NISSAN NOTE 2016 Service Repair Manual DLK-192
< PREPARATION >[WITHOUT INTELLIGENT KEY SYSTEM]
PREPARATION
Commercial Service Tools
INFOID:0000000012430154
KV48105501
(J-45295-A)
Transmitter Activation Tool • Activate TPMS transmitter ID

Page 882 of 3641

NISSAN NOTE 2016 Service Repair Manual COMPONENT PARTSDLK-193
< SYSTEM DESCRIPTION > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
SYSTEM DESCRIPTION
COMPONENT PARTS
REMOTE KEYLESS ENTRY SYSTEM
REMOTE KEYLESS EN TRY SY

Page 883 of 3641

NISSAN NOTE 2016 Service Repair Manual DLK-194
< SYSTEM DESCRIPTION >[WITHOUT INTELLIGENT KEY SYSTEM]
COMPONENT PARTS
REMOTE KEYLESS ENTRY SYSTEM : Fron t Door Lock Assembly (Driver Side)
INFOID:0000000012430156
• Door lock actuator and

DLK-194
< SYSTEM DESCRIPTION >[WITHOUT INTELLIGENT KEY SYSTEM]
COMPONENT PARTS
REMOTE KEYLESS ENTRY SYSTEM : Fron t Door Lock Assembly (Driver Side)
INFOID:0000000012430156
• Door lock actuator and unlock sensor are Integrated in front door
lock assembly LH.
• Door lock actuator receives lock/unlock signal from BCM, and then locks/unlocks driver door.
• Only front door lock assembly LH integrates unlock sensor. Unlock sensor transmits lock/unlock status of driver door to BCM.
3. BCM Then, when the ignition switch is turned ON, BCM
performs ID verification between BCM and ECM. If
the ID verification result is OK, ECM can start en-
gine.
Refer to BCS-77, "
BODY CONTROL SYSTEM :
Component Parts Location" for detailed installation
location.
4. Main power window and door lock/unlock switch Door lock and unlock switch is integrated into the
main power window and door lock/unlock switch.
Door lock and unlock switch transmits door lock/un-
lock operation signal to BCM.
Refer to PWC-7, "
Main Power Window And Door
Lock/Unlock Switch".
5. Front door lock assembly LH Door key cylinder switch is integrated into front door
lock assembly (driver side).
Door key cylinder switch detects door LOCK/UN-
LOCK operation using mechanical key, and then
transmits the operation signal to BCM.
Refer to DLK-194, "
REMOTE KEYLESS ENTRY
SYSTEM : Front Door Lock Assembly (Driver
Side)".
6. Rear door lock actuator LH Rear door lock actuator locks/unlocks the rear door
latch assembly.
7. Back door lock actuator Back door lock actuator locks/unlocks the back door
latch assembly. Refer to
DLK-195, "
REMOTE KEY-
LESS ENTRY SYSTEM : Back Door Lock Assem-
bly".
8. Remote keyless entry receiver Remote keyless entry receiver receives button op-
eration signal and key ID signal of Intelligent Key,
and them transmits them to the BCM.
Refer to DLK-195, "
REMOTE KEYLESS ENTRY
SYSTEM : Remote Keyless Entry Receiver".
9. Door switch Door switch detects door open/close condition and
then transmits ON/OFF signal to BCM. Refer to
DLK-195, "
REMOTE KEYLESS ENTRY SYSTEM :
Door Switch".
No.
Component Function
JMKIA8649ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

Page 884 of 3641

NISSAN NOTE 2016 Service Repair Manual COMPONENT PARTSDLK-195
< SYSTEM DESCRIPTION > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
REMOTE KEYLESS ENTRY SYSTEM : Remote Keyless Entry ReceiverINFOID:0000000012430157
•

Page 885 of 3641

NISSAN NOTE 2016 Service Repair Manual DLK-196
< SYSTEM DESCRIPTION >[WITHOUT INTELLIGENT KEY SYSTEM]
SYSTEM
SYSTEM
AUTOMATIC DOOR LOCK/UNLOCK FUNCTION
AUTOMATIC DOOR LOCK/UNLOC
K FUNCTION : System DiagramINFOID:0000000012430161
AUTOMATIC

