Page 1818 of 3641

FAX-1
TRANSMISSION & DRIVELINE
CEF
G H
I
J
K L
M
SECTION FA X
A
B
FA X
N
O P
CONTENTS
FRONT AXLE
PRECAUTION ....... ........................................2
PRECAUTIONS .............................................. .....2
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ............................................................. ......
2
Precaution for Drive Shaft .........................................2
Precautions for Wheel Hub and Knuckle ..................2
PREPARATION ............................................3
PREPARATION .............................................. .....3
Special Service Tools .......................................... ......3
Commercial Service Tools ........................................4
SYMPTOM DIAGNOSIS ...............................6
NOISE, VIBRATION AND HARSHNESS
(NVH) TROUBLESHOOTING ........................ .....
6
NVH Troubleshooting Chart ................................ ......6
PERIODIC MAINTENANCE ..........................7
FRONT WHEEL HUB AND KNUCKLE ......... .....7
Inspection ............................................................ ......7
FRONT DRIVE SHAFT ........................................8
Inspection ............................................................ ......8
REMOVAL AND INSTALLATION ................9
FRONT WHEEL HUB AND KNUCKLE ......... .....9
Exploded View ..................................................... .....9
Removal and Installation ..........................................9
Disassembly and Assembly .....................................11
Inspection ................................................................13
FRONT DRIVE SHAFT BOOT ..........................14
Exploded View .........................................................14
WHEEL SIDE ......................................................... ....14
WHEEL SIDE : Removal and Installation ................15
TRANSAXLE SIDE ................................................ ....18
TRANSAXLE SIDE : Removal and Installation .......18
Inspection ............................................................ ....18
FRONT DRIVE SHAFT .....................................19
Exploded View .........................................................19
Removal and Installation .........................................19
UNIT DISASSEMBLY AND ASSEMBLY ....21
FRONT DRIVE SHAFT .....................................21
Exploded View ..................................................... ....21
Disassembly and Assembly .....................................22
SERVICE DATA AND SPECIFICATIONS
(SDS) ............... .......................................... ...
27
SERVICE DATA AND SPECIFICATIONS
(SDS) .................................................................
27
Wheel Bearing ..................................................... ....27
Drive Shaft ...............................................................27
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 1819 of 3641

FAX-2
< PRECAUTION >
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000012431882
The Supplemental Restraint System such as “A IR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the SR and SB section of
this Service Manual.
WARNING:
• To avoid rendering the SRS inopera tive, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
• Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintent ional activation of the system. For re moval of Spiral Cable and Air Bag
Module, see the SR section.
• Do not use electrical test equipmen t on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harn esses can be identified by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
• When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Igni-
tion ON or engine running, DO NOT use air or electri c power tools or strike near the sensor(s) with a
hammer. Heavy vibration could activate the sensor( s) and deploy the air bag(s), possibly causing
serious injury.
• When using air or electric power tools or hammers , always switch the Ignition OFF, disconnect the
battery and wait at least three minutes before performing any service.
Precaution for Drive ShaftINFOID:0000000012431883
Observe the following precautions when disassembling and assembling drive shaft.
• Do not disassemble joint sub-assembly because it is non-overhaul parts.
• Perform work in a location which is as dust-free as possible.
• Clean the parts, before disassembling and assembling.
• Prevent the entry of foreign objects dur ing disassembly of the service location.
• Reassemble disassembled parts carefully in the correct order. If work is interrupted, a clean cover must be placed over parts.
• Use paper waste. Fabric shop cloths must not be used because of the danger of lint adhering to parts.
• Clean disassembled parts (except for rubber parts) with kerosene which shall be removed by blowing with air or wiping with paper waste.
Precautions for Wheel Hub and KnuckleINFOID:0000000012431884
Observe the following precautions when assembling wheel hub and knuckle.
• Perform work in a location which is as dust-free as possible.
• Use paper waste. Fabric shop cloths must not be used because of the danger of lint adhering to parts.
• If any of wheel hub, steering knuckle, wheel bearing, and wheel hub lock nut is dropped, it must not be used.
• Always check that the tools used for press-fit work of wheel hub and wheel bearing have no wear and defor- mation so that a pressure can be applied vertically.
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 1820 of 3641
PREPARATIONFAX-3
< PREPARATION >
CEF
G H
I
J
K L
M A
B
FA X
N
O P
PREPARATION
PREPARATION
Special Service ToolsINFOID:0000000012431885
The actual shape of the tools may di ffer from those illustrated here.
