NISSAN NOTE 2016 Service Repair Manual EC-434
< DTC/CIRCUIT DIAGNOSIS >[HR16DE]
P219C, P219D, P219E, P219F AIR FUEL RATIO
Without CONSULT
1. Let engine idle.
2. Listen to each fuel injector operating sound.
Is the inspection result normal?

EC-434
< DTC/CIRCUIT DIAGNOSIS >[HR16DE]
P219C, P219D, P219E, P219F AIR FUEL RATIO
Without CONSULT
1. Let engine idle.
2. Listen to each fuel injector operating sound.
Is the inspection result normal?
YES >> GO TO 6.
NO >> Perform trouble diagnosis for fuel injector, refer to EC-
151, "Component Function Check".
6.CHECK FUNCTION OF FUEL INJECTOR-2
CAUTION:
Perform the following procedure in a place with no combustible objects and good ventilation.
1. Turn ignition switch OFF.
2. Confirm that the engine is cooled down and there are no fire hazards near the vehicle.
3. Disconnect all fuel injector harness connectors.
4. Remove fuel tube assembly. Refer to EM-40, "
Removal and Installation".
Keep fuel hose and all fuel injectors connected to fuel tube.
5. Disconnect all ignition coil harness connectors.
6. Prepare pans or saucers under each fuel injector.
7. Crank engine for approximately 3 seconds.
Is the inspection result normal?
YES >> GO TO 7.
NO >> Replace fuel injector. Refer to EM-40, "
Removal and
Installation".
7.CHECK FUNCTION OF IGNITION COIL-1
CAUTION:
Perform the following steps in a well -ventilated area with no combustibles.
1. Turn ignition switch OFF.
2. Remove fuel pump fuse from IPDM E/R to release fuel pressure. NOTE:
CONSULT must not be used to release fuel pressu re. It develops again during the following steps,
if released by using CONSULT.
3. Start the engine.
4. After an engine stall, crank the engine two or three times to release all the fuel pressure.
5. Turn ignition switch OFF.
6. Disconnect all the harness connectors of ignition coil to prevent electric discharge from occurring in igni-
tion coil.
7. Remove ignition coil assembly and spark plug of cylinder. Refer to EM-47, "
Removal and Installation".
8. Crank engine for 5 seconds or more to remove combustion gas in the cylinder.
9. Connect spark plug and harness connector to ignition coil. Clicking noise should be heard.
PBIB3332E
• Fuel should be sprayed evenly for each fuel injector.
• Fuel must not drip from the tip of fuel injector.
PBIA9666J
Revision: August 2015
2016 Versa Note

cardiagn.com

Page 1562 of 3641

NISSAN NOTE 2016 Service Repair Manual P219C, P219D, P219E, P219F AIR FUEL RATIO
EC-435
< DTC/CIRCUIT DIAGNOSIS > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
10. Allow a 13-17mm (0.52-0.66 in) spacing between spark plug and
grounded metal por

P219C, P219D, P219E, P219F AIR FUEL RATIO
EC-435
< DTC/CIRCUIT DIAGNOSIS > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
10. Allow a 13-17mm (0.52-0.66 in) spacing between spark plug and
grounded metal portion as shown in the figure to fix the ignition
coil with a rope or an equivalent.
11. Crank the engine for approximately 3 seconds to see if sparking occurs between spark plug and the grounded metal portion.
CAUTION:
• The discharge voltage becomes 20 kV or higher. There-fore, always stay away from the spark plug and ignition
coil at least 50 cm (19.7 in) during the inspection.
• Leaving a space of more than 17mm (0.66 in) may damage
the ignition coil.
NOTE:
When the gap is less than 13 mm (0.52 in), a the sp ark might be generated even if the coil is mal-
functioning.
Is the inspection result normal?
YES >> GO TO 8.
NO >> GO TO 10.
8.CHECK COMPRESSION PRESSURE
Check compression pressure. Refer to EM-13, "
Inspection".
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-42, "Intermittent Incident".
NO >> Check pistons, piston rings, valves, valve seats and cylinder head gaskets.
9.DETECT MALFUNCTIONING PART
Check fuel hoses and fuel tubes for clogging.
Is the inspection result normal?
YES >> Replace fuel filter and fuel pump assembly. Refer to FL-6, "Exploded View".
NO >> Repair or replace error-detected parts.
10.CHECK FUNCTION OF IGNITION COIL-2
1. Turn ignition switch OFF.
2. Disconnect spark plug and connect a non-malfunctioning spark plug.
3. Crank engine for approximately 3 seconds, and rec heck whether spark is generated between the spark
plug and the grounded metal portion.
Is the inspection result normal?
YES >> GO TO 11.
NO >> Check ignition coil, power transistor and their circuits. Refer to EC-451, "
Component Function
Check".
11 .CHECK SPARK PLUG
Check the initial spark plug for fouling, etc.
Is the inspection result normal?
YES >> 1. Repair or clean spark plug. Refer to EM-47,
"Exploded View".
2. GO TO 12.
NO >> Replace spark plug(s) with standard type one(s). For spark plug type, refer to EM-117, "
Spark Plug".
12.CHECK FUNCTION OF IGNITION COIL-3Spark should be generated.
JMBIA0066GB
Spark should be generated.
SEF156I
Revision: August 2015
2016 Versa Note

cardiagn.com

Page 1563 of 3641

NISSAN NOTE 2016 Service Repair Manual EC-436
< DTC/CIRCUIT DIAGNOSIS >[HR16DE]
P219C, P219D, P219E, P219F AIR FUEL RATIO
1. Reconnect the initial spark plugs.
2. Crank engine for approximately 3 seconds, and rec
heck whether spark is gene

Page 1564 of 3641

NISSAN NOTE 2016 Service Repair Manual ASCD BRAKE SWITCHEC-437
< DTC/CIRCUIT DIAGNOSIS > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
ASCD BRAKE SWITCH
Component Function CheckINFOID:0000000012431635
1.CHECK ASCD BRAKE SWITCH FUNCTION
With CON

Page 1565 of 3641

NISSAN NOTE 2016 Service Repair Manual EC-438
< DTC/CIRCUIT DIAGNOSIS >[HR16DE]
ASCD BRAKE SWITCH
YES >> GO TO 3.
NO >> Repair or replace error-detected parts.
3.CHECK ASCD BRAKE SWITCH
Check the ASCD brake switch. Refer to EC-438, "
Comp

Page 1566 of 3641

NISSAN NOTE 2016 Service Repair Manual CLUTCH PEDAL POSITION SWITCHEC-439
< DTC/CIRCUIT DIAGNOSIS > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
CLUTCH PEDAL POSITION SWITCH
Component Function CheckINFOID:0000000012431638
1.CHECK CLUTCH PEDAL

Page 1567 of 3641

NISSAN NOTE 2016 Service Repair Manual EC-440
< DTC/CIRCUIT DIAGNOSIS >[HR16DE]
CLUTCH PEDAL POSITION SWITCH
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair open circuit or short to ground or short to power in harness or conn

Page 1568 of 3641

NISSAN NOTE 2016 Service Repair Manual COOLING FANEC-441
< DTC/CIRCUIT DIAGNOSIS > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
COOLING FAN
Component Function CheckINFOID:0000000012431641
1.CHECK COOLING FAN FUNCTION
With CONSULT
1. Turn ignit
