CONTENTS
AUDIO, VISUAL & NAVIGATION SYSTEM
BASE AUDIO
PRECAUTION ....... ........................................
6
PRECAUTIONS .............................................. .....6
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ............................................................. ......
6
Precaution for Work ..................................................6
PREPARATION ............................................7
PREPARATION .............................................. .....7
Special Service Tools .......................................... ......7
Commercial Service Tools ........................................7
SYSTEM DESCRIPTION ..............................8
COMPONENT PARTS ................................... .....8
Component Parts Location .................................. ......8
Audio unit ..................................................................8
Speaker .....................................................................9
Bluetooth® Control Unit ............................................9
Bluetooth® Antenna ................................................10
Steering Wheel Audio Control Switches .................10
Microphone .............................................................10
Rod Antenna, Antenna Amp. and Antenna Feeder
....
10
SYSTEM .............................................................12
System Description ............................................. ....12
DIAGNOSIS SYSTEM (AUDIO UNIT) ................14
Diagnosis Description ......................................... ....14
On Board Diagnosis Function .................................14
DIAGNOSIS SYSTEM (BLUETOOTH® CON-
TROL UNIT) ........................................................
17
Diagnosis Description .............................................17
Work Flow ...............................................................17
ECU DIAGNOSIS INFORMATION ..............18
AUDIO UNIT ......................................................18
Reference Value .................................................. ....18
BLUETOOTH® CONTROL UNIT ......................21
Reference Value ......................................................21
WIRING DIAGRAM ......................................24
BASE AUDIO ....................................................24
Wiring Diagram .................................................... ....24
BASIC INSPECTION ...................................33
DIAGNOSIS AND REPAIR WORKFLOW ........33
Work Flow ............................................................ ....33
DTC/CIRCUIT DIAGNOSIS .........................35
POWER SUPPLY AND GROUND CIRCUIT ....35
AUDIO UNIT ........................................................... ....35
AUDIO UNIT : Diagnosis Procedure .......................35
BLUETOOTH® CONTROL UNIT .......................... ....35
BLUETOOTH® CONTROL UNIT : Diagnosis Pro-
cedure ......................................................................
35
FRONT DOOR SPEAKER ................................37
Diagnosis Procedure ...............................................37
REAR DOOR SPEAKER ..................................39
Diagnosis Procedure ...............................................39
BLUETOOTH® VOICE SIGNAL CIRCUIT .......41
Diagnosis Procedure ...............................................41
BLUETOOTH® CONTROL SIGNAL CIRCUIT ...43
Diagnosis Procedure ........................................... ....43
MICROPHONE SIGNAL CIRCUIT ....................44
Diagnosis Procedure ...............................................44
STEERING SWITCH .........................................46
Diagnosis Procedure ...............................................46
Revision: August 2015 2016 Versa Note

