Page 929 of 3641
![NISSAN NOTE 2016 Service Repair Manual DLK-240
< DTC/CIRCUIT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
KEY CYLINDER SWITCH
NO >> Repair or replace harness.
3.CHECK DOOR KEY CYLINDER SIGNAL CIRCUIT
1. Disconnect BCM connector M18.
2. Chec NISSAN NOTE 2016 Service Repair Manual DLK-240
< DTC/CIRCUIT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
KEY CYLINDER SWITCH
NO >> Repair or replace harness.
3.CHECK DOOR KEY CYLINDER SIGNAL CIRCUIT
1. Disconnect BCM connector M18.
2. Chec](/manual-img/5/57363/w960_57363-928.png)
DLK-240
< DTC/CIRCUIT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
KEY CYLINDER SWITCH
NO >> Repair or replace harness.
3.CHECK DOOR KEY CYLINDER SIGNAL CIRCUIT
1. Disconnect BCM connector M18.
2. Check continuity between front door lock key cylinder switch LH connector and BCM connector M18.
3. Check continuity between front door lock key cylinder switch LH connector and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace harness.
4.CHECK DOOR KEY CYLINDER SWITCH
Check door key cylinder switch.
Refer to DLK-240, "
Component Inspection".
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-42, "Intermittent Incident".
NO >> Replace front door lock key cylinder switch LH. Refer to DLK-295, "
DOOR LOCK : Removal and
Installation".
Component InspectionINFOID:0000000012430195
COMPONENT INSPECTION
1.CHECK DOOR KEY CYLINDER SWITCH
Check front door lock key cylinder switch LH.
Is the inspection result normal?
YES >> Key cylinder switch is OK.
NO >> Replace front door lock key cylinder switch LH. Refer to DLK-295, "
DOOR LOCK : Removal and
Installation".
Front door lock key cylinder switch LH con-
nector Terminal
BCM connector Terminal Continuity
D14 6
M18 8
Ye s
57
Front door lock key cylinder switch LH connector Te r m i n a l
GroundContinuity
D14 6
No
5
Te r m i n a l Key position Continuity
Front door lock key cylinder switch LH connector
6 4 Lock
Yes
Neutral / Unlock No
5 Unlock
Yes
Neutral / Lock No
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 930 of 3641
![NISSAN NOTE 2016 Service Repair Manual KEY SWITCH (BCM INPUT)DLK-241
< DTC/CIRCUIT DIAGNOSIS > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
KEY SWITCH (BCM INPUT)
Diagnosis ProcedureINFOID:0000000012430196
Regarding W NISSAN NOTE 2016 Service Repair Manual KEY SWITCH (BCM INPUT)DLK-241
< DTC/CIRCUIT DIAGNOSIS > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
KEY SWITCH (BCM INPUT)
Diagnosis ProcedureINFOID:0000000012430196
Regarding W](/manual-img/5/57363/w960_57363-929.png)
KEY SWITCH (BCM INPUT)DLK-241
< DTC/CIRCUIT DIAGNOSIS > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
KEY SWITCH (BCM INPUT)
Diagnosis ProcedureINFOID:0000000012430196
Regarding Wiring Diagram information, refer to DLK-206, "Wiring Diagram".
1.CHECK KEY SWITCH INPUT SIGNAL
With CONSULT
Check key switch “KEY ON SW” in “Data Monitor”. Refer to BCS-90, "
DOOR LOCK : CONSULT Function
(BCM - DOOR LOCK)".
• When key is inserted to ignition key cylinder:
• When key is removed from ignition key cylinder:
Without CONSULT
Check voltage between BCM connector M18 terminal 37 and ground.
Is the inspection result normal?
YES >> Key switch (insert) circuit is OK.
NO >> GO TO 2.
2.CHECK KEY SWITCH (INSERT)
1. Turn ignition switch OFF.
2. Disconnect key switch connector.
3. Check continuity between key switch terminals.
Is the inspection result normal?