Tool number
(TechMate No.)
To o l n a m e Description
KV40104000
(—)
Hub lock nut wrench Removing and Installing wheel hub lock
nut
a: 85 mm (3.35 in)
b: 65 mm (2.56 in)
ST33710000
(—)
Drift Removing wheel hub
a: 30 mm (1.18 in) dia.
b: 23 mm (0.91 in) dia.
ST30031000
(—)
Puller Removing wheel bearing inner race (out-
er)
ST35321000
(—)
Drift • Removing wheel bearing
• Installing wheel hub
a: 49 mm (1.93 in) dia.
b: 41 mm (1.61 in) dia.
ST35271000
(—)
Drift Installing wheel bearing
a: 72 mm (2.83 in) dia.
b: 63 mm (2.48 in) dia.
ST33061000
(—)
Drift Installing wheel hub
a: 38 mm (1.50 in) dia.
b: 28.5 mm (1.122 in) dia.
ZZA0802D
ZZA1233D
ZZA0700D
ZZA1051D
ZZA0837D
ZZA1051D
Revision: August 2015
2016 Versa Note
cardiagn.com
Page 1821 of 3641
FAX-4
< PREPARATION >
PREPARATION
Commercial Service Tools
INFOID:0000000012431886
KV40107300
(J-51751)
Boot band crimping tool Installing boot band
KV40107500
(—)
Drive shaft attachment Removing drive shaft
KV38107900
(—)
Differential side oil seal protector Installing drive shaft
a: 32 mm (1.26 in) dia.
Tool number
(TechMate No.)
Tool name
Description
ALDIA0586ZZ
ZZA1230D
PDIA1183J
Tool name
Description
Drive shaft puller Removing drive shaft joint sub-assembly
Sliding hammer Removing drive shaft
Ball joint remover Removing wheel stud
JPDIG0152ZZ
ZZA0023D
NT146
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 1822 of 3641
PREPARATIONFAX-5
< PREPARATION >
CEF
G H
I
J
K L
M A
B
FA X
N
O P
Drift • Installing wheel bearing
• Installing splash guard
a: 68 mm (2.68 in) dia.
Drift Installing splash guard
a: 95 mm (3.74 in) dia.
Power tool Loosening nuts, screws and bolts
Tool name
Description
ZZA0898D
JPDIC0679ZZ
PIIB1407E
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 1823 of 3641
FAX-6
< SYMPTOM DIAGNOSIS >
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING
SYMPTOM DIAGNOSIS
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING
NVH Troubleshooting ChartINFOID:0000000012431887
Use chart below to find the cause of the symptom. If necessary, repair or replace these parts.
×: ApplicableReference
—
FAX-8—
FAX-8—
FSU-5FSU-5—
WT-45WT-44—
BR-7ST-7
Possible cause and SUSPECTED PARTS
Excessive joint angle
Joint sliding resistance
Imbalance
Improper installation, looseness
Parts interference
Wheel bearing damage
FRONT SUSPENSION
FRONT AXLE
TIRE
ROAD WHEEL
DRIVE SHAFT
BRAKE
STEERING
Symptom DRIVE
SHAFT
Noise
××××××× ××
Shake × × ××××× ××
FRONT
AXLE Noise
×××× ×××××
Shake ×××× ×××××
Vibration ×××××××
Shimmy ×××××××
Shudder × × ×× ××
Poor quality ride or handling ×××××
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 1824 of 3641
FRONT WHEEL HUB AND KNUCKLEFAX-7
< PERIODIC MAINTENANCE >
CEF
G H
I
J
K L
M A
B
FA X
N
O P
PERIODIC MAINTENANCE
FRONT WHEEL HUB AND KNUCKLE
InspectionINFOID:0000000012431888
COMPONENT PART
• Check that the mounting conditions (looseness, ba cklash) of each component and component conditions
(wear, damage) are normal.
• Check the axle and suspension parts for excessive play, weary or damage.
• Shake each front wheel to check for excessive play.
FRONT WHEEL BEARING INSPECTION
Check the following items, and replace the part if necessary.
• Move the wheel bearing in the axial direction by hand. Make sure there is no looseness in the wheel bearing.
• Rotate the wheel bearing and make sure there is no unusual noise or other irregular conditions. If there are any irregular conditions, replace wheel bearing.
SMA525A
Axial end play : Refer to FA X - 2 7.
Revision: August 2015 2016 Versa Note
