Page 361 of 3641

NISSAN NOTE 2016 Service Repair Manual BCS-100 < SYSTEM DESCRIPTION >[WITHOUT INTELLIGENT KEY SYSTEM] DIAGNOSIS SYSTEM (BCM) PANIC ALARM : CONSULT Func tion (BCM - PANIC ALARM) INFOID:0000000012432388 ACTIVE TEST Test Item Description VEHI

Page 362 of 3641

NISSAN NOTE 2016 Service Repair Manual BCS BCM BCS-101 < ECU DIAGNOSIS INFORMATION > [WITHOUT INTELLIGENT KEY SYSTEM] C D E F G H I J K L B A O P N ECU DIAGNOSIS INFORMATION BCM Reference ValueINFOID:0000000012432389 NOTE: The Signal Tech

Page 363 of 3641

NISSAN NOTE 2016 Service Repair Manual BCS-102 < ECU DIAGNOSIS INFORMATION >[WITHOUT INTELLIGENT KEY SYSTEM] BCM FAN O N SIGBlower fan OFF Off Blower fan ON On FR FOG SW Front fog lamp switch OFF Off Front fog lamp switch ON On FR WASHER

Page 364 of 3641

NISSAN NOTE 2016 Service Repair Manual BCS BCM BCS-103 < ECU DIAGNOSIS INFORMATION > [WITHOUT INTELLIGENT KEY SYSTEM] C D E F G H I J K L B A O P N KEYLESS PANIC PANIC button of keyfob not pressed Off PANIC button of keyfob pressed On KEYL

Page 365 of 3641

NISSAN NOTE 2016 Service Repair Manual BCS-104 < ECU DIAGNOSIS INFORMATION >[WITHOUT INTELLIGENT KEY SYSTEM] BCM TERMINAL LAYOUT PHYSICAL VALUES ALMIA0502ZZ Te r m i n a l N o . (Wire color) Description Condition Va l u e (Approx.) Signal

Page 366 of 3641

NISSAN NOTE 2016 Service Repair Manual BCS BCM BCS-105 < ECU DIAGNOSIS INFORMATION > [WITHOUT INTELLIGENT KEY SYSTEM] C D E F G H I J K L B A O P N31 (Y) Ground Input 4 signal Input Combination switchOFF 0 V TURN LH 1.0 V PASSING HEADLAMP

Page 367 of 3641

NISSAN NOTE 2016 Service Repair Manual BCS-106 < ECU DIAGNOSIS INFORMATION >[WITHOUT INTELLIGENT KEY SYSTEM] BCM 52 (G)Ground Input 2 signal Input Combination switchOFF 0 V FR WASHER 1.0 V RR WASHER RR WIPER ON 6 1 (R) Ground Input 1 sign

Page 368 of 3641

NISSAN NOTE 2016 Service Repair Manual BCS BCM BCS-107 < ECU DIAGNOSIS INFORMATION > [WITHOUT INTELLIGENT KEY SYSTEM] C D E F G H I J K L B A O P N 10 (G) Ground Rear defogger sw signal Input Rear window defogger switch OFF Battery volta