YES >> Repair or replace harness or fuse.
NO >> Replace key switch. KEY ON SW : ON
KEY ON SW : OFF
Connector
Te r m i n a l
Condition Voltage (V)
(Approx.)
(+) (–)
M18 37Ground Key is inserted.
Battery voltage
Key is removed. 0
Terminals Condition Continuity
1 – 2 Key is inserted.
Yes
Key is removed. No
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 931 of 3641
![NISSAN NOTE 2016 Service Repair Manual DLK-242
< DTC/CIRCUIT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
DOOR LOCK ACTUATOR
DOOR LOCK ACTUATOR
DRIVER SIDE
DRIVER SIDE : DescriptionINFOID:0000000012430197
Locks/unlocks the door with the sig NISSAN NOTE 2016 Service Repair Manual DLK-242
< DTC/CIRCUIT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
DOOR LOCK ACTUATOR
DOOR LOCK ACTUATOR
DRIVER SIDE
DRIVER SIDE : DescriptionINFOID:0000000012430197
Locks/unlocks the door with the sig](/manual-img/5/57363/w960_57363-930.png)
DLK-242
< DTC/CIRCUIT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
DOOR LOCK ACTUATOR
DOOR LOCK ACTUATOR
DRIVER SIDE
DRIVER SIDE : DescriptionINFOID:0000000012430197
Locks/unlocks the door with the signal from BCM.
DRIVER SIDE : Component Function CheckINFOID:0000000012430198
1.CHECK FUNCTION
1. Perform “DOOR LOCK” in “Active Test” using CONSULT.
2. Touch “ALL LOCK” or “ALL UNLOCK” to check that it works normally.
Is the inspection result normal?
YES >> Door lock actuator is OK.
NO >> Refer to DLK-242, "
DRIVER SIDE : Diagnosis Procedure".
DRIVER SIDE : Diagnosis ProcedureINFOID:0000000012430199
Regarding Wiring Diagram information, refer to DLK-206, "Wiring Diagram".
1.CHECK DOOR LOCK ACTUATOR INPUT SIGNAL
1. Turn ignition switch OFF.
2. Disconnect front door lock actuator LH connector.
3. Check voltage between front door lock actuator LH harness connector and ground.
Is the inspection result normal?
YES >> Replace front door lock actuator LH. Refer to DLK-295, "DOOR LOCK : Removal and Installa-
tion".
NO >> GO TO 2.
2.CHECK DOOR LOCK ACTUATOR CIRCUIT
1. Disconnect BCM connector and all door lock actuator connectors.
2. Check continuity between BCM harness connector and front door lock actuator LH harness connector.
3. Check continuity between BCM harness connector and ground.
Is the inspection result normal?
(+) (–) Condition Vo l ta g e
(Approx.)
Front door lock actuator
LH
Connector Terminal
D14 1
Ground Door lock and unlock switch Lock
Battery voltage
2 Unlock
BCMFront door lock actuator LH
Continuity
Connector TerminalConnector Terminal
M19 54
D14 1
Ye s
41 2
BCM GroundContinuity
Connector Terminal
M19 54
No
41
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 932 of 3641
![NISSAN NOTE 2016 Service Repair Manual DOOR LOCK ACTUATORDLK-243
< DTC/CIRCUIT DIAGNOSIS > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
YES >> GO TO 3.
NO >> Repair or replace harness.
3.CHECK BCM OUTPUT SIGNAL
1. Con NISSAN NOTE 2016 Service Repair Manual DOOR LOCK ACTUATORDLK-243
< DTC/CIRCUIT DIAGNOSIS > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
YES >> GO TO 3.
NO >> Repair or replace harness.
3.CHECK BCM OUTPUT SIGNAL
1. Con](/manual-img/5/57363/w960_57363-931.png)
DOOR LOCK ACTUATORDLK-243
< DTC/CIRCUIT DIAGNOSIS > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
YES >> GO TO 3.
