2016 NISSAN NOTE warning

ACC-2
< PRECAUTION >
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000012432475
The Supplemental Restraint System such as “A IR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the SR and SB section of
this Service Manual.
WARNING:
• To avoid rendering the SRS inopera tive, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
• Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintent ional activation of the system. For re moval of Spiral Cable and Air Bag
Module, see the SR section.
• Do not use electrical test equipmen t on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harn esses can be identified by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
• When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Igni-
tion ON or engine running, DO NOT use air or electri c power tools or strike near the sensor(s) with a
hammer. Heavy vibration could activate the sensor( s) and deploy the air bag(s), possibly causing
serious injury.
• When using air or electric power tools or hammers , always switch the Ignition OFF, disconnect the
battery and wait at least three minutes before performing any service.
Revision: August 2015 2016 Versa Note

cardiagn.com

AV-6
< PRECAUTION >[BASE AUDIO]
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint Syst
em (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000012432858
The Supplemental Restraint System such as “A IR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the SR and SB section of
this Service Manual.
WARNING:
• To avoid rendering the SRS inopera tive, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
• Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintent ional activation of the system. For re moval of Spiral Cable and Air Bag
Module, see the SR section.
• Do not use electrical test equipmen t on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harn esses can be identified by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
• When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Igni-
tion ON or engine running, DO NOT use air or electri c power tools or strike near the sensor(s) with a
hammer. Heavy vibration could activate the sensor( s) and deploy the air bag(s), possibly causing
serious injury.
• When using air or electric power tools or hammers , always switch the Ignition OFF, disconnect the
battery and wait at least three minutes before performing any service.
Precaution for WorkINFOID:0000000012432859
• When removing or disassembling each component, be careful not to damage or deform it. If a component may be subject to interference, be sure to protect it with a shop cloth.
• When removing (disengaging) components with a screwdriver or similar tool, be sure to wrap the component with a shop cloth or vinyl tape to protect it.
• Protect the removed parts with a shop cloth and prevent them from being dropped.
• Replace a deformed or damaged clip.
• If a part is specified as a non-reusable part, always replace it with a new one.
• Be sure to tighten bolts and nuts securely to the specified torque.
• After installation is complete, be sure to check that each part works properly.
• Follow the steps below to clean components:
- Water soluble dirt:
• Dip a soft cloth into lukewarm water, wring the water out of the cloth and wipe the dirty area.
• Then rub with a soft, dry cloth.
- Oily dirt:
• Dip a soft cloth into lukewarm water with mild detergent (concentration: within 2 to 3%) and wipe the dirty area.
• Then dip a cloth into fresh water, wring the water out of the cloth and wipe the detergent off.
• Then rub with a soft, dry cloth.
- Do not use organic solvent such as thinner, benzene, alcohol or gasoline.
- For genuine leather seats, use a genuine leather seat cleaner.
Revision: August 2015 2016 Versa Note

cardiagn.com

AV-62
< PRECAUTION >[DISPLAY AUDIO]
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint Syst
em (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000012432945
The Supplemental Restraint System such as “A IR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the SR and SB section of
this Service Manual.
WARNING:
• To avoid rendering the SRS inopera tive, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
• Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintent ional activation of the system. For re moval of Spiral Cable and Air Bag
Module, see the SR section.
• Do not use electrical test equipmen t on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harn esses can be identified by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
• When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Igni-
tion ON or engine running, DO NOT use air or electri c power tools or strike near the sensor(s) with a
hammer. Heavy vibration could activate the sensor( s) and deploy the air bag(s), possibly causing
serious injury.
• When using air or electric power tools or hammers , always switch the Ignition OFF, disconnect the
battery and wait at least three minutes before performing any service.
Precaution for Trouble DiagnosisINFOID:0000000012432946
AV COMMUNICATION SYSTEM
• Do not apply voltage of 7.0 V or higher to the measurement terminals.
• Use the tester with its open terminal voltage being 7.0 V or less.
• Be sure to turn ignition switch OFF and disconnect the battery cable from\
the negative terminal before checking the circuit.
Precaution for Harness RepairINFOID:0000000012432947
AV COMMUNICATION SYSTEM
• Solder the repaired parts, and wrap with tape. [Frays of twisted line
must be within 110 mm (4.33 in).]
PKIA0306E
Revision: August 2015 2016 Versa Note

