Page 1521 of 3641
![NISSAN NOTE 2016 Service Repair Manual EC-394
< DTC/CIRCUIT DIAGNOSIS >[HR16DE]
P1720 VSS
P1720 VSS
DescriptionINFOID:0000000012431605
ECM receives two vehicle speed signals via the CAN comm
unication line. One is sent from “ABS actuator NISSAN NOTE 2016 Service Repair Manual EC-394
< DTC/CIRCUIT DIAGNOSIS >[HR16DE]
P1720 VSS
P1720 VSS
DescriptionINFOID:0000000012431605
ECM receives two vehicle speed signals via the CAN comm
unication line. One is sent from “ABS actuator](/manual-img/5/57363/w960_57363-1520.png)
EC-394
< DTC/CIRCUIT DIAGNOSIS >[HR16DE]
P1720 VSS
P1720 VSS
DescriptionINFOID:0000000012431605
ECM receives two vehicle speed signals via the CAN comm
unication line. One is sent from “ABS actuator and
electric unit (control unit)” via combination meter, and the other is from TCM (Transmission control module).
ECM uses these signals for engine control.
DTC LogicINFOID:0000000012431606
DTC DETECTION LOGIC
NOTE:
• If DTC P1720 is displayed with DTC UXXXX, first perform the trouble diagnosis for DTC UXXXX.
• If DTC P1720 is displayed with DTC P0605, first perform the trouble diagno sis for DTC P0605. Refer
to EC-351, "
DTC Logic".
• If DTC P1720 is displayed with DTC P0607, first perform the trouble diagno sis for DTC P0607. Refer
to EC-353, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conducted, always perform the following before conduct-
ing the next test.
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine.
2. Drive vehicle at a speed of 20 km/h (12 MPH) or more for at least 5 seconds without depressing the brake pedal.
3. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Go to EC-394, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000012431607
1.CHECK DTC WITH TCM
Check DTC with TCM. Refer to TM-110, "
DTC Index".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Perform trouble shooting relevant to DTC indicated.
2.CHECK DTC WITH “ABS ACTUATOR A ND ELECTRIC UNIT (CONTROL UNIT)”
Check DTC with “ABS actuator and elec tric unit (control unit)”. Refer to BRC-43, "
DTC Index".
Is the inspection result normal?
DTC No. Trouble diagnosis content DTC detecting condition Possible cause
P1720 Vehicle speed sensor
(TCM output) The difference between two vehicle
speed signals is out of the specified
range. • Harness or connectors
(Secondary speed sensor circuit is open or shorted.)
(Wheel sensor circuit is open or shorted.)
•TCM
• Secondary speed sensor
• ABS actuator and electric unit (control unit)
• Wheel sensor
• Combination meter
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 1522 of 3641
P1720 VSSEC-395
< DTC/CIRCUIT DIAGNOSIS > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
YES >> GO TO 3.
NO >> Perform trouble shooting relevant to DTC indicated.
3.CHECK COMBINATION METER FUNCTION
Check combination meter function. Refer to MWI-24, "
DTC Index".
>> INSPECTION END
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 1523 of 3641
![NISSAN NOTE 2016 Service Repair Manual EC-396
< DTC/CIRCUIT DIAGNOSIS >[HR16DE]
P1805 BRAKE SWITCH
P1805 BRAKE SWITCH
DTC LogicINFOID:0000000012431608
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. T NISSAN NOTE 2016 Service Repair Manual EC-396
< DTC/CIRCUIT DIAGNOSIS >[HR16DE]
P1805 BRAKE SWITCH
P1805 BRAKE SWITCH
DTC LogicINFOID:0000000012431608
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. T](/manual-img/5/57363/w960_57363-1522.png)
EC-396
< DTC/CIRCUIT DIAGNOSIS >[HR16DE]
P1805 BRAKE SWITCH
P1805 BRAKE SWITCH
DTC LogicINFOID:0000000012431608
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Fully depress the brake pedal for at least 5 seconds.
3. Erase DTC.
4. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Go to EC-396, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000012431609
1.CHECK STOP LAMP SWITCH CIRCUIT
1. Turn ignition switch OFF.
2. Check the stop lamp when depressing and releasing the brake pedal.
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 2.