NO >> Repair or replace harness.
3.CHECK BCM OUTPUT SIGNAL
1. Connect BCM connector.
2. Check voltage between front door lock actuator LH harness connector and ground.
Is the inspection result normal?
YES >> Check for internal short of each door lock actuator.
NO >> Replace BCM. Refer to BCS-137, "
Removal and Installation".
PASSENGER SIDE
PASSENGER SIDE : DescriptionINFOID:0000000012430200
Locks/unlocks the door with the signal from BCM.
PASSENGER SIDE : Component Function CheckINFOID:0000000012430201
1.CHECK FUNCTION
1. Perform “DOOR LOCK”“Active Test” using CONSULT.
2. Touch “ALL LOCK” or “ALL UNLOCK” to check that it works normally.
Is the inspection result normal?
YES >> Door lock actuator is OK.
NO >> Refer to DLK-243, "
PASSENGER SIDE : Diagnosis Procedure".
PASSENGER SIDE : Dia gnosis ProcedureINFOID:0000000012430202
Regarding Wiring Diagram information, refer to DLK-206, "Wiring Diagram".
1.CHECK DOOR LOCK ACTUATOR INPUT SIGNAL
1. Turn ignition switch OFF.
2. Disconnect front door lock actuator RH connector.
3. Check voltage between front door lock actuator RH harness connector and ground.
Is the inspection result normal?
YES >> Replace front door lock actuator RH. Refer to DLK-295, "DOOR LOCK : Removal and Installa-
tion".
NO >> GO TO 2.
2.CHECK DOOR LOCK ACTUATOR CIRCUIT
1. Disconnect BCM connector and all door lock actuators.
2. Check continuity between BCM harness connector and front door lock actuator RH harness connector.
(+)
(–) Condition Vo l ta g e
(Approx.)
BCM
Connector Terminal
M19 54
Ground Door lock and unlock switch Lock
Battery voltage
41 Unlock
(+)
(–) Condition Vo l ta g e
(Approx.)
Front door lock actuator
RH
Connector Terminal
D114 2
Ground Door lock and unlock switch Lock
Battery voltage
1 Unlock
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 933 of 3641
![NISSAN NOTE 2016 Service Repair Manual DLK-244
< DTC/CIRCUIT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
DOOR LOCK ACTUATOR
3. Check continuity between
BCM harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO NISSAN NOTE 2016 Service Repair Manual DLK-244
< DTC/CIRCUIT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
DOOR LOCK ACTUATOR
3. Check continuity between
BCM harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO](/manual-img/5/57363/w960_57363-932.png)
DLK-244
< DTC/CIRCUIT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
DOOR LOCK ACTUATOR
3. Check continuity between
BCM harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness.
3.CHECK BCM OUTPUT SIGNAL
1. Connect BCM connector.
2. Check voltage between front door lock actuator RH harness connector and ground.
Is the inspection result normal?
YES >> Check for internal short of each door lock actuator.
NO >> Replace BCM. Refer to BCS-137, "
Removal and Installation".
REAR LH
REAR LH : DescriptionINFOID:0000000012430203
Locks/unlocks the door with the signal from BCM.
REAR LH : Component Function CheckINFOID:0000000012430204
1.CHECK FUNCTION
1. Perform “DOOR LOCK” in “Active Test” using CONSULT.
2. Touch “ALL LOCK” or “ALL UNLOCK” to check that it works normally.
Is the inspection result normal?
YES >> Door lock actuator is OK.
NO >> Refer to DLK-244, "
REAR LH : Diagnosis Procedure".
REAR LH : Diagnosis ProcedureINFOID:0000000012430205
Regarding Wiring Diagram information, refer to DLK-206, "Wiring Diagram".
