3. Adjust the cutoff line height (A) with the aiming adjustment screw so that the distance (X) between the horizontal center line
of front fog lamp (H) and (A) becomes 200 mm (7.87 in).
Front fog lamp light distribution on the screen
• A :Cutoff line
• B :High illuminance
• H :Horizontal center line of front fog lamp
• V :Vertical center line of front fog lamp
• X :Cutoff line height
JPLIA0008ZZ
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 1754 of 3641

EXL-102
< REMOVAL AND INSTALLATION >
FRONT COMBINATION LAMP
REMOVAL AND INSTALLATION
FRONT COMBINATION LAMP
Exploded ViewINFOID:0000000012432832
Removal and InstallationINFOID:0000000012432833
REMOVAL
1. Remove front bumper fascia. Refer to EXT-24, "Removal and Installation".
2. Remove the front combination lamp bolts.
3. Pull front combination lamp forward.
4. Disconnect the harness connectors from front combination lamp and remove.
INSTALLATION
Installation is in the reverse order of removal.
NOTE:
After installation, perform headlamp aiming adjustment procedure. Refer to EXL-98, "
Aiming Adjustment Pro-
cedure".
Bulb ReplacementINFOID:0000000012432834
WARNING:
Do not touch bulb by hand while it is lit or right after being turned off. Burning may result.
CAUTION:
• Do not touch the glass surface of the bulb with bare hands or allow oil or grease to get on it to pre-
vent damage to the bulb.
• Do not leave bulb out of lamp reflector for a long time because dust, moisture smoke, etc. may affect
the performance of lamp. When replacing bulb, be sure to replace it with new one.
HEADLAMP BULB
1. Front fender2. Radiator core upper support 3. Front combination lamp
JMLIA3217GB
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 1755 of 3641
FRONT COMBINATION LAMPEXL-103
< REMOVAL AND INSTALLATION >
C
DE
F
G H
I
J
K
M A
B
EXL
N
O P
Removal
1. Remove plastic cover.
2. Remove bulb from the front combination lamp.
Installation
Installation is in the reverse order of removal.
CAUTION:
After installing the bulb, install the bulb socket securely for watertightness.
SIDE MARKER LAMP BULB
Removal
1. Rotate bulb socket counterclockwise and remove.
2. Remove the bulb from bulb socket.
Installation
Installation is in the reverse order of removal.
CAUTION:
After installing the bulb, install the bulb socket securely for watertightness.
FRONT TURN SIGNAL/PARKING LAMP BULB
Removal
1. Rotate bulb socket counterclockwise and remove.
2. Remove the bulb from bulb socket.
Installation
Installation is in the reverse order of removal.
CAUTION:
After installing the bulb, install the bulb socket securely for watertightness.
Revision: August 2015
2016 Versa Note
cardiagn.com
Page 1756 of 3641
EXL-104
< REMOVAL AND INSTALLATION >
FRONT FOG LAMP
FRONT FOG LAMP
Exploded ViewINFOID:0000000012432835
TYPE 1
TYPE 2
Removal and InstallationINFOID:0000000012432836
REMOVAL
1. Partially remove front fender protector. Refer to EXT-38, "Exploded View".
2. Disconnect the harness connector from front fog lamp.
3. Remove screws and front fog lamp.
INSTALLATION
Installation is in the reverse order of removal.
NOTE:
After installation, perform fog lamp aiming adjustment procedure. Refer to EXL-100, "
Aiming Adjustment Pro-
cedure".
AWLIA2178ZZ
1. Front fog lamp2. Front bumper fasciaA. Front fog lamp bracket
AWLIA2473ZZ
1. Front fog lamp 2. Front bumper fascia3. Front fog lamp finisher
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 1757 of 3641
FRONT FOG LAMPEXL-105
< REMOVAL AND INSTALLATION >
C
DE
F
G H
I
J
K
M A
B
EXL
N
O P
Bulb ReplacementINFOID:0000000012432837
WARNING:
Do not touch bulb by hand while it is lit or right after being turned off. Burning may result.
CAUTION:
• Do not touch the glass surface of the bulb with bare hands or allow oi l or grease to get on it to pre-
vent damage to the bulb.
• Do not leave bulb out of lamp reflector for a long time because dust, moisture smoke, etc. may affect
the performance of lamp. When replacing bulb, be sure to replace it with new one.
REMOVAL
1. Partially remove fender protector. Refer to EXT-38, "Exploded View".
2. Disconnect harness connector (1) from front fog lamp bulb.
3. Rotate the bulb (2) counterclockwise and remove.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
After installing the bulb, install the bulb socket securely for watertightness.
SKIB8304J
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 1758 of 3641
EXL-106
< REMOVAL AND INSTALLATION >
DOOR MIRROR TURN SIGNAL LAMP
DOOR MIRROR TURN SIGNAL LAMP
Removal and InstallationINFOID:0000000012432838
REMOVAL
1. Remove the door mirror rear finisher. Refer to MIR-18, "Removal and Installation".
2. Remove the screws (A) and door mirror turn signal lamp (1).
3. Disconnect the harness connector from the door mirror turn signal lamp and remove.
INSTALLATION
Installation is in the reverse order of removal.
Bulb ReplacementINFOID:0000000012432839
DOOR MIRROR SIDE TURN SIGNAL LAMP
The door mirror side turn signal lamp bulb is integrated into the door mirror side turn signal lamp and is ser-
viced as an assembly. Refer to EXL-106, "
Removal and Installation".
ALLIA1492ZZ
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 1759 of 3641
COMBINATION SWITCHEXL-107
< REMOVAL AND INSTALLATION >
C
DE
F
G H
I
J
K
M A
B
EXL
N
O P
COMBINATION SWITCH
Exploded ViewINFOID:0000000012432840
Removal and InstallationINFOID:0000000012432841
REMOVAL
1. Remove the steering wheel. Refer to ST-8, "Removal and Installation".
2. Remove steering column covers. Refer to IP-17, "
Removal and Installation".
3. Remove the combination switch screws.
4. Disconnect the harness connector from the combination switch.
5. Remove the combination switch by lifting upward.
INSTALLATION
Installation is in the reverse order of removal.
1. Combination switch 2. Combination switch harness
connector
JMMIA0383ZZ
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 1760 of 3641
EXL-108
< REMOVAL AND INSTALLATION >
HAZARD SWITCH
HAZARD SWITCH
Exploded ViewINFOID:0000000012432842
Removal and InstallationINFOID:0000000012432843
REMOVAL
1. Remove cluster lid C. Refer to IP-22, "Removal and Installation".
2. Release pawls and remove hazard switch.
INSTALLATION
Installation is in the reverse order of removal.
1. Cluster lid C
2.Hazard switch
Pawl