cardiagn.com

AV
SYSTEMAV-69
< SYSTEM DESCRIPTION > [DISPLAY AUDIO]
C
D
E
F
G H
I
J
K L
M B A
O P
SYSTEM
System DescriptionINFOID:0000000012432959
SYSTEM DIAGRAM
AUDIO SYSTEM
The audio system consists of the following components
• Audio unit
• Front door speakers
• Rear door speakers
• Steering wheel audio control switches
• USB interface and AUX in jack
• Antenna base (antenna amp. and satellite antenna)
• Rod antenna
When the audio system is on, AM/FM signals received by the rod antenna are amplified by the antenna amp.
and sent to the audio unit. The audio unit then sends audio signals to the front door speakers and rear door
speakers.
Refer to Owner's Manual for audio system operating instructions.
HANDS-FREE PHONE SYSTEM
• Bluetooth® control is built into the audio unit.
• The connection between cellular phone and the audio unit is performed with Bluetooth
® communication.
• The voice guidance signal is input from the audio unit and output to the front speakers when operating the cellular phone.
When A Call Is Originated
• Spoken voice sound output from the microphone (microphone signal) is input to the audio unit.
• Audio unit outputs to cellular phone with Bluetooth
® communication as a TEL voice signal.
• Voice sound is then heard at the other party.
When Receiving A Call
• Voice sound is input to own cellular phone from the other party.
• TEL voice signal is input to the audio unit by establishing Bluetooth
® communication from cellular phone,
and the signal is output to front speakers.
REAR VIEW MONITOR
Camera Image Operation Principle
• The audio unit supplies power to the rear view camera when receiving a reverse signal.
• The rear view camera transmits camera images to the audio unit.
• The audio unit combines a warning message and fixed guide lines with an image received from the rear view camera.
AWNIA4135GB
Revision: August 2015 2016 Versa Note

cardiagn.com

AV-126
< PRECAUTION >[NAVIGATION]
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint Syst
em (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000012432992
The Supplemental Restraint System such as “A IR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the SR and SB section of
this Service Manual.
WARNING:
• To avoid rendering the SRS inopera tive, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
• Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintent ional activation of the system. For re moval of Spiral Cable and Air Bag
Module, see the SR section.
• Do not use electrical test equipmen t on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harn esses can be identified by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
• When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Igni-
tion ON or engine running, DO NOT use air or electri c power tools or strike near the sensor(s) with a
hammer. Heavy vibration could activate the sensor( s) and deploy the air bag(s), possibly causing
serious injury.
• When using air or electric power tools or hammers , always switch the Ignition OFF, disconnect the
battery and wait at least three minutes before performing any service.
Cautions in Removing Battery Terminal and AV Control Unit (Models with AV Control
Unit)
INFOID:0000000012432993
CAUTION:
Remove battery terminal and AV control unit 30 seconds or more after turning the ignition switch OFF.
NOTE:
After the ignition switch is turned OFF, the AV cont rol unit continues operating for approximately 30 seconds.
Therefore, data corruption may occur if battery voltage is cut off within 30 seconds.
Precaution for Trouble DiagnosisINFOID:0000000012432994
AV COMMUNICATION SYSTEM
• Do not apply voltage of 7.0 V or higher to the measurement terminals.
• Use the tester with its open terminal voltage being 7.0 V or less.
• Be sure to turn ignition switch OFF and disconnect the battery cable from\
the negative terminal before checking the circuit.
Precaution for Harness RepairINFOID:0000000012432995
AV COMMUNICATION SYSTEM
Revision: August 2015 2016 Versa Note

