• The combination meter includes an on board diagnosis function.
• The combination meter can be diagnosed with CONSUL NISSAN NOTE 2016 Service Repair Manual MWI
SYSTEMMWI-11
< SYSTEM DESCRIPTION > [TYPE A]
C
D
E
F
G H
I
J
K L
M B A
O P
• The combination meter includes an on board diagnosis function.
• The combination meter can be diagnosed with CONSUL](/manual-img/5/57363/w960_57363-2368.png)
MWI
SYSTEMMWI-11
< SYSTEM DESCRIPTION > [TYPE A]
C
D
E
F
G H
I
J
K L
M B A
O P
• The combination meter includes an on board diagnosis function.
• The combination meter can be diagnosed with CONSULT.
METER CONTROL FUNCTION LIST
METER SYSTEM : Fail-safeINFOID:0000000012432544
The combination meter activates the fail-safe contro l if CAN communication with each unit is malfunctioning.
System DescriptionReference
Measuring instruments Speedometer
Indicates vehicle speed. MWI-12,
"SPEEDOME-
TER : System De-
scription"
Tachometer
Indicates engine speed. MWI-12, "
TA -
CHOMETER :
System Descrip-
tion"
Shift position indicator
Indicates shift position.MWI-13, "
SHIFT
POSITION INDI-
CATOR : System
Description"
Warning lamp/indicator
lamp
Engine oil pressure warning lamp The warning lamp turns ON or turns OFF,
according to engine hydraulic pressure. MWI-13, "
OIL
PRESSURE
WARNING LAMP
: System Descrip-
tion"
Meter illumination con-
trol
Meter illumination control function
Controls the back light of combination meter. MWI-13, "
METER
ILLUMINATION
CONTROL : Sys-
tem Description"
Information displayOdo/trip meter Indicates mileage.
MWI-14, "
INFOR-
MATION DIS-
PLAY : System
Description"
Engine coolant temperature gauge Indicates engine coolant temperature.
Fuel gaugeIndicates fuel level.
Loose fuel cap warning Indicates loose fuel cap.
Low fuel warning Indicates fuel level.
Trip computer Instant fuel consumption Displays current fuel consumption.
Average fuel consumption Displays average fuel consumption.
Distance to empty Displays distance to empty.
Travel distance
Displays mileage.
Function Specifications
Speedometer Reset to zero by suspending communication.
Tachometer
Illumination control When suspending communication, changes to nighttime mode.
Shift position indicator When suspending communication, not indicate.
Information display Trip com-
puterCurrent fuel consump-
tion
• When reception time of an abnormal signal is 2 seconds or
less, the last received datum is used for calculation to indi-
cate the result.
• When reception time of an abnormal signal is more than two
seconds, the last result calculated during normal condition is
indicated.
Average fuel consump-
tion
Distance to empty
Engine coolant temperature gauge Reset to zero by suspending communication.
Odo/trip meter An indicated value is maintained at communications blackout.
Buzzer The buzzer turns OFF by suspending communication.
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2370 of 3641
![NISSAN NOTE 2016 Service Repair Manual MWI-12
< SYSTEM DESCRIPTION >[TYPE A]
SYSTEM
SPEEDOMETER
SPEEDOMETER : System DescriptionINFOID:0000000012432545
SYSTEM DIAGRAM
DESCRIPTION
The ABS actuator and electric unit (control unit) receives e NISSAN NOTE 2016 Service Repair Manual MWI-12
< SYSTEM DESCRIPTION >[TYPE A]
SYSTEM
SPEEDOMETER
SPEEDOMETER : System DescriptionINFOID:0000000012432545
SYSTEM DIAGRAM
DESCRIPTION
The ABS actuator and electric unit (control unit) receives e](/manual-img/5/57363/w960_57363-2369.png)
MWI-12
< SYSTEM DESCRIPTION >[TYPE A]
SYSTEM
SPEEDOMETER
SPEEDOMETER : System DescriptionINFOID:0000000012432545
SYSTEM DIAGRAM
DESCRIPTION
The ABS actuator and electric unit (control unit) receives each wheel speed sensor signal and provides a vehi-
cle speed signal to the combination meter via CAN communication.
