TM-8
< PRECAUTION >[5MT: RS5F91R]
PRECAUTIONS
- Oily dirt:
• Dip a soft cloth into lukewarm water with mild detergent (concentration: within 2 to 3%) and wipe the dirty
area.
• Then dip a cloth into fresh water, wring the water out of the cloth and wipe the detergent off.
• Then rub with a soft, dry cloth.
- Do not use organic solvent such as thinner, benzene, alcohol or gasoline.
- For genuine leather seats, use a genuine leather seat cleaner.
Liquid GasketINFOID:0000000012430939
REMOVAL OF LIQUID GASKET SEALING
• After removing the bolts and nuts, separate the mating surface and remove the liquid gasket using Tool (A).
CAUTION:
Be careful not to damage the mating surfaces.
• In areas where the cutter is difficult to use, use a plastic hammer to lightly tap (1) the cutter where the liquid gasket is applied. Use a
plastic hammer to slide (2) the cutter by tapping on the side.
CAUTION:
Do not damage the mating surfaces.
LIQUID GASKET APPLICATION PROCEDURE
1. Using suitable tool (A), remove old liquid gasket adhering to the liquid gasket application surface and the mating surface.
• Remove liquid gasket completely from the groove of the liquidgasket application surface, mounting bolts, and bolt holes.
2. Wipe the liquid gasket application surface and the mating sur- face with white gasoline (lighting and heating use) to remove
adhering moisture, grease and foreign materials.
3. Attach liquid gasket tube to the suitable tool. Use Genuine Silicone RTV Seal ant, or equivalent. Refer to
GI-22, "
Recommended Chemical Products and Sealants".
4. Apply liquid gasket without gaps to the specified location accord- ing to the specified dimensions.
• If there is a groove for liquid gasket application, apply liquid
gasket to the groove.
• As for bolt holes (B), normally apply liquid gasket inside the holes. Occasionally, it should be applied outside the holes.
Check to read the text of this manual.
• Within five minutes of liquid gasket application, install the mat- ing component.
• If liquid gasket protrudes, wipe it off immediately.
• Do not retighten mounting bolts or nuts after the installation. Tool Number : KV10111100 (J-37228)
AWBIA1249GB
JPBIA0053ZZ
EMA0622D
(A) : Groove
: Inside
JPBIA0010ZZ
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 3250 of 3641
PRECAUTIONSTM-9
< PRECAUTION > [5MT: RS5F91R]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
• After 30 minutes or more have passed from the installation, fill engine oil and engine coolant.
CAUTION:
If there are specific instructions in the procedures contained in this manual concerning liquid gas-
ket application, observe them.
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 3251 of 3641
TM-10
< PREPARATION >[5MT: RS5F91R]
PREPARATION
PREPARATION
PREPARATION
Special Service ToolsINFOID:0000000012430940
The actual shape of the tools may differ from those illustrated here.
Tool number
(TechMate No.)
Tool nameDescription
KV32500QAA
(—)
Drift set Installing differential side oil seal
1. —
Drift
a: 54.3 mm (2.138 in) dia.
b: 45 mm (1.77 in) dia.
c: 26.6 mm (1.047 in) dia.
2. — Drift
d: 54 mm (2.13 in) dia.
e: 48.6 mm (1.913 in) dia.
f: 26.6 mm (1.047 in) dia
KV32300QAC
(—)
Puller Removing 5th main gear
KV32300QAD
(—)
Puller Removing 5th main gear
ST35300000
(—)
Drift • Removing and installing input shaft rear
bearing
• Removing and installing mainshaft rear bearing
a: 45 mm (1.77 in) dia.
b: 59 mm (2.32 in) dia.
K V 111 0 11 S 0
(—)
Va l v e s e a t r e m o v e r Removing mainshaft front bearing
JPDIC0730ZZ
SCIA1781J
SCIA1782J
ZZA0969D
ZZA0872D
Revision: August 2015
2016 Versa Note
cardiagn.com
Page 3252 of 3641
PREPARATIONTM-11
< PREPARATION > [5MT: RS5F91R]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
ST33400001
(—)
Drift Installing mainshaft front bearing
a: 60 mm (2.36 in) dia.
b: 47 mm (1.85 in) dia.
KV40100900
(—)
Drift Installing input shaft front bearing
a: 52 mm (2.05 in) dia.
b: 39.5 mm (1.555 in) dia.
KV32300QAE
(—)
Drift Installing differential side bearing outer race
a: 61.5 mm (2.421 in) dia.
ST33052000
(—)
Drift Removing differential side bearing
a: 22 mm (0.87 in) dia.
b: 28mm (1.10 in) dia.
KV40104920
(—)
Drift Installing differential side bearing
a: 21.7 mm (0.854 in) dia.
b: 44.7 mm (1.760 in) dia.
—
(J-46534)
Trim Tool Set Removing trim components
Tool number
(TechMate No.)
Tool name
Description
ZZA0814D
NT084
JPDIC0635ZZ
ZZA0969D
ZZA0969D
AWJIA0483ZZ
Revision: August 2015
2016 Versa Note
cardiagn.com
Page 3253 of 3641
TM-12
< PREPARATION >[5MT: RS5F91R]
PREPARATION
Commercial Service Tools
INFOID:0000000012430941
Tool name Description
Socket Removing and installing drain plug
a: 8 mm (0.31 in)
b: 5 mm (0.20 in)
Drift Removing input shaft front bearing
a: 38 mm (1.50 in) dia.