1.CHECK DOOR LOCK ACTUATOR INPUT SIGNAL
1. Turn ignition switch OFF.
2. Disconnect rear door lock actuator LH connector.
3. Check voltage between rear door lock actuator LH harness connector and ground.
BCM Front door lock actuator RH
Continuity
Connector TerminalConnector Terminal
M19 54
D114 2
Ye s
53 1
BCM GroundContinuity
Connector Terminal
M19 54
No
53
(+)
(–) Condition Vo l ta g e
(Approx.)
BCM
Connector Terminal
M19 54
Ground Door lock and unlock switch Lock
Battery voltage
53 Unlock
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 934 of 3641
![NISSAN NOTE 2016 Service Repair Manual DOOR LOCK ACTUATORDLK-245
< DTC/CIRCUIT DIAGNOSIS > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
Is the inspection result normal?
YES >> Replace rear door lock actuator LH. Refer NISSAN NOTE 2016 Service Repair Manual DOOR LOCK ACTUATORDLK-245
< DTC/CIRCUIT DIAGNOSIS > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
Is the inspection result normal?
YES >> Replace rear door lock actuator LH. Refer](/manual-img/5/57363/w960_57363-933.png)
DOOR LOCK ACTUATORDLK-245
< DTC/CIRCUIT DIAGNOSIS > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
Is the inspection result normal?
YES >> Replace rear door lock actuator LH. Refer to DLK-299, "DOOR LOCK : Removal and Installation".
NO >> GO TO 2.
2.CHECK DOOR LOCK ACTUATOR CIRCUIT
1. Disconnect BCM connector and all door lock actuator connectors.
2. Check continuity between BCM harness connector and rear door lock actuator LH harness connector.
3. Check continuity between BCM harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness.
3.CHECK BCM OUTPUT SIGNAL
1. Connect BCM connector.
2. Check voltage between rear door lock actuator LH harness connector and ground.
Is the inspection result normal?
YES >> Check for internal short of each door lock actuator.
NO >> Replace BCM. Refer to BCS-137, "
Removal and Installation".
REAR RH
REAR RH : DescriptionINFOID:0000000012430206
Locks/unlocks the door with the signal from BCM.
REAR RH : Component Function CheckINFOID:0000000012430207
1.CHECK FUNCTION
1. Perform “DOOR LOCK” in “Active Test” using CONSULT.
2. Touch “ALL LOCK” or “ALL UNLOCK” to check that it works normally.
Is the inspection result normal?
(+)
(–) Condition Vo l ta g e
(Approx.)
Rear door lock actuator LH
Connector Terminal
D205 1
Ground Door lock and unlock switch Lock
Battery voltage
2 Unlock
BCMRear door lock actuator LH
Continuity
Connector TerminalConnector Terminal
M19 54
D205 1
Ye s
53 2
BCM GroundContinuity
Connector Terminal
M19 54
No
53
(+)
(–) Condition Vo l ta g e
(Approx.)
BCM
Connector Terminal
M19 54
Ground Door lock and unlock switch Lock
Battery voltage
53 Unlock
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 935 of 3641
![NISSAN NOTE 2016 Service Repair Manual DLK-246
< DTC/CIRCUIT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
DOOR LOCK ACTUATOR
YES >> Door lock actuator is OK.
NO >> Refer to
DLK-246, "
REAR RH : Diagnosis Procedure".
REAR RH : Diagnosis Pro NISSAN NOTE 2016 Service Repair Manual DLK-246
< DTC/CIRCUIT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
DOOR LOCK ACTUATOR
YES >> Door lock actuator is OK.
NO >> Refer to
DLK-246, "
REAR RH : Diagnosis Procedure".
REAR RH : Diagnosis Pro](/manual-img/5/57363/w960_57363-934.png)
DLK-246
< DTC/CIRCUIT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
DOOR LOCK ACTUATOR
YES >> Door lock actuator is OK.
NO >> Refer to
DLK-246, "
REAR RH : Diagnosis Procedure".
REAR RH : Diagnosis ProcedureINFOID:0000000012430208
Regarding Wiring Diagram information, refer to DLK-206, "Wiring Diagram".