TACHOMETER
TACHOMETER : System DescriptionINFOID:0000000012432546
SYSTEM DIAGRAM
DESCRIPTION
The crank position sensor sends a crankshaft positi
on signal to the ECM. The ECM provides an engine speed
signal to the combination meter via CAN communication lines. The tachometer indicates engine speed in rev-
olutions per minute (rpm).
SHIFT POSITION INDICATOR
Warning lamp/indicator lamp ABS warning lamp
The lamp turns ON by suspending communication.
Slip indicator lamp
Malfunction indicator lamp (MIL)
VDC OFF indicator lamp
EPS warning lamp
Brake warning lamp
High beam indicator lamp
The lamp turns OFF by suspending communication.
Turn signal indicator lamp
Door warning lamp
Light indicator lamp
Engine oil pressure warning lamp
O/D OFF indicator lamp
Function
Specifications
AWNIA2379GB
JSNIA2462GB
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2371 of 3641
![NISSAN NOTE 2016 Service Repair Manual MWI
SYSTEMMWI-13
< SYSTEM DESCRIPTION > [TYPE A]
C
D
E
F
G H
I
J
K L
M B A
O P
SHIFT POSITION INDICATOR : System DescriptionINFOID:0000000012432547
SYSTEM DIAGRAM
DESCRIPTION
The combination meter rec NISSAN NOTE 2016 Service Repair Manual MWI
SYSTEMMWI-13
< SYSTEM DESCRIPTION > [TYPE A]
C
D
E
F
G H
I
J
K L
M B A
O P
SHIFT POSITION INDICATOR : System DescriptionINFOID:0000000012432547
SYSTEM DIAGRAM
DESCRIPTION
The combination meter rec](/manual-img/5/57363/w960_57363-2370.png)
MWI
SYSTEMMWI-13
< SYSTEM DESCRIPTION > [TYPE A]
C
D
E
F
G H
I
J
K L
M B A
O P
SHIFT POSITION INDICATOR : System DescriptionINFOID:0000000012432547
SYSTEM DIAGRAM
DESCRIPTION
The combination meter receives the shift position si gnal from TCM via CAN communication, and displays the
position of the shift indicator.
OIL PRESSURE WARNING LAMP
OIL PRESSURE WARNING LAMP : System DescriptionINFOID:0000000012432548
SYSTEM DIAGRAM
DESCRIPTION
The combination meter turns the engine oil pressure warning lamp ON when receiving a signal from the ECM
via CAN communication.
METER ILLUMINATION CONTROL
METER ILLUMINATION CONTROL : System DescriptionINFOID:0000000012432549
SYSTEM DIAGRAM
DESCRIPTION
• Combination meter controls meter illumination, based on the following signal.
- Position light request signal
• The combination meter turns ON meter illumination when the following conditions are satisfied.
AWNIA3081GB
AWNIA2885GB
JSNIA2919GB
Condition
Combination switch (Lighting switch) 1st or 2nd position
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2372 of 3641
![NISSAN NOTE 2016 Service Repair Manual MWI-14
< SYSTEM DESCRIPTION >[TYPE A]
SYSTEM
• The combination meter turns OFF meter illumination when the following conditions are satisfied.
INFORMATION DISPLAY
INFORMATION DISPLAY : System Descri NISSAN NOTE 2016 Service Repair Manual MWI-14
< SYSTEM DESCRIPTION >[TYPE A]
SYSTEM
• The combination meter turns OFF meter illumination when the following conditions are satisfied.
INFORMATION DISPLAY
INFORMATION DISPLAY : System Descri](/manual-img/5/57363/w960_57363-2371.png)
MWI-14
< SYSTEM DESCRIPTION >[TYPE A]
SYSTEM
• The combination meter turns OFF meter illumination when the following conditions are satisfied.