Drift Installing bushing
a: 14.5 mm (0.571 in) dia.
Puller • Removing 5th-reverse synchronizer hub
• Removing differential side bearing
Bearing remover Removing bushing
Power tool Loosening nuts, screws and bolts
PCIB1776E
S-NT063
S-NT063
NT077
S-NT134
PIIB1407E
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 3254 of 3641
STRUCTURE AND OPERATIONTM-13
< SYSTEM DESCRIPTION > [5MT: RS5F91R]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
SYSTEM DESCRIPTION
STRUCTURE AND OPERATION
Sectional ViewINFOID:0000000012430942
System DescriptionINFOID:0000000012430943
DOUBLE-CONE SYNCHRONIZER
1. Clutch housing 2. 1st-2nd synchronizer hub assembly 3. 3rd-4th synchronizer hub assembly
4. 5th input gear 5. 5th-reverse synchronizer hub as-
sembly 6. 5th-reverse baulk ring
7. 5th main gear 8. 4th main gear9. 3rd main gear
10. 2nd main gear 11. 2nd double-cone synchronizer 12. 1st double-cone synchronizer
13. 1st main gear 14. Differential side bearing15. Differential
16. Final gear 17. Mainshaft18. Input shaft
JPDIC0580ZZ
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 3255 of 3641
![NISSAN NOTE 2016 Service Repair Manual TM-14
< SYSTEM DESCRIPTION >[5MT: RS5F91R]
STRUCTURE AND OPERATION
Double-cone synchronizers are adopted for 1st and 2nd gears to
reduce operating force of the shift selector.
REVERSE GEAR NOISE PREVE NISSAN NOTE 2016 Service Repair Manual TM-14
< SYSTEM DESCRIPTION >[5MT: RS5F91R]
STRUCTURE AND OPERATION
Double-cone synchronizers are adopted for 1st and 2nd gears to
reduce operating force of the shift selector.
REVERSE GEAR NOISE PREVE](/manual-img/5/57363/w960_57363-3254.png)
TM-14
< SYSTEM DESCRIPTION >[5MT: RS5F91R]
STRUCTURE AND OPERATION
Double-cone synchronizers are adopted for 1st and 2nd gears to
reduce operating force of the shift selector.
REVERSE GEAR NOISE PREVENTION FUNCTION (REVERSE BRAKE)
Description
Soon after the clutch is disengaged, the input shaft is st
ill rotating due to inertia. This may cause a gear noise
when the shift selector is moved to reverse position. The reverse gear noise prevention function stops the
rotation of the input shaft and enables smooth gear shifting when the reverse gear is selected.
Operation Principle
1. When the shift selector is moved to reverse position, 5th-reverse
coupling sleeve (1) slides in the reverse direction. ( )
2. Synchronizer levers (2) with s upport point (A) at 5th-reverse
synchronizer hub (3) presses 5th-reverse baulk ring (4). ( )
3. Friction that is generated at 5-reverse baulk ring presses syn-
chronizer lever on 5th-reverse coupling sleeve. ( )
4. 5th-reverse coupling sleeve that is pressed by synchronizer lever stops the rotation of input shaft.
(1) : Outer baulk ring
(2) : 2nd main gear
(3) : Synchronizer cone
(4) : Inner baulk ring
(5) : 1st main gear
(6) : 1st-2nd coupling sleeve
SCIA7117E
(5) : 5th input gear
JPDIC0415ZZ
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 3256 of 3641
![NISSAN NOTE 2016 Service Repair Manual POSITION SWITCHTM-15
< DTC/CIRCUIT DIAGNOSIS > [5MT: RS5F91R]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
DTC/CIRCUIT DIAGNOSIS
POSITION SWITCH
BACK-UP LAMP SWITCH
BACK-UP LAMP SWITCH : Component InspectionINFOID NISSAN NOTE 2016 Service Repair Manual POSITION SWITCHTM-15
< DTC/CIRCUIT DIAGNOSIS > [5MT: RS5F91R]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
DTC/CIRCUIT DIAGNOSIS
POSITION SWITCH
BACK-UP LAMP SWITCH
BACK-UP LAMP SWITCH : Component InspectionINFOID](/manual-img/5/57363/w960_57363-3255.png)
POSITION SWITCHTM-15
< DTC/CIRCUIT DIAGNOSIS > [5MT: RS5F91R]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
DTC/CIRCUIT DIAGNOSIS
POSITION SWITCH
BACK-UP LAMP SWITCH
BACK-UP LAMP SWITCH : Component InspectionINFOID:0000000012430944
1.CHECK BACK-UP LAMP SWITCH
1. Disconnect position switch connector. Refer to TM-19, "
Removal and Installation".
2. Check continuity between position switch terminals.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace position switch. Refer to TM-19, "
Removal and
Installation".
PARK/NEUTRAL POSITION (PNP) SWITCH
PARK/NEUTRAL POSITION (PNP) SWITCH : Component InspectionINFOID:0000000012430945
1.CHECK PARK/NEUTRAL POSITION (PNP) SWITCH
1. Disconnect position switch connector. Refer to TM-19, "
Removal and Installation".
2. Check continuity between position switch terminals.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace position switch. Refer to TM-19, "
Removal and
Installation".
Terminals Condition Continuity
12 Reverse gear position
Yes
Except reverse gear position No
MCIA0157E
TerminalsCondition Continuity
23 Neutral gear position
Yes
Except neutral gear position No
JPDIC0092ZZ