2.CHECK STOP LAMP SWIT CH POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect stop lamp switch harness connector.
3. Check the voltage between stop lamp switch harness connector and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 3.
3.DETECT MALFUNCTIONING PART
Check the following.
• 10 A fuse (No. 30)
• Harness for open or short between stop lamp switch and battery
>> Repair open circuit or short to ground or short to power in harness or connectors.
DTC No. Trouble diagnosis content DTC detecting condition Possible cause
P1805 Brake switch A brake switch signal is not sent to ECM
for extremely long time while the vehicle is
driving. • Harness or connectors
(Stop lamp switch circuit is open or shorted.)
• Stop lamp switch
Brake pedal Stop lamp
Fully released Not illuminated
Slightly depressed Illuminated
Sto p l am p s w it ch
Ground Voltage
Connector Terminal
E57 (M/T)
E13 (CVT) 1
Ground Battery voltage
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 1524 of 3641
![NISSAN NOTE 2016 Service Repair Manual P1805 BRAKE SWITCHEC-397
< DTC/CIRCUIT DIAGNOSIS > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
4.CHECK STOP LAMP SWITCH INPUT SI
GNAL CIRCUIT FOR OPEN AND SHORT
1. Disconnect stop lamp switch harness con NISSAN NOTE 2016 Service Repair Manual P1805 BRAKE SWITCHEC-397
< DTC/CIRCUIT DIAGNOSIS > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
4.CHECK STOP LAMP SWITCH INPUT SI
GNAL CIRCUIT FOR OPEN AND SHORT
1. Disconnect stop lamp switch harness con](/manual-img/5/57363/w960_57363-1523.png)
P1805 BRAKE SWITCHEC-397
< DTC/CIRCUIT DIAGNOSIS > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
4.CHECK STOP LAMP SWITCH INPUT SI
GNAL CIRCUIT FOR OPEN AND SHORT
1. Disconnect stop lamp switch harness connector.
2. Disconnect ECM harness connector.
3. Check the continuity between ECM harness connector and stop lamp switch harness connector.
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair open circuit or short to ground or short to power in harness or connectors.
5.CHECK STOP LAMP SWITCH
Refer to EC-397, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 6.
NO >> Replace brake pedal assembly. Refer to BR-20, "
Removal and Installation".
6.CHECK INTERMITTENT INCIDENT
Refer to GI-42, "
Intermittent Incident".
>> INSPECTION END
Component InspectionINFOID:0000000012431610
1.CHECK STOP LAMP SWITCH-I
1. Turn ignition switch OFF.
2. Disconnect stop lamp switch harness connector.
3. Check the continuity between stop lamp switch terminals under the following conditions.
Is the inspection result normal?
YES >> INSPECTION END
NO >> GO TO 2.
2.CHECK STOP LAMP SWITCH-II
1. Adjust stop lamp switch installation. Refer to BR-21, "
Inspection and Adjustment".
2. Check the continuity between stop lamp switch terminals under the following conditions.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace brake pedal assembly. Refer to BR-20, "
Removal and Installation".
ECM Stop lamp switch
Continuity
Connector Terminal Connector Terminal
E16 99E57 (M/T)
E13 (CVT) 2 Existed
Terminals
ConditionContinuity
1 and 2 Brake pedal Fully released Not existed
Slightly depressed Existed
Terminals
ConditionContinuity
1 and 2 Brake pedal Fully released Not existed
Slightly depressed Existed
Revision: August 2015
2016 Versa Note
cardiagn.com
Page 1525 of 3641
![NISSAN NOTE 2016 Service Repair Manual EC-398
< DTC/CIRCUIT DIAGNOSIS >[HR16DE]
P2096, P2097 A/F SENSOR 1
P2096, P2097 A/F SENSOR 1
DTC LogicINFOID:0000000012431611
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Co NISSAN NOTE 2016 Service Repair Manual EC-398
< DTC/CIRCUIT DIAGNOSIS >[HR16DE]
P2096, P2097 A/F SENSOR 1
P2096, P2097 A/F SENSOR 1
DTC LogicINFOID:0000000012431611
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Co](/manual-img/5/57363/w960_57363-1524.png)
EC-398
< DTC/CIRCUIT DIAGNOSIS >[HR16DE]
P2096, P2097 A/F SENSOR 1
P2096, P2097 A/F SENSOR 1
DTC LogicINFOID:0000000012431611
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conducted, always perform the following procedure
before conducting the next test.