INFORMATION DISPLAY
INFORMATION DISPLAY : System DescriptionINFOID:0000000012432550
SYSTEM DIAGRAM
DESRIPTION
• The combination meter receives signals from swit
ches, sensors and modules for operating the following
functions on the information display.
- Odo/trip meter
- Engine coolant temperature gauge
- Fuel gauge
- Trip computer
- Interrupt indication
- Meter illumination level
- Low fuel warning
- Loose fuel cap warning
ODO/TRIP METER
The combination meter calculates mileage using the v ehicle speed signal from the ABS actuator and electric
unit (control unit) and displays the mileage on the information display.
ENGINE COOLANT TEMPERATURE GAUGE
The engine coolant temperature gauge indicates the engine coolant temperature.
The ECM provides an engine coolant temperature signal to the combination meter via CAN communication.
FUEL GAUGE
Control Outline
The fuel level sensor unit sends a variable resistor signal to the combination meter. The fuel gauge indicates
the approximate fuel level in the fuel tank.
Refuel Control
The unit detects the driver is refueling the vehicle and accelerates the fuel gauge segment movement if the
fuel level changes by 9 (2-3/8 US, 2 lmp gal) or more.
Condition
Combination switch (Lighting switch) OFF
AWNIA2439GB
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2373 of 3641
MWI
SYSTEMMWI-15
< SYSTEM DESCRIPTION > [TYPE A]
C
D
E
F
G H
I
J
K L
M B A
O P
Lighting segment-resistance relationship
INTERRUPT INDICATION
Low Fuel Warning
The low fuel warning turns ON when the fuel level in t
he fuel tank reaches approximately 7.8 (2-1/8 US gal,
1-3/4 Imp gal).
LOOSE FUEL CAP WARNING
The LOOSE FUEL CAP message will display in the informat ion display when the fuel-filler cap is not tightened
correctly. The message will turn off as soon as the ECM detects the fuel-filler cap is properly tightened. The
ECM provides a loose fuel cap signal to the combination meter via CAN communication lines.
AWNIA3088GB
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2374 of 3641
MWI-16
< SYSTEM DESCRIPTION >[TYPE A]
OPERATION
OPERATION
Switch Name and FunctionINFOID:0000000012432551
JSNIA3909ZZ
Switch name
Operation Description
Illumination control switch (1)
PressAn illuminance level of the back light of the combination meter can be adjusted.
Meter control switch (2) • The information display screen can be switched.
• The trip meter can be switched between A and B.
• Trip meter A/B can be reset by pressing and holding the meter control switch.
• Time can be adjusted.
Revision: August 2015
2016 Versa Note
cardiagn.com
Page 2375 of 3641
![NISSAN NOTE 2016 Service Repair Manual MWI
DIAGNOSIS SYSTEM (COMBINATION METER)MWI-17
< SYSTEM DESCRIPTION > [TYPE A]
C
D
E
F
G H
I
J
K L
M B A
O P
DIAGNOSIS SYSTEM (C OMBINATION METER)
On Board Diagnosis FunctionINFOID:0000000012432552
ON NISSAN NOTE 2016 Service Repair Manual MWI
DIAGNOSIS SYSTEM (COMBINATION METER)MWI-17
< SYSTEM DESCRIPTION > [TYPE A]
C
D
E
F
G H
I
J
K L
M B A
O P
DIAGNOSIS SYSTEM (C OMBINATION METER)
On Board Diagnosis FunctionINFOID:0000000012432552
ON](/manual-img/5/57363/w960_57363-2374.png)
MWI
DIAGNOSIS SYSTEM (COMBINATION METER)MWI-17
< SYSTEM DESCRIPTION > [TYPE A]
C
D
E
F
G H
I
J
K L
M B A
O P
DIAGNOSIS SYSTEM (C OMBINATION METER)
On Board Diagnosis FunctionINFOID:0000000012432552
ON BOARD DIAGNOSIS ITEM
Information display, speedometer and tachometer can be checked in self-diagnosis mode.
