Page 1505 of 3641

NISSAN NOTE 2016 Service Repair Manual EC-378
< DTC/CIRCUIT DIAGNOSIS >[HR16DE]
P1554 BATTERY CURRENT SENSOR
Diagnosis Procedure
INFOID:0000000012431588
1.CHECK GROUND CONNECTION
1. Turn ignition switch OFF.
2. Check ground connection E15.

EC-378
< DTC/CIRCUIT DIAGNOSIS >[HR16DE]
P1554 BATTERY CURRENT SENSOR
Diagnosis Procedure
INFOID:0000000012431588
1.CHECK GROUND CONNECTION
1. Turn ignition switch OFF.
2. Check ground connection E15. Refer to Ground Inspection in GI-44, "
Circuit Inspection".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace ground connection.
2.CHECK BATTERY CURRENT SENSO R POWER SUPPLY CIRCUIT
1. Disconnect battery current sensor harness connector.
2. Turn ignition switch ON.
3. Check the voltage between battery current sensor harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair open circuit or sort to ground or short to power in harness or connectors.
3.CHECK BATTERY CURRENT SENSOR GROUND CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between battery current sensor harness connector and ECM harness connector.
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair open circuit or sort to ground or short to power in harness or connectors.
4.CHECK BATTERY CURRENT SENSOR INPUT SIGNAL CIRCUIT FOR OPEN AND SHORT
1. Check the continuity between battery current sensor harness connector and ECM harness connector.
2. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair open circuit or sort to ground or short to power in harness or connectors.
5.CHECK BATTERY CURRENT SENSOR
Refer to EC-379, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 6.
NO >> Replace battery negative cable assembly.
6.CHECK INTERMITTENT INCIDENT
Refer to GI-42, "
Intermittent Incident".
Battery current sensor
Ground Voltage
Connector Terminal
F9 1 Ground Approx. 5V
Battery current sensor ECM Continuity
Connector Terminal Connector Terminal
F9 3 F11 68 Existed
Battery current sensor ECM Continuity
Connector Terminal Connector Terminal
F9 4 F11 58 Existed
Revision: August 2015 2016 Versa Note

cardiagn.com

Page 1506 of 3641

NISSAN NOTE 2016 Service Repair Manual P1554 BATTERY CURRENT SENSOREC-379
< DTC/CIRCUIT DIAGNOSIS > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
>> INSPECTION END
Component InspectionINFOID:0000000012431589
1.CHECK BATTERY CURRENT SENSOR
1. Re

Page 1507 of 3641

NISSAN NOTE 2016 Service Repair Manual EC-380
< DTC/CIRCUIT DIAGNOSIS >[HR16DE]
P1564 ASCD STEERING SWITCH
P1564 ASCD STEERING SWITCH
DTC LogicINFOID:0000000012431590
DTC DETECTION LOGIC
NOTE:
If DTC P1564 is displayed with DTC P0605, firs

EC-380
< DTC/CIRCUIT DIAGNOSIS >[HR16DE]
P1564 ASCD STEERING SWITCH
P1564 ASCD STEERING SWITCH
DTC LogicINFOID:0000000012431590
DTC DETECTION LOGIC
NOTE:
If DTC P1564 is displayed with DTC P0605, first pe
rform the trouble diagnosis for DTC P0605. Refer to
EC-351, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conducted, always perform the following procedure
before conducting the next test.
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Wait at least 10 seconds.
3. Press MAIN switch for at least 10 seconds, then release it and wait at least 10 seconds.
4. Press CANCEL switch for at least 10 seconds, then release it and wait at least 10 seconds.
5. Press ACCEL/RES switch for at least 10 seconds , then release it and wait at least 10 seconds.
6. Press COAST/SET switch for at least 10 seconds , then release it and wait at least 10 seconds.
7. Check DTC.
Is DTC detected?
YES >> Proceed to EC-380, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000012431591
1.CHECK ASCD STEERING SWITCH CIRCUIT
With CONSULT
1. Turn ignition switch ON.
2. Select “MAIN SW”, “CANCEL SW”, “RESUME/ACC SW” and “SET SW” in “DATA MONITOR” mode of
“ENGINE” using CONSULT.
3. Check each item indication as per the following conditions.
DTC No. CONSULT screen terms
(Trouble diagnosis content) DTC detecting condition
Possible cause
P1564 ASCD SW
(ASCD steering switch) • An excessively high voltage signal from the ASCD
steering switch is sent to ECM.
• ECM detects that input signal from the ASCD steering switch is out of the specified range.
• ECM detects that the ASCD steering switch is stuck ON. • Harness or connectors
(ASCD steering switch circuit
is open or shorted.)
• ASCD steering switch
•ECM
Monitor item ConditionIndication
MAIN SW MAIN switchPressed ON
Released OFF
CANCEL SW CANCEL switch Pressed ON
Released OFF
RESUME/ACC SW ACCEL/RES switch Pressed ON
Released OFF
Revision: August 2015
2016 Versa Note

cardiagn.com

Page 1508 of 3641

NISSAN NOTE 2016 Service Repair Manual P1564 ASCD STEERING SWITCHEC-381
< DTC/CIRCUIT DIAGNOSIS > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O Without CONSULT
1. Turn ignition switch ON.
2. Check the voltage between ECM harness connector termi