DLK-196
< SYSTEM DESCRIPTION >[WITHOUT INTELLIGENT KEY SYSTEM]
SYSTEM
SYSTEM
AUTOMATIC DOOR LOCK/UNLOCK FUNCTION
AUTOMATIC DOOR LOCK/UNLOC
K FUNCTION : System DiagramINFOID:0000000012430161
AUTOMATIC DOOR LOCK/UNLOCK FUNCTION : System DescriptionINFOID:0000000012430162
DOOR LOCK FUNCTION
• The door lock and unlock switch (LH) is built in to main power window and door lock/unlock switch.
• The door lock and unlock switch (RH) is built into power window and door lock/unlock switch RH.
• Interlocked with the locking operation of door lock and unlock switch, door lock actuators of all doors are
locked.
• Interlocked with the unlocking operation of door lock and unlock switch, door lock actuators of all doors are
unlocked.
Door Key Cylinder
• With the door key inserted in the door key cylinder on driver side, turning it to “LOCK”, will lock door lock actuator of all doors.
• With the door key inserted in the door key cylinder on driver side, turning it to “UNLOCK” onc\
e unlocks the driver side door lock actuator; turning it to “UNLOCK” again within 60 seconds after the first unlock operation
unlocks all of the other doors. - (SELECTIVE UNLOCK OPERATION)
Selective unlock operation mode can be changed using “DOOR LOCK-UNLOCK SET” mode in “Work sup-
port”. Refer to BCS-90, "
DOOR LOCK : CONSULT Function (BCM - DOOR LOCK)".
AUTOMATIC DOOR LOCKS (LOCK OPERATION)
The automatic door locks function is the function that locks all doors linked with the vehicle speed or shift posi-
tion.
Vehicle Speed Sensing Auto Door Lock*1
All doors are locked when the vehicle speed reaches 24 km/h (15 MPH) or more.
BCM outputs the lock signal to all door lock actuators when it detects that the ignition switch is turned ON, all
doors are closed and the vehicle speed received from the combination meter via CAN communication
becomes 24 km/h (15 MPH) or more.
ALKIA2288GB
Input SingleFunction Actuator
Door lock/unlock switch Door lock/unlock signal Door lock function
• Each door lock actuator
Door key cylinder switch
Each door switch
Door open/close signal
Key reminder function
Combination meter Warning buzzer signal
Vehicle speed signal
Automatic door lock/unlock
function
Revision: August 2015
2016 Versa Note

cardiagn.com

Page 886 of 3641

$NISSAN NOTE 2016 Service Repair Manual SYSTEMDLK-197 < SYSTEM DESCRIPTION > [WITHOUT INTELLIGENT KEY SYSTEM] C D E F G H I J L M A B DLK N O P If a door is opened and closed at any time during one ignition cycle (O\ FF → ON), even after$

SYSTEMDLK-197
< SYSTEM DESCRIPTION > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
If a door is opened and closed at any time during one ignition cycle (O\
FF → ON), even after initial auto door
lock operation has taken place, the BCM will relock all doors when the vehicle speed reaches 24 km/h (15
MPH) or more again.
Setting change of Automatic Door Locks (LOCK) Function
The LOCK operation setting of the aut omatic door locks function can be changed.
With CONSULT
The ON/OFF switching of the automatic door locks (LOCK) function and the type selection of the automatic
door locks (LOCK) function can be performed at the “Work support”. Refer to BCS-90, "
DOOR LOCK : CON-
SULT Function (BCM - DOOR LOCK)".
Without CONSULT
The automatic door locks (LOCK) function can be swit ched ON/OFF by performing the following operation:
1. Close all doors (door switch OFF).
2. Push the ignition switch to the ON position.
3. Press and hold the door lock and unlock switch for 5 seconds or more in the lock direction within 20 sec- onds after turning the ignition switch ON.
4. The switching is completed when the hazard lamp blinks.
5. The ignition switch must be turned OFF and ON again between each setting change.
AUTOMATIC DOOR LOCKS (UNLOCK OPERATION)
The automatic door locks (UNLOCK) function is the func tion that unlocks all doors linked with the key position
or shift position.
IGN OFF Interlo ck Door Unlock*1
All doors are unlocked when the power supply position is changed from ON to OFF.
BCM outputs the unlock signal to all door lock actuator s when it detects that the power supply position is
changed from ignition switch ON to OFF.
Setting change of Automatic Door Locks (UNLOCK) Function
The UNLOCK operation setting of the automatic door locks function can be changed.
With CONSULT
The ON/OFF switching of the automatic door locks (UNL OCK) function and the type selection of the automatic
door locks (UNLOCK) function can be perfo rmed at the “Work support”. Refer to BCS-90, "
DOOR LOCK :
CONSULT Function (BCM - DOOR LOCK)".
Without CONSULT
The automatic door locks (UNLOCK) function can be sw itched ON/OFF by performing the following operation:
1. Close all doors (door switch OFF).
2. Place the ignition switch in the ON position.
3. Press and hold the door lock and unlock switch for 5 seconds or more in the unlock direction within 20 seconds after turning the power supply position ON.
4. The switching is completed when the hazard lamp blinks.
5. The ignition switch must be turned OFF and ON again between each setting change.
*1: This function is set to ON before delivery.
POWER DOOR LOCK SYSTEM
OFF → ON : 2 blinks
ON → OFF : 1 blink
OFF → ON : 2 blinks
ON → OFF : 1 blink
Revision: August 2015 2016 Versa Note