cardiagn.com

AV
AV CONTROL UNITAV-151
< ECU DIAGNOSIS INFORMATION > [NAVIGATION]
C
D
E
F
G H
I
J
K L
M B A
O P
1: Without around view monitor
2: With around view monitor
DTC IndexINFOID:0000000012433019
47
(L) — USB D+ signal
— —— —
48
(R) — USB D
− signal — — — —
49
(Shield) — USB shield
— —— —
50
(B) Ground Antenna amp. ON signal Output ON
AV control unit ON, FM-AM
selected.Battery voltage
51
(B) Ground AM-FM main antenna Input ON AV control unit ON, FM-AM
selected.5.0 V
52
(Shield) —AM-FM main antenna
shield
—— —
—
55
(B) Ground GPS antenna signal Input ON
AV control unit ON, NAV se-
lected.5.0 V
56
(Shield) — GPS antenna shield
— —— —
57
(B) Ground Satellite antenna signal Input ON AV control unit ON, XM se-
lected.
5.0 V
58
(Shield) — Satellite antenna shield — —
——
Te r m i n a l
(Wire color) Description
Condition
Reference value
(Approx.)
+ – Signal nameInput/
Output Ignition
switch Operation
CONSULT Display
Reference Page
U1000: CAN COMM CIRCUIT AV-186, "
AV CONTROL UNIT : DTC Logic"
U1010: CONTROL UNIT (CAN)AV-187, "AV CONTROL UNIT : DTC Logic"
U1200: Cont Unit AV- 1 9 8 , "DTC Logic"
U1217: BLUETOOTH MODULEAV- 1 9 9 , "DTC Logic"
U1229: iPod CERTIFICATIONAV- 2 0 0 , "DTC Logic"
U122F: Digital broadcasting connection errorAV- 2 0 1 , "DTC Logic"
U1244: GPS ANTENNA CONNAV- 2 0 3 , "DTC Logic"
U1258: XM ANTENNA CONNAV- 2 0 4 , "DTC Logic"
U1263: USB OVERCURRENTAV- 2 0 5 , "DTC Logic"
U1264: ANTENNA AMP TERMINALAV- 2 0 6 , "DTC Logic"
U12AA: Configuration ErrorAV- 2 0 7 , "DTC Logic"
U12AC: Display Temperature too High AV- 2 0 8 , "DTC Logic"
U12AD: ECU Temperature too High AV- 2 0 9 , "DTC Logic"
U12AE: Internal Amplifier temperature WarningAV- 2 1 0 , "DTC Logic"
U12AF: CD Mechanism Temperature Warning AV- 2 11 , "DTC Logic"
U12B0: Supply Voltage Goes below 9V > 20sAV- 2 1 2 , "DTC Logic"
U12B1: Supply Voltage Goes High > 16V for 20sAV- 2 1 3 , "DTC Logic"
Revision: August 2015 2016 Versa Note

cardiagn.com

AV-210
< DTC/CIRCUIT DIAGNOSIS >[NAVIGATION]
U12AE AV CONTROL UNIT
U12AE AV CONTROL UNIT
DTC LogicINFOID:0000000012433074
DTC DETECTION LOGIC
CONSULT Display
DTC Detection Condition Possible Cause
Internal Amplifier temperature
Warning
[U12AE] Internal amplifier temperature has exceeded
maximum temperature. Replace AV control unit if malfunction occurs
constantly.
Refer to AV- 2 4 1 , "
Removal and Installation".
Revision: August 2015
2016 Versa Note

cardiagn.com

AV
U12AF AV CONTROL UNITAV-211
< DTC/CIRCUIT DIAGNOSIS > [NAVIGATION]
C
D
E
F
G H
I
J
K L
M B A
O P
U12AF AV CONTROL UNIT
DTC LogicINFOID:0000000012433075
DTC DETECTION LOGIC
CONSULT Display DTC Detection Condition Possible Cause
CD Mechanism Temperature
Warning
[U12AF] CD drive temperature has exceeded maximum
temperature. CD drive is switched OFF to avoid
irreversible
damage. Replace AV control unit if malfunction occurs
constantly.
Refer to
AV- 2 4 1 , "
Removal and Installation".
Revision: August 2015 2016 Versa Note

cardiagn.com