1.CHECK DOOR LOCK ACTUATOR INPUT SIGNAL
1. Turn ignition switch OFF.
2. Disconnect rear door lock actuator RH connector.
3. Check voltage between rear door lock actuator RH harness connector and ground.
Is the inspection result normal?
YES >> Replace rear door lock actuator RH. Refer to DLK-299, "DOOR LOCK : Removal and Installation".
NO >> GO TO 2.
2.CHECK DOOR LOCK ACTUATOR CIRCUIT
1. Disconnect BCM connector and all door lock actuator connectors.
2. Check continuity between BCM harness connector and rear door lock actuator RH harness connector.
3. Check continuity between BCM harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness.
3.CHECK BCM OUTPUT SIGNAL
1. Connect BCM connector.
2. Check voltage between rear door lock actuator RH harness connector and ground.
Is the inspection result normal?
YES >> Check for internal short of each door lock actuator.
NO >> Replace BCM. Refer to BCS-137, "
Removal and Installation".
(+)
(–) Condition Vo l ta g e
(Approx.)
Rear door lock actuator RH
Connector Terminal
D305 2
Ground Door lock and unlock switch Lock
Battery voltage
1 Unlock
BCMRear door lock actuator RH
Continuity
Connector TerminalConnector Terminal
M19 54
D305 2
Ye s
53 1
BCM GroundContinuity
Connector Terminal
M19 54
No
53
(+)
(–) Condition Vo l ta g e
(Approx.)
BCM
Connector Terminal
M19 54
Ground Door lock and unlock switch Lock
Battery voltage
53 Unlock
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 936 of 3641
![NISSAN NOTE 2016 Service Repair Manual REMOTE KEYLESS ENTRY RECEIVERDLK-247
< DTC/CIRCUIT DIAGNOSIS > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
REMOTE KEYLESS ENTRY RECEIVER
DescriptionINFOID:0000000012430209
Rece NISSAN NOTE 2016 Service Repair Manual REMOTE KEYLESS ENTRY RECEIVERDLK-247
< DTC/CIRCUIT DIAGNOSIS > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
REMOTE KEYLESS ENTRY RECEIVER
DescriptionINFOID:0000000012430209
Rece](/manual-img/5/57363/w960_57363-935.png)
REMOTE KEYLESS ENTRY RECEIVERDLK-247
< DTC/CIRCUIT DIAGNOSIS > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
REMOTE KEYLESS ENTRY RECEIVER
DescriptionINFOID:0000000012430209
Receives keyfob operation and transmits to BCM.
Component Function CheckINFOID:0000000012430210
1.CHECK FUNCTION
With CONSULT
Check remote keyless entry receiver “KEYLESS LOCK”, “KEYLESS UNLOCK”, and “KEYLESS PANIC” in
“Data Monitor”.
Is the inspection result normal?
YES >> Remote keyless entry receiver is OK.
NO >> Refer to DLK-247, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000012430211
Regarding Wiring Diagram information, refer to DLK-216, "Wiring Diagram".
1.CHECK REMOTE KEYLESS ENTRY RECEIVER OUTPUT SIGNAL
1. Turn ignition switch OFF.
2. Check signal between remote keyless entry receiver connector and ground with oscilloscope.
Is the inspection result normal?
YES >> GO TO 7.
NO >> GO TO 2.
Monitor item Condition
KEYLESS LOCK Checks whether value changes from “Off” to “On” when operating keyfob lock button.
KEYLESS UNLOCK Checks whether value changes from “Off” to “On” when operating keyfob unlock button.
KEYLESS PANIC Checks whether value changes from “Off” to “On” when operating keyfob panic button.
Te r m i n a l s
ConditionSignal
(Reference value)
(+)
(–)
Remote keyless entry re-
ceiver connector Te r m i n a l
M23 2 Ground Waiting
(All doors closed)
When signal is received (All doors closed)
PIIB7728J
PIIB7729J
Revision: August 2015 2016 Versa Note
cardiagn.com