cardiagn.com

AV-2
SYMPTOM DIAGNOSIS .............................48
AUDIO SYSTEM ............................................. ...48
Symptom Table ................................................... ...48
NORMAL OPERATING CONDITION ................51
Description ........................................................... ...51
REMOVAL AND INSTALLATION ...............53
AUDIO UNIT ................................................... ...53
Exploded View ..................................................... ...53
Removal and Installation ........................................53
FRONT DOOR SPEAKER .............................. ...54
Removal and Installation ..................................... ...54
REAR DOOR SPEAKER ................................ ...55
Removal and Installation ..................................... ...55
BLUETOOTH® CONTROL UNIT ......................56
Removal and Installation ........................................56
BLUETOOTH® ANTENNA ................................57
Removal and Installation ..................................... ...57
STEERING SWITCH ..........................................58
Removal and Installation ..................................... ...58
MICROPHONE ...................................................59
Removal and Installation ..................................... ...59
ROD ANTENNA .................................................60
Exploded View ..................................................... ...60
Removal and Installation ........................................60
ANTENNA FEEDER ....................................... ...61
Feeder Layout ..................................................... ...61
DISPLAY AUDIO
PRECAUTION .............. ...............................
62
PRECAUTIONS .............................................. ...62
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" .............................................................. ...
62
Precaution for Trouble Diagnosis ...........................62
Precaution for Harness Repair ...............................62
Precaution for Work ................................................63
PREPARATION ...........................................64
PREPARATION .............................................. ...64
Special Service Tools .......................................... ...64
Commercial Service Tools ......................................64
SYSTEM DESCRIPTION ............................65
COMPONENT PARTS .................................... ...65
Component Parts Location .................................. ...65
Audio Unit ...............................................................65
Speaker ..................................................................66
USB Interface and AUX In Jack .............................66
Steering Wheel Audio Control Switches .............. ...67
Microphone .............................................................67
Rear View Camera ..................................................67
Rod Antenna, Antenna Amp., Satellite Antenna
and Antenna Feeder ...............................................
67
SYSTEM ............................................................69
System Description .............................................. ...69
DIAGNOSIS SYSTEM (AUDIO UNIT) ...............71
Description ........................................................... ...71
On Board Diagnosis Function .................................71
ECU DIAGNOSIS INFORMATION .............76
AUDIO UNIT ......................................................76
Reference Value .................................................. ...76
WIRING DIAGRAM ....................................80
DISPLAY AUDIO ............................................ ...80
Wiring Diagram .................................................... ...80
BASIC INSPECTION ..................................91
DIAGNOSIS AND REPAIR WORKFLOW ...... ...91
Work Flow ............................................................ ...91
INSPECTION AND ADJUSTMENT ...................93
REGISTRATION (AUDIO UNIT) ............................ ...93
REGISTRATION (AUDIO UNIT) : Description ........93
REGISTRATION (AUDIO UNIT) : Work Proce-
dure .........................................................................
93
DTC/CIRCUIT DIAGNOSIS ........................95
POWER SUPPLY AND GROUND CIRCUIT .. ...95
AUDIO UNIT ........................................................... ...95
AUDIO UNIT : Diagnosis Procedure .......................95
FRONT DOOR SPEAKER .................................96
Diagnosis Procedure ............................................ ...96
REAR DOOR SPEAKER ...................................98
Diagnosis Procedure ............................................ ...98
REAR VIEW CAMERA IMAGE SIGNAL CIR-
CUIT ..................................................................
100
Diagnosis Procedure ............................................ .100
MICROPHONE SIGNAL CIRCUIT ...................102
Diagnosis Procedure ............................................ .102
STEERING SWITCH .........................................104
Diagnosis Procedure ............................................ .104
USB CONNECTOR ..........................................106
Diagnosis Procedure ............................................ .106
AUXILIARY INPUT JACK ................................107
Diagnosis Procedure ............................................ .107
Revision: August 2015 2016 Versa Note

