLOCK SENSOR
Component Function CheckINFOID:0000000012542550
1.CHECK FUNCTION
1. Select INTELLIGENT KEY of BCM using CONSUL NISSAN NOTE 2016 Service Repair Manual DLK-92
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
UNLOCK SENSOR
UNLOCK SENSOR
Component Function CheckINFOID:0000000012542550
1.CHECK FUNCTION
1. Select INTELLIGENT KEY of BCM using CONSUL](/manual-img/5/57363/w960_57363-780.png)
DLK-92
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
UNLOCK SENSOR
UNLOCK SENSOR
Component Function CheckINFOID:0000000012542550
1.CHECK FUNCTION
1. Select INTELLIGENT KEY of BCM using CONSULT.
2. Select UNLK SEN-DR in DATA MONITORmode.
3. Check that the function operates normall y according to the following conditions.
Is the inspection result normal?
YES >> Unlock sensor is OK.
NO >> Refer to DLK-92, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000012542551
Regarding Wiring Diagram information, refer to DLK-36, "Wiring Diagram".
1.CHECK UNLOCK SENSOR INPUT SIGNAL
1. Turn ignition switch OFF.
2. Disconnect front door lock assembly LH connector.
3. Check signal between front door lock assembly LH harness connector and ground with oscilloscope.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.CHECK UNLOCK SENSOR CIRCUIT
1. Disconnect BCM connector.
2. Check continuity between BCM harness connector and front door lock assembly LH harness connector.
3. Check continuity between BCM harness connector and ground.
Monitor item Condition Status
UNLK SEN -DR Driver side door Lock
OFF
Unlock ON
(+)
(–)Signal
(Reference value)
Front door lock assembly LH
Connector Terminal
D14 3Ground
JPMIA0011GB
BCM Front door lock assembly LH
Continuity
Connector TerminalConnector Terminal
M97 31D14 3Yes
BCM GroundContinuity
Connector Terminal
M97 31 No
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 782 of 3641
![NISSAN NOTE 2016 Service Repair Manual UNLOCK SENSORDLK-93
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
Is the inspection result normal?
YES >> Replace BCM. Refer to BCS-74, "Removal and Instal NISSAN NOTE 2016 Service Repair Manual UNLOCK SENSORDLK-93
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
Is the inspection result normal?
YES >> Replace BCM. Refer to BCS-74, "Removal and Instal](/manual-img/5/57363/w960_57363-781.png)
UNLOCK SENSORDLK-93
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
Is the inspection result normal?
YES >> Replace BCM. Refer to BCS-74, "Removal and Installation".
NO >> Repair or replace harness.
3.CHECK UNLOCK SENSOR GROUND CIRCUIT
Check continuity between front door lo ck assembly LH harness connector and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace harness.
4.CHECK UNLOCK SENSOR
Refer to DLK-93, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Replace front door lock assembly LH. Refer to DLK-168, "
DOOR LOCK : Removal and Installa-
tion".
5.CHECK INTERMITTENT INCIDENT
Refer to GI-42, "
Intermittent Incident".
>> Inspection End.
Component InspectionINFOID:0000000012542552
1.CHECK UNLOCK SENSOR
1. Turn ignition switch OFF.
2. Disconnect front door lock assembly LH connector.
3. Check continuity between front door lock assembly LH terminals.
Is the inspection result normal?
YES >> Inspection End.
NO >> Replace front door lock assembly LH. Refer to DLK-168, "
DOOR LOCK : Removal and Installa-
tion".
