Page 1801 of 3641

NISSAN NOTE 2016 Service Repair Manual EXT-34 < REMOVAL AND INSTALLATION > FRONT SPOILER FRONT SPOILER Exploded ViewINFOID:0000000012432173 TYPE 1 AWKIA2566ZZ 1. Front fascia side deflector (RH) 2. Front air spoiler3. Front fascia side def

Page 1802 of 3641

NISSAN NOTE 2016 Service Repair Manual FRONT SPOILEREXT-35 < REMOVAL AND INSTALLATION > C DE F G H I J L M A B EXT N O P TYPE 2 Removal and InstallationINFOID:0000000012432174 REMOVAL 1. Remove front fascia side deflector screws from each

Page 1803 of 3641

NISSAN NOTE 2016 Service Repair Manual EXT-36 < REMOVAL AND INSTALLATION > COWL TOP COWL TOP Exploded ViewINFOID:0000000012432175 1. Cowl top side cover (RH) 2. Front fender seal (RH) 3. Cowl top extension 4. EPT seal [t: 5.0 mm (0.197 in)

Page 1804 of 3641

NISSAN NOTE 2016 Service Repair Manual COWL TOPEXT-37 < REMOVAL AND INSTALLATION > C DE F G H I J L M A B EXT N O P Removal and InstallationINFOID:0000000012432176 REMOVAL 1. Remove front wiper arms (LH/RH). Refer to WW-63, "Removal and I

Page 1805 of 3641

NISSAN NOTE 2016 Service Repair Manual EXT-38 < REMOVAL AND INSTALLATION > FENDER PROTECTOR FENDER PROTECTOR Exploded ViewINFOID:0000000012432177 Removal and InstallationINFOID:0000000012432178 REMOVAL 1. Remove fender protector screws and

Page 1806 of 3641

NISSAN NOTE 2016 Service Repair Manual UNDER COVEREXT-39 < REMOVAL AND INSTALLATION > C DE F G H I J L M A B EXT N O P UNDER COVER FRONT UNDER COVER FRONT UNDER COVER : Exploded ViewINFOID:0000000012432179 FRONT UNDER COVER : Removal and I

Page 1807 of 3641

NISSAN NOTE 2016 Service Repair Manual EXT-40 < REMOVAL AND INSTALLATION > UNDER COVER Exploded View INFOID:0000000012432181 FLOOR UNDER COVER FLOOR UNDER COVER : Removal and InstallationINFOID:0000000012432182 REMOVAL Remove the rear floo

Page 1808 of 3641

NISSAN NOTE 2016 Service Repair Manual UNDER COVEREXT-41 < REMOVAL AND INSTALLATION > C DE F G H I J L M A B EXT N O P INSTALLATION Installation is in the reverse order of removal. REAR WIND DEFLECTOR REAR WIND DEFLECTOR : Removal and Ins