cardiagn.com

AV
AV-3
C
DE
F
G H
I
J
K L
M B
A
O P
SYMPTOM DIAGNOSIS ..... .......................108
AUDIO SYSTEM ............................................. ..108
Symptom Table ................................................... ..108
NORMAL OPERATING CONDITION ...............111
Description .......................................................... ..111
REMOVAL AND INSTALLATION .............113
AUDIO UNIT ................................................... ..113
Exploded View .................................................... ..113
Removal and Installation .......................................113
FRONT DOOR SPEAKER ............................. ..114
Removal and Installation .......................................114
REAR DOOR SPEAKER ................................ ..115
Removal and Installation .......................................115
USB INTERFACE ........................................... ..116
Removal and Installation .......................................116
AUXILIARY INPUT JACK .............................. ..117
Removal and Installation .......................................117
REAR VIEW CAMERA ................................... ..118
Removal and Installation .......................................118
BLUETOOTH® CONTROL UNIT ................... ..119
Removal and Installation .......................................119
BLUETOOTH® ANTENNA ............................ ..120
Removal and Installation .......................................120
STEERING SWITCH ...................................... ..121
Removal and Installation .......................................121
MICROPHONE ............................................... ..122
Removal and Installation .......................................122
ROD ANTENNA ............................................. ..123
Exploded View .................................................... ..123
Removal and Installation .......................................123
ANTENNA FEEDER ....................................... ..124
Feeder Layout ..................................................... ..124
SATELLITE RADIO ANTENNA .......................125
Removal and Installation .......................................125
NAVIGATION
PRECAUTION ....... .....................................
126
PRECAUTIONS .............................................. ..126
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ............................................................. ..
126
Cautions in Removing Battery Terminal and AV
Control Unit (Models with AV Control Unit) ...........
126
Precaution for Trouble Diagnosis ..........................126
Precaution for Harness Repair ..............................126
Precaution for Work ............................................ ..127
PREPARATION .........................................128
PREPARATION ...............................................128
Special Service Tools .......................................... ..128
Commercial Service Tools .....................................128
SYSTEM DESCRIPTION ...........................129
COMPONENT PARTS ....................................129
Component Parts Location .................................. ..129
AV Control Unit ......................................................130
Speakers ...............................................................130
USB Interface and AUX In Jack ............................131
Steering Wheel Audio Control Switches ................131
Microphone ............................................................131
Around View Monitor Control Unit .........................131
Rear View Camera ................................................132
Side Cameras ........................................................132
Front Camera ........................................................132
Steering Angle Sensor ...........................................132
Rod Antenna, Antenna Amp., Satellite Antenna
and Antenna Feeder ..............................................
132
GPS Antenna .........................................................134
SD Card .................................................................134
SYSTEM ..........................................................135
System Description .............................................. ..135
DIAGNOSIS SYSTEM (AV CONTROL UNIT) .143
Description .............................................................143
On Board Diagnosis Function ................................143
CONSULT Function ...............................................144
DIAGNOSIS SYSTEM (AROUND VIEW MON-
ITOR CONTROL UNIT) ...................................
146
CONSULT Function ...............................................146
ECU DIAGNOSIS INFORMATION ............148
AV CONTROL UNIT ........................................148
Reference Value .................................................. ..148
DTC Index .............................................................151
AROUND VIEW MONITOR CONTROL UNIT .152
Reference Value ....................................................152
DTC Index .............................................................154
WIRING DIAGRAM ....................................155
NAVIGATION SYSTEM ..................................155
Wiring Diagram .................................................... ..155
BASIC INSPECTION .................................171
DIAGNOSIS AND REPAIR WORKFLOW ......171
Work Flow ............................................................ ..171
INSPECTION AND ADJUSTMENT ................173
ADDITIONAL SERVICE WHEN REPLACING AV
CONTROL UNIT .................................................... ..
173
Revision: August 2015 2016 Versa Note

cardiagn.com

AV-8
< SYSTEM DESCRIPTION >[BASE AUDIO]
COMPONENT PARTS
SYSTEM DESCRIPTION
COMPONENT PARTS
Component Parts LocationINFOID:0000000012432862
Audio unitINFOID:0000000012432863
DESCRIPTION
A. Luggage side lower finisher (RH) re-
moved B. Front of headliner
AWNIA3646ZZ
No.
Component Function
1. Rod antenna Refer to AV- 1 0 , "
Rod Antenna, Antenna Amp. and Antenna Feeder".
2. Antenna base (antenna amp.)
3. Rear door speaker RH
Refer to AV- 9 , "
Sp ea ke r".
4. Front door speaker RH
5. Front door speaker LH
6. Rear door speaker LH
7. Steering wheel audio control switches Refer to
AV- 1 0 , "
Steering Wheel Audio Control Switches".
8. Audio unit Refer to AV- 8 , "
Audio unit".
9. Bluetooth
® control unit Refer to AV- 9 , "Bluetooth® Control Unit".
10. Bluetooth
® antenna Refer to AV- 1 0 , "Bluetooth® Antenna".
11. Microphone Refer to AV- 1 0 , "
Microphone".
Revision: August 2015 2016 Versa Note

cardiagn.com

AV
COMPONENT PARTSAV-9
< SYSTEM DESCRIPTION > [BASE AUDIO]
C
D
E
F
G H
I
J
K L
M B A
O P
• AM/FM electronic tuner radio, CD player, and auxiliary input jack are integrated into the audio unit.
• The audio unit supports CD-R/CD-RW and provides the playback
of MP3/WMA music files.
SpeakerINFOID:0000000012432864
FRONT DOOR SPEAKER
• 16.5 cm (6.5 in) speakers are instal led in the bottom of the front doors.
• Sound signals are input from the audio unit to output high, mid and low range sounds.
REAR DOOR SPEAKER
• 16.5 cm (6.5 in) speakers are installed in the bottom of the rear doors.
• Sound signals are input from the audio unit to output high, mid and
low range sounds.
Bluetooth® Control UnitINFOID:0000000012432865
• Inputs the TEL voice signal from Bluetooth® antenna and outputs it
to the audio unit
• Connected to the audio unit via AV communication.
JSNIA5416ZZ
JPNIA1454ZZ
JPNIA1454ZZ
JSNIA4236ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