cardiagn.com

Page 887 of 3641

NISSAN NOTE 2016 Service Repair Manual DLK-198
< SYSTEM DESCRIPTION >[WITHOUT INTELLIGENT KEY SYSTEM]
SYSTEM
POWER DOOR LOCK SYSTEM : System Diagram
INFOID:0000000012430163
POWER DOOR LOCK SYSTE M : System DescriptionINFOID:000000001243016

Page 888 of 3641

NISSAN NOTE 2016 Service Repair Manual SYSTEMDLK-199
< SYSTEM DESCRIPTION > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
REMOTE KEYLESS ENTRY SY STEM : System DiagramINFOID:0000000012430165
REMOTE KEYLESS ENTRY SYST E

SYSTEMDLK-199
< SYSTEM DESCRIPTION > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
REMOTE KEYLESS ENTRY SY STEM : System DiagramINFOID:0000000012430165
REMOTE KEYLESS ENTRY SYST EM : System DescriptionINFOID:0000000012430166
The remote keyless entry system can be locked and unlocked by pressing door lock and unlock button of key-
fob.
DOOR LOCK AND UNLOCK OPERATION
• When door lock and unlock button of keyfob is pressed, door lock and unlock signal transmits from keyfob to
BCM via remote keyless entry receiver.
• When BCM receives the door lock and unlock signal, it operates door lock actuator, flashes the hazard lamp (lock: 2 times, unlock: 1 time) and horn chirp signal to IPDM E/R at the same time as a reminder.
• IPDM E/R honks horn (lock: 1 time) as a reminder.
OPERATION CONDITION
OPERATION AREA
To ensure that the keyfob works effect ively, use within 10 m (33ft) range of the vehicle, however the operable
range may differ according to surroundings.
SELECTIVE UNLOCK OPERATION
When door lock is unlocked, pressing LOCK button on keyfob once will lock all doors. When door lock is
locked, pressing UNLOCK button on keyfob will unlock driver side door. Pressing UNLOCK button on keyfob
second time within 5 seconds from the first time will unlock all doors.
HAZARD AND HORN REMINDER
When the doors are locked or unlocked by keyfob, power is supplied to sound horn and flash hazard warning
lamps as a reminder
The hazard and horn reminder has C mode (horn chirp mode) and S mode (non-horn chirp mode).
How to Change Hazard and Horn Reminder Modes
With CONSULT
Hazard and horn reminders can be changed using “Work support” in “MULTI REMOTE ENT”.
ALKIA2290GB
Remote controller operation Operation condition
Lock/unlock Key switch is OFF. Mechanical key is removed from the ignition cylinder.
Hazard reminder settingMode 1Mode 2Mode 3Mode 4
Keyfob operation Lock Unlock Lock Unlock Lock Unlock Lock Unlock
Hazard warning lamp blink — — — Once Twice — Twice Once
