Page 2169 of 3641

NISSAN NOTE 2016 Service Repair Manual INT-18 < REMOVAL AND INSTALLATION > REAR DOOR FINISHER REAR DOOR FINISHER Exploded ViewINFOID:0000000012431862 Removal and InstallationINFOID:0000000012431863 REMOVAL - POWER WINDOW 1. Release rear do

Page 2170 of 3641

NISSAN NOTE 2016 Service Repair Manual REAR DOOR FINISHERINT-19 < REMOVAL AND INSTALLATION > C DE F G H I K L M A B INT N O P 3. Remove screw (B) from power window and door lock/unlock switch (RH) finisher. 4. Remove power window and door

Page 2171 of 3641

NISSAN NOTE 2016 Service Repair Manual INT-20 < REMOVAL AND INSTALLATION > REAR DOOR FINISHER 3. Release the metal clip (A) behind the manual window crank han-dle using a suitable tool (B). Pull the manual window crank han- dle (3) outward

Page 2172 of 3641

NISSAN NOTE 2016 Service Repair Manual BODY SIDE TRIMINT-21 < REMOVAL AND INSTALLATION > C DE F G H I K L M A B INT N O P BODY SIDE TRIM Exploded ViewINFOID:0000000012431864 FRONT PILLAR FINISHER FRONT PILLAR FINISHER : Removal and Install

Page 2173 of 3641

NISSAN NOTE 2016 Service Repair Manual INT-22 < REMOVAL AND INSTALLATION > BODY SIDE TRIM 2. Pull front pillar finisher downward as shown to release the frontpillar finisher clip (bottom). : Clip : Pawl 3. Cut and discard front pillar fini

Page 2174 of 3641

NISSAN NOTE 2016 Service Repair Manual BODY SIDE TRIMINT-23 < REMOVAL AND INSTALLATION > C DE F G H I K L M A B INT N O P 1. Release front kicking plate pawls and metal clip using a suitable tool (A) and remove front kicking plate as shown

Page 2175 of 3641

NISSAN NOTE 2016 Service Repair Manual INT-24 < REMOVAL AND INSTALLATION > BODY SIDE TRIM CAUTION: • Visually check the clips and pawls for deformation and damage during installation. • When installing rear kicking plate, check that cl

Page 2176 of 3641

NISSAN NOTE 2016 Service Repair Manual BODY SIDE TRIMINT-25 < REMOVAL AND INSTALLATION > C DE F G H I K L M A B INT N O P Installation Installation is in the reverse order of removal. CENTER PILLAR LOWER FINISHER CENTER PILLAR LOWER FINISH