AV-10
< SYSTEM DESCRIPTION >[BASE AUDIO]
COMPONENT PARTS
Bluetooth® Antenna
INFOID:0000000012432866
Receives the TEL voice signal from cellular phone and outputs it to
the Bluetooth
® control unit.
Steering Wheel Audio Control SwitchesINFOID:0000000012432867
• Operations for audio and hands-free phone are possible.
• Switch is connected to the Bluetooth
® control unit.
MicrophoneINFOID:0000000012432868
• The microphone is installed in the roof in front of the map lamp assembly.
• Power is supplied from the Bluetooth
® control unit.
Rod Antenna, Antenna Amp. and Antenna FeederINFOID:0000000012432869
RADIO ANTENNA
AM/FM radio rod antenna and antenna base is located on the rear of the roof. The antenna amp. is built into
the antenna base.
ANTENNA FEEDER LAYOUT
JSNIA4237ZZ
AWNIA4137ZZ
JPNIA1448ZZ
AWNIA3059GB
Revision: August 2015 2016 Versa Note

cardiagn.com

AV-12
< SYSTEM DESCRIPTION >[BASE AUDIO]
SYSTEM
SYSTEM
System DescriptionINFOID:0000000012432870
SYSTEM DIAGRAM
AUDIO SYSTEM
The audio system consists of the following components
• Audio unit
• Front door speakers
• Rear door speakers
• Steering wheel audio control switches
• Antenna base (antenna amp.)
• Rod antenna
When the audio system is on, AM/FM signals received
by the rod antenna are amplified by the antenna amp.
and sent to the audio unit. The audio unit then sends audio signals to the front door speakers and rear door
speakers.
Refer to Owner's Manual for audio system operating instructions.
HANDS-FREE PHONE SYSTEM
System Operation
NOTE:
Cellular telephones must have their wireless connec tion set up (paired) before using the Bluetooth
® telephone
system.
The Bluetooth
® telephone system allows users who have a Bluetooth® cellular telephone to make a wireless
connection between their cellular telephone and the Bluetooth
® control unit. Hands-free cellular telephone
calls can be sent and received. Some Bluetooth
® cellular telephones may not be recognized by the Bluetooth®
control unit. When a cellular telephone or the Bluetooth® control unit is replaced, the telephone must be paired
with the Bluetooth
® control unit. Different cellular telephones may have different pairing procedures, refer to
the cellular telephone operating manual.
Refer to the Owner's Manual for Bluetooth
® telephone system operating instructions.
Bluetooth® Control Unit
When the ignition switch is turned to ACC or ON, the Bluetooth® control unit will power up. During power up,
the Bluetooth
® control unit is initialized and performs various self-checks. Initialization may take up to 20 sec-
onds.
Steering Wheel Audio Control Switches
When buttons on the steering wheel audio control switches are pushed, the resistance in steering wheel audio
control switch circuit changes, depending on which button is pushed.
The following functions can be performed using the steering wheel audio control switches:
• Initiate self-diagnosis of the Bluetooth
® telephone system
• Answer and end telephone calls
AWNIA4134GB
Revision: August 2015 2016 Versa Note

cardiagn.com

AV
SYSTEMAV-13
< SYSTEM DESCRIPTION > [BASE AUDIO]
C
D
E
F
G H
I
J
K L
M B A
O P
• Adjust the volume of calls
Microphone
The microphone is located in the roof console asse mbly. The microphone sends a signal to the Bluetooth®
control unit. The microphone can be actively tested during self-diagnosis.
Audio Unit
The audio unit receives signals from the Bluetooth® control unit and sends audio signals to the speakers.
SPEED SENSITIVE VOLUME SYSTEM
Volume level of this system goes up and down automatica lly in proportion to the vehicle speed. The control
level can be selected by the customer. Refer to Owner's Manual for operating instructions.