1. Turn ignition switch OFF and wait least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait least 10 seconds.
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is more than 11 at idle.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Clear the mixture ratio self-learning value. Refer to EC-132, "
Description".
2. Turn ignition switch OFF and wait at least 10 seconds.
3. Start engine and keep the engine speed between 3,500 and 4,000 rpm for 1 minute under no load.
4. Let engine idle for 1 minute.
5. Keep engine speed between 2,500 and 3,000 rpm for 20 minutes.
6. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Go to EC-398, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000012431612
1.CHECK GROUND CONNECTION
1. Turn ignition switch OFF.
2. Check ground connection E15. Refer to Ground Inspection in GI-44, "
Circuit Inspection".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace ground connection.
2.RETIGHTEN A/F SENSOR 1 AND HEATED OXYGEN SENSOR 2
Loosen and retighten the A/F sensor 1 and heated oxygen sensor 2. Refer to EM-31, "
Removal and Installa-
tion".
>> GO TO 3.
3.CHECK FOR EXHAUST GAS LEAK
1. Start engine and run it at idle.
DTC No. CONSULT screen terms
(Trouble diagnosis content) DTC detecting condition
Possible Cause
P2096 POST CAT FUEL TRIM SYS
B1
(Post catalyst fuel trim system
too lean bank 1) The output voltage computed by ECM from the A/
F sensor 1 signal is shifts to the lean side for a
specified period.
• A/F sensor 1
• A/F sensor 1 heater
• Heated oxygen sensor 2
• Fuel pressure
• Fuel injector
• Intake air leaks
• Exhaust gas leaks
P2097 POST CAT FUEL TRIM SYS
B1
(Post catalyst fuel trim system
too rich bank 1) The A/F signal computed by ECM from the A/F
sensor 1 signal is shifts to the rich side for a spec-
ified period.
Revision: August 2015
2016 Versa Note
cardiagn.com
Page 1526 of 3641
![NISSAN NOTE 2016 Service Repair Manual P2096, P2097 A/F SENSOR 1EC-399
< DTC/CIRCUIT DIAGNOSIS > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
2. Listen for an exhaust gas leak before the three way catalyst 2.
Is exhaust gas detected?
YES >> Re NISSAN NOTE 2016 Service Repair Manual P2096, P2097 A/F SENSOR 1EC-399
< DTC/CIRCUIT DIAGNOSIS > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
2. Listen for an exhaust gas leak before the three way catalyst 2.
Is exhaust gas detected?
YES >> Re](/manual-img/5/57363/w960_57363-1525.png)
P2096, P2097 A/F SENSOR 1EC-399
< DTC/CIRCUIT DIAGNOSIS > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
2. Listen for an exhaust gas leak before the three way catalyst 2.
Is exhaust gas detected?
YES >> Repair or replace.
NO >> GO TO 4.
4.CHECK FOR INTAKE AIR LEAK
1. Start engine and run it at idle.
2. Listen for an intake air leak after the mass air flow sensor.
Is intake air leak detected?
YES >> Repair or replace.
NO >> GO TO 5.
5.CLEAR THE MIXTURE RATIO SELF-LEARNING VALUE
1. Clear the mixture ratio self-learning value. Refer to EC-132, "
Description".
2. Run engine for at least 10 minutes at idle speed.
Is the 1st trip DTC P0171 or P0172 detected? Is it difficult to start engine?
YES >> Perform trouble diagnosis for DTC P0171or P0172. Refer to EC-248, "DTC Logic" or EC-252,
"DTC Logic".
NO >> GO TO 6.
6.CHECK HARNESS CONNECTOR
1. Turn ignition switch OFF.
2. Disconnect A/F sensor 1 harness connector.
3. Check harness connector for water.
Is the inspection result normal?
YES >> GO TO 7.
NO >> Repair or replace harness connector.
7.CHECK A/F SENSOR 1 POWER SUPPLY CIRCUIT
1. Turn ignition switch ON.
2. Check the voltage between A/F sensor 1 harness connector and ground.
Is the inspection result normal?
