NISSAN NOTE 2016 Service Repair Manual DLK-16
< SYSTEM DESCRIPTION >[WITH INTELLIGENT KEY SYSTEM]
COMPONENT PARTS
INTELLIGENT KEY SYSTEM : In side Key Antenna (Console)
INFOID:0000000012429967
• Inside key antenna (console) detects that

Page 706 of 3641

NISSAN NOTE 2016 Service Repair Manual COMPONENT PARTSDLK-17
< SYSTEM DESCRIPTION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
INTELLIGENT KEY SYSTEM : Outsi de Key Antenna (Passenger Side)INFOID:0000000012429971
• O

Page 707 of 3641

NISSAN NOTE 2016 Service Repair Manual DLK-18
< SYSTEM DESCRIPTION >[WITH INTELLIGENT KEY SYSTEM]
COMPONENT PARTS
INTELLIGENT KEY SYSTEM : Back Door Lock Assembly
INFOID:0000000012429975
• Back door lock assembly integrates door lock act

Page 708 of 3641

NISSAN NOTE 2016 Service Repair Manual COMPONENT PARTSDLK-19
< SYSTEM DESCRIPTION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
INTELLIGENT KEY SYSTEM : Door SwitchINFOID:0000000012429979
Door switch detects open/close

Page 709 of 3641

NISSAN NOTE 2016 Service Repair Manual DLK-20
< SYSTEM DESCRIPTION >[WITH INTELLIGENT KEY SYSTEM]
SYSTEM (POWER DOOR LOCK SYSTEM)
SYSTEM (POWER DOOR LOCK SYSTEM)
System DiagramINFOID:0000000012429981
System DescriptionINFOID:00000000124299

DLK-20
< SYSTEM DESCRIPTION >[WITH INTELLIGENT KEY SYSTEM]
SYSTEM (POWER DOOR LOCK SYSTEM)
SYSTEM (POWER DOOR LOCK SYSTEM)
System DiagramINFOID:0000000012429981
System DescriptionINFOID:0000000012429982
DOOR LOCK FUNCTION
• The door lock and unlock switch LH is built into the main power window and door lock/unlock switch.
• The door lock and unlock switch RH is built into
the power window and door lock/unlock switch RH.
• Interlocked with the locking operation of door lock and unlock switch, door lock actuators of all doors are
locked.
• Interlocked with the unlocking operation of door lock and unlock switch, door lock actuators of all doors are
unlocked.
Door Key Cylinder
• With the door key inserted in the door key cylinder on driver side, turning it to “LOCK”, will lock door lock actuator of all doors.
• With the door key inserted in the door key cylinder on driver side, turning it to “UNLOCK” onc\
e unlocks the driver side door lock actuator; turning it to “UNLOCK” again within 60 seconds after the first unlock operation
unlocks all of the other doors. - (SELECTIVE UNLOCK OPERATION)
Selective unlock operation mode can be changed using “A UTO LOCK SET” in “Work support”. Refer to BCS-
18, "DOOR LOCK : CONSULT Function (BCM - DOOR LOCK)".
AUTOMATIC DOOR LOCKS (LOCK OPERATION)
The automatic door locks function is the function that locks all doors linked with the vehicle speed or shift posi-
tion.
Vehicle Speed Sensing Auto Door Lock*1
All doors are locked when the vehicle speed reaches 24 km/h (15 MPH) or more.
BCM outputs the lock signal to all door lock actuators when it detects that the ignition switch is turned ON, all
doors are closed and the vehicle speed received from the combination meter via CAN communication
becomes 24 km/h (15 MPH) or more.
If a door is opened and closed at any time during one ignition cycle (OFF → ON), even after initial auto door
lock operation has taken place, the BCM will relock al l doors when the vehicle speed reaches 24 km/h (15
MPH) or more again.
ALKIA2288GB
Input SingleFunction Actuator
Door lock/unlock switch Door lock/unlock signal Door lock function
• Each door lock actuator
Door key cylinder switch
Each door switch
Door open/close signal
Key reminder function
Combination meter Warning buzzer signal
Vehicle speed signal
Automatic door lock/unlock
function
Revision: August 2015
2016 Versa Note

cardiagn.com

Page 710 of 3641

NISSAN NOTE 2016 Service Repair Manual SYSTEM (POWER DOOR LOCK SYSTEM)DLK-21
< SYSTEM DESCRIPTION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
Setting change of Automatic Door Locks (LOCK) Function
The LOCK operation s

SYSTEM (POWER DOOR LOCK SYSTEM)DLK-21
< SYSTEM DESCRIPTION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
Setting change of Automatic Door Locks (LOCK) Function
The LOCK operation setting of the aut
omatic door locks function can be changed.
With CONSULT
The ON/OFF switching of the automatic door locks (LOCK) function and the type selection of the automatic
door locks (LOCK) function can be performed at the “Work support” setting. Refer to BCS-18, "
DOOR LOCK :
CONSULT Function (BCM - DOOR LOCK)".
Without CONSULT
The automatic door locks (LOCK) function can be switched ON/OFF by performing the following operation:
1. Close all doors. (door switch OFF)
2. Push the ignition switch to the ON position.
3. Press and hold the door lock and unlock switch for 5 seconds or more in the lock direction within 20 sec- onds after turning the ignition switch ON.
4. The switching is completed when the hazard lamp blinks.
5. The ignition switch must be turned OFF and ON again between each setting change.
AUTOMATIC DOOR LOCKS (UNLOCK OPERATION)
The automatic door locks (UNLOCK) function is the func tion that unlocks all doors linked with the key position
or shift position.
IGN OFF Interlo ck Door Unlock*1
All doors are unlocked when the power supply position is changed from ON to OFF.
BCM outputs the unlock signal to all door lock actuator s when it detects that the power supply position is
changed from ignition switch ON to OFF.
Setting change of Automatic Door Locks (UNLOCK) Function
The UNLOCK operation setting of the automatic door locks function can be changed.
With CONSULT
The ON/OFF switching of the automatic door locks (UNL OCK) function and the type selection of the automatic
door locks (UNLOCK) function can be performed at the “Work support” setting. Refer to BCS-18, "
DOOR
LOCK : CONSULT Function (BCM - DOOR LOCK)".
Without CONSULT
The automatic door locks (UNLOCK) function can be sw itched ON/OFF by performing the following operation:
1. Close all doors. (door switch OFF)
2. Place the ignition switch in the ON position.
3. Press and hold the door lock and unlock switch for 5 seconds or more in the unlock direction within 20 seconds after turning the power supply position ON.
4. The switching is completed when the hazard lamp blinks.
5. The ignition switch must be turned OFF and ON again between each setting change.
*1: This function is set to ON before delivery.
OFF → ON : 2 blinks
ON → OFF : 1 blink
OFF → ON : 2 blinks
ON → OFF : 1 blink
Revision: August 2015 2016 Versa Note

cardiagn.com

Page 711 of 3641

NISSAN NOTE 2016 Service Repair Manual DLK-22
< SYSTEM DESCRIPTION >[WITH INTELLIGENT KEY SYSTEM]
SYSTEM (INTELLIGENT KEY SYSTEM)
SYSTEM (INTELLIGENT KEY SYSTEM)
INTELLIGENT KEY SYSTEM
INTELLIGENT KEY SYSTEM : System DescriptionINFOID:0000

Page 712 of 3641

NISSAN NOTE 2016 Service Repair Manual SYSTEM (INTELLIGENT KEY SYSTEM)DLK-23
< SYSTEM DESCRIPTION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
DOOR LOCK FUNCTION