Page 1509 of 3641

NISSAN NOTE 2016 Service Repair Manual EC-382
< DTC/CIRCUIT DIAGNOSIS >[HR16DE]
P1564 ASCD STEERING SWITCH
Component Inspection
INFOID:0000000012431592
1.CHECK ASCD STEERING SWITCH
1. Disconnect combination switch (spiral cable) harness co

Page 1510 of 3641

NISSAN NOTE 2016 Service Repair Manual P1572 ASCD BRAKE SWITCHEC-383
< DTC/CIRCUIT DIAGNOSIS > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
P1572 ASCD BRAKE SWITCH
DTC LogicINFOID:0000000012431593
DTC DETECTION LOGIC
NOTE:
•
If DTC P1572 is

P1572 ASCD BRAKE SWITCHEC-383
< DTC/CIRCUIT DIAGNOSIS > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
P1572 ASCD BRAKE SWITCH
DTC LogicINFOID:0000000012431593
DTC DETECTION LOGIC
NOTE:
•
If DTC P1572 is displayed with DT C P0605, first perform the trouble diagnosis for DTC P0605. Refer
to EC-351, "
DTC Logic".
• This self-diagnosis has the one trip detection logic. When malfunction A is detected, DTC is not
stored in ECM memory. And in that case, 1st trip DTC and 1st trip freeze frame data are displayed.
1st trip DTC is erased when ignition switch OFF. And even when ma lfunction A is detected in two
consecutive trips, DTC is not stored in ECM memory.
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conducted, always perform the following procedure
before conducting the next test.
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
NOTE:
Procedure for malfunction B is not described here. It take s extremely long time to complete procedure for mal-
function B. By performing procedure for malfunction A, the incident that causes malfunction B can be
detected.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE FOR MALFUNCTION A
1. Start engine.
2. Press MAIN switch and make sure that CRUISE indicator is displayed in combination meter.
3. Drive the vehicle for at least 5 consecut ive seconds as per the following conditions.
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
This procedure may be conducted with the drive wheel s lifted in the shop or by driving the vehicle.
If a road test is expected to be easier , it is unnecessary to lift the vehicle.
4. Check DTC.
Is DTC detected?
YES >> Proceed to EC-388, "Diagnosis Procedure".
NO >> GO TO 3.
3.PERFORM DTC CONFIRMATION PROCEDURE FOR MALFUNCTION B
1. Drive the vehicle for at least 5 consecut ive seconds as per the following conditions.
CAUTION:
DTC No. CONSULT screen terms
(Trouble diagnosis content) DTC detecting condition
Possible cause
P1572 ASCD BRAKE SW
(ASCD brake switch) A)
When the vehicle speed is above 30 km/h
(19 MPH), ON signals from the stop lamp
switch and the ASCD brake switch are
sent to the ECM at the same time. • Harness or connectors
(Stop lamp switch circuit is shorted.)
(ASCD brake switch circuit is shorted.)
• Stop lamp switch
• ASCD brake switch
• Incorrect stop lamp switch installation
• Incorrect ASCD brake switch installation
•ECM
B)
ASCD brake switch signal is not sent to
ECM for extremely long time while the ve-
hicle is driving.
Vehicle speed More than 30 km/h (19 mph)
Selector lever Suitable position
Revision: August 2015
2016 Versa Note

cardiagn.com

Page 1511 of 3641

NISSAN NOTE 2016 Service Repair Manual EC-384
< DTC/CIRCUIT DIAGNOSIS >[HR16DE]
P1572 ASCD BRAKE SWITCH
Always drive vehicle at a safe speed.
NOTE:
This procedure may be conducted with the drive wheel
s lifted in the shop or by driving the

Page 1512 of 3641

NISSAN NOTE 2016 Service Repair Manual P1572 ASCD BRAKE SWITCHEC-385
< DTC/CIRCUIT DIAGNOSIS > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
Is the inspection result normal?
YES >> Check intermittent incident. Refer to
GI-42, "Intermittent Inc