YES >> GO TO 9.
NO >> GO TO 8.
8.DETECT MALFUNCTIONING PART
Check the following.
• IPDM E/R harness connector F42
• 20A fuse (No. 53)
• Harness for open or short between A/F sensor 1 and fuse
>> Repair or replace harness or connectors.
9.CHECK A/F SENSOR 1 INPUT SIGNAL CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between A/F sensor 1 harness connector and ECM harness connector.
Water should not exit.
A/F sensor 1
Ground Voltage
Connector Terminal
F12 4 Ground Battery voltage
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 1527 of 3641
![NISSAN NOTE 2016 Service Repair Manual EC-400
< DTC/CIRCUIT DIAGNOSIS >[HR16DE]
P2096, P2097 A/F SENSOR 1
4. Check the continuity between ECM harness connec
tor or A/F sensor 1 harness connector and ground.
5. Also check harness for short NISSAN NOTE 2016 Service Repair Manual EC-400
< DTC/CIRCUIT DIAGNOSIS >[HR16DE]
P2096, P2097 A/F SENSOR 1
4. Check the continuity between ECM harness connec
tor or A/F sensor 1 harness connector and ground.
5. Also check harness for short](/manual-img/5/57363/w960_57363-1526.png)
EC-400
< DTC/CIRCUIT DIAGNOSIS >[HR16DE]
P2096, P2097 A/F SENSOR 1
4. Check the continuity between ECM harness connec
tor or A/F sensor 1 harness connector and ground.
5. Also check harness for short to power.
Is the inspection result normal?
YES >> GO TO 10.
NO >> Repair open circuit or short to ground or short to power in harness or connectors.
10.CHECK A/F SENSOR 1 HEATER
Refer to EC-175, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 11.
NO >> GO TO 13.
11 .CHECK HEATED OXYGEN SENSOR 2
Refer to EC-226, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 12.
NO >> Replace heated oxygen sensor 2. Refer to EX-5, "
Exploded View".
12.CHECK INTERMITTENT INCIDENT
Perform GI-42, "
Intermittent Incident".
Is the inspection result normal?
YES >> GO TO 13.
NO >> Repair or replace.
13.REPLACE AIR FUEL RATIO (A/F) SENSOR 1
Replace air fuel ratio (A/F) sensor 1. Refer to EM-31, "
Removal and Installation".
CAUTION:
• Discard any sensor which has been dropped from a height of more than 0.5 m (19.7 in) onto a hard
surface such as a concrete floor; use a new one.
• Before installing new sensor, cl ean exhaust system threads using oxygen sensor thread cleaner tool
[commercial service tool: (J-43897-18) or (J-43897-12)] and approved anti-seize lubricant (commer-
cial service tool).
Do you have CONSULT?
YES >> GO TO 14.
NO >> GO TO 15.
14.CONFIRM A/F ADJUSTMENT DATA
With CONSULT
1. Turn ignition switch ON.
2. Select “A/F ADJ-B1” in “D ATA MONITOR” mode with CONSULT.
3. Make sure that “0.000” is displayed on CONSULT screen.
Is
“0.000” displayed?
YES >> INSPECTION END
NO >> GO TO 15.
A/F sensor 1 ECM
Continuity
Connector Terminal Connector Terminal
F12 1
F11 49
Existed
25 3
A/F sensor 1 ECM
Ground Continuity
Connector Terminal Connector Terminal
F12 1
F11 49
Ground Not existed
25 3
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 1528 of 3641
P2096, P2097 A/F SENSOR 1EC-401
< DTC/CIRCUIT DIAGNOSIS > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
15.CLEAR THE MIXTURE RATIO SELF-LEARNING VALUE
Clear the mixture ratio self-learning value. Refer to EC-132, "
Description".
Do you have CONSULT?
YES >> GO TO 16.
NO >> INSPECTION END
16.CONFIRM A/F ADJUSTMENT DATA
With CONSULT
1. Turn ignition switch ON.
2. Select “A/F ADJ-B1” in “DATA MONITOR” mode with CONSULT.
3. Make sure that “0.000” is displayed on CONSULT screen.
>> INSPECTION END
Revision: August 2015 2016 Versa Note
cardiagn.com