STARTING COMBINATION ME TER SELF-DIAGNOSIS MODE
METHOD OF STARTING
1. Turn ignition switch ON, and switch the trip meter to “trip A” or “trip B”.
2. Turn ignition switch to OFF.
3. While pressing the meter control switch (1), turn the ignition
switch ON.
4. Make sure that the trip meter displays “0000.0”.
5. Press the meter control switch (1) at least 3 times. (Within 7 sec- onds after the ignition switch is turned ON).
6. The combination meter is turned to self-diagnosis mode. • All segments of the information display and shift position indi-cator (A) for CVT models are displayed.
NOTE:
• Check combination meter power supply and ground circui t when the self-diagnosis mode of the combination
meter does not start. replace combination meter if power supply and ground circuit are normal.
• If any of the segments are not disp layed, replace combination meter.
7. Each meter activates by pressing the meter control switch.
JSNIA3904ZZ
JSNIA3900ZZ
AWNIA2440ZZ
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2376 of 3641
![NISSAN NOTE 2016 Service Repair Manual MWI-18
< SYSTEM DESCRIPTION >[TYPE A]
DIAGNOSIS SYSTEM (COMBINATION METER)
NOTE:
• If any of the meters or gauges is not activated, replace combination meter.
• The figure is reference.
CONSULT Fu NISSAN NOTE 2016 Service Repair Manual MWI-18
< SYSTEM DESCRIPTION >[TYPE A]
DIAGNOSIS SYSTEM (COMBINATION METER)
NOTE:
• If any of the meters or gauges is not activated, replace combination meter.
• The figure is reference.
CONSULT Fu](/manual-img/5/57363/w960_57363-2375.png)
MWI-18
< SYSTEM DESCRIPTION >[TYPE A]
DIAGNOSIS SYSTEM (COMBINATION METER)
NOTE:
• If any of the meters or gauges is not activated, replace combination meter.
• The figure is reference.
CONSULT Function (METER/M&A)INFOID:0000000012432553
APPLICATION ITEMS
CONSULT can display each diagnostic item
using the diagnostic test modes shown.
SELF DIAG RESULT
Refer to MWI-24, "DTC Index".
DATA MONITOR
Display Item List
X: Applicable
METER/M&A Diagnosis mode Description
Self Diagnostic Result The combination meter self-diagnosis results.
Data Monitor Displays combination meter input/output data in real time.
Work support Supports combination meter diagnosis.
ECU Identification The combination meter part number is displayed.
Warning History Lighting history of the warning lamp and indicator lamp can be checked.
Display item [Unit]MAIN
SIGNALS Description
SPEED METER
[mph] or [km/h] X Displays the value of vehicle speed signal.
SPEED OUTPUT
[mph] or [km/h] X Displays the value of vehicle speed signal, which is transmitted to each unit with CAN communication.
ODO OUTPUT
[Mi] or [km] Displays odometer signal value transmitted to other units via CAN communication.
TACHO METER
[rpm] X Displays the value of engine speed signal, which is input from ECM.
FUEL METER
[L] X Displays the fuel level.
W TEMP METER
[ ° F] or [ °C] X Displays the value of engine coolant temperature signal, which is input from ECM.
ABS W/L
[ON/OFF] Displays [ON/OFF] conditio
n of ABS warning indicator
VDC/TCS IND
[ON/OFF] Displays [ON/OFF] condition
of VDC OFF indicator lamp.
SLIP IND
[ON/OFF] Displays [ON/OFF] condition of SLIP indicator lamp.
BRAKE W/L
[ON/OFF] Displays [ON/OFF] condition of brake warning indicator.
DOOR W/L
[ON/OFF] Displays [ON/OFF] condition of door warning indicator.
HI-BEAM IND
[ON/OFF] Displays [ON/OFF] condition of high beam indicator.
TURN IND
[ON/OFF] Displays [ON/OFF] condition of turn indicator.
LIGHT IND
[ON/OFF] Displays [ON/OFF] condition of light indicator.
OIL W/L
[ON/OFF] Displays [ON/OFF] condition of engine oil pressure warning indicator.
Revision: August 2015
2016 Versa Note
cardiagn.com