Front door lock assembly LH
GroundContinuity
Connector Terminal
D14 4 Yes
Front door lock assembly LH
Condition Continuity
Te r m i n a l
3 4Driver side door Unlock
Yes
Lock No
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 783 of 3641
![NISSAN NOTE 2016 Service Repair Manual DLK-94
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
DOOR REQUEST SWITCH
DOOR REQUEST SWITCH
Component Function CheckINFOID:0000000012430030
1.CHECK FUNCTION
1. Select “INTELLIGENT KEY” NISSAN NOTE 2016 Service Repair Manual DLK-94
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
DOOR REQUEST SWITCH
DOOR REQUEST SWITCH
Component Function CheckINFOID:0000000012430030
1.CHECK FUNCTION
1. Select “INTELLIGENT KEY”](/manual-img/5/57363/w960_57363-782.png)
DLK-94
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
DOOR REQUEST SWITCH
DOOR REQUEST SWITCH
Component Function CheckINFOID:0000000012430030
1.CHECK FUNCTION
1. Select “INTELLIGENT KEY” of “BCM” using CONSULT.
2. Select “REQ SW-DR”, “REQ SW-AS” in “Data Monitor”.
3. Check that the function operates normall y according to the following conditions:
Is the inspection result normal?
YES >> Front door request switch is OK.
NO >> Refer to DLK-94, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000012430031
Regarding Wiring Diagram information, refer to DLK-46, "Wiring Diagram".
1.CHECK DOOR REQUEST SWITCH INPUT SIGNAL
1. Turn ignition switch OFF.
2. Disconnect malfunctioning front door request switch connector.
3. Check voltage between malfunctioning front door request switch harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.CHECK DOOR REQUEST SWITCH CIRCUIT
1. Disconnect BCM connector.
2. Check continuity between malfunctioning front door request switch harness connector and BCM harness
connector.
3. Check continuity between malfunctioning front door request switch harness connector and ground.
Monitor item Condition Status
REQ SW -DR Door request switch LH Pressed
ON
Released OFF
REQ SW -AS Door request switch RH Pressed
ON
Released OFF
(+)
(–)Vo l ta g e
(Approx.)
Front door request switch
Connector Terminal
Left side D17
3Ground Battery voltage
Right side D113
Front door request switch BCM
Continuity
Connector TerminalConnector Terminal
Left side D17
3M98 75
Ye s
Right side D113 100
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 784 of 3641
![NISSAN NOTE 2016 Service Repair Manual DOOR REQUEST SWITCHDLK-95
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
Is the inspection result normal?
YES >> Replace BCM. Refer to BCS-74, "Removal and NISSAN NOTE 2016 Service Repair Manual DOOR REQUEST SWITCHDLK-95
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
Is the inspection result normal?
YES >> Replace BCM. Refer to BCS-74, "Removal and](/manual-img/5/57363/w960_57363-783.png)
DOOR REQUEST SWITCHDLK-95
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
Is the inspection result normal?
YES >> Replace BCM. Refer to BCS-74, "Removal and Installation".
NO >> Repair or replace harness.
3.CHECK DOOR REQUEST SWITCH GROUND CIRCUIT
Check continuity between malfunctioning front door request switch harness connector and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace harness.
4.CHECK DOOR REQUEST SWITCH
Refer to DLK-95, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Replace malfunctioning front door request switch.
5.CHECK INTERMITTENT INCIDENT
Refer to GI-42, "
Intermittent Incident".
>> Inspection End.
Component InspectionINFOID:0000000012430032
1.CHECK DOOR REQUEST SWITCH
1. Turn ignition switch OFF.
2. Disconnect malfunctioning front door request switch connector.
3. Check continuity between malfunctioning front door request switch terminals.
Is the inspection result normal?
YES >> Inspection End.
NO >> Replace malfunctioning front door request switch. Refer to DLK-185, "
DRIVER SIDE : Removal
and Installation" (driver side) or DLK-185, "PASSENGER SIDE : Removal and Installation" (pas-
senger side).
Front door request switch
GroundContinuity
Connector Terminal
Left side D17
3N o
Right side D113
Front door request switch
GroundContinuity
Connector Terminal
Left side D17
4Y es
Right side D113
Front door request switch
Condition Continuity
Te r m i n a l
3 4Door request switch Pressed
Yes
Released No
Revision: August 2015 2016 Versa Note
cardiagn.com
