Page 3569 of 3641

NISSAN NOTE 2016 Service Repair Manual WW-4 < PRECAUTION > PRECAUTIONS • Dip a soft cloth into lukewarm water with mild detergent (concentration: within 2 to 3%) and wipe the dirtyarea. • Then dip a cloth into fresh water, wring the wa

Page 3570 of 3641

NISSAN NOTE 2016 Service Repair Manual PREPARATIONWW-5 < PREPARATION > C DE F G H I J K M A B WW N O P PREPARATION PREPARATION Special Service ToolsINFOID:0000000012433195 The actual shape of the tools may differ from those illustrated her

Page 3571 of 3641

NISSAN NOTE 2016 Service Repair Manual WW-6 < SYSTEM DESCRIPTION > COMPONENT PARTS SYSTEM DESCRIPTION COMPONENT PARTS Component Parts LocationINFOID:0000000012433197 Description A. Right front engine compartment area B. Cowl areaC. Steerin

Page 3572 of 3641

NISSAN NOTE 2016 Service Repair Manual COMPONENT PARTSWW-7 < SYSTEM DESCRIPTION > C DE F G H I J K M A B WW N O P 3. Washer fluid level switch (for Canada) Transmits the washer fluid level switch signal to the combination meter. 4. Front

Page 3573 of 3641

NISSAN NOTE 2016 Service Repair Manual WW-8 < SYSTEM DESCRIPTION > SYSTEM SYSTEM FRONT WIPER AND WASHER SYSTEM FRONT WIPER AND WASHER SYSTEM : System DiagramINFOID:0000000012433198 FRONT WIPER AND WASHER SYSTEM : System DescriptionINFOID:0

Page 3574 of 3641

NISSAN NOTE 2016 Service Repair Manual SYSTEMWW-9 < SYSTEM DESCRIPTION > C DE F G H I J K M A B WW N O P AUTO STOP OPERATION 1. Front wiper switch is turned OFF. 2. BCM monitors wiper switch position by combination switch reading position

Page 3575 of 3641

NISSAN NOTE 2016 Service Repair Manual WW-10 < SYSTEM DESCRIPTION > SYSTEM 2. Front washer switch ON. 3. The front washer switch provides ground for the front and rear washer motor. 4. BCM reads the combination switch position and transmi

Page 3576 of 3641

NISSAN NOTE 2016 Service Repair Manual SYSTEMWW-11 < SYSTEM DESCRIPTION > C DE F G H I J K M A B WW N O P - Ignition switch ON - Rear wiper switch INT • BCM controls the rear wiper to operate once. • BCM detects the rear wiper motor st
