Page 697 of 3641

NISSAN NOTE 2016 Service Repair Manual DLK-8
HOOD LOCK RELEASE CABLE ............................293
HOOD LOCK RELEASE CABLE : Removal and
Installation .............................................................
293
HOOD LOCK RELEASE H

DLK-8
HOOD LOCK RELEASE CABLE ............................293
HOOD LOCK RELEASE CABLE : Removal and
Installation .............................................................
293
HOOD LOCK RELEASE HANDLE ........................ ..294
HOOD LOCK RELEASE HANDLE : Removal and
Installation ........................................................... ..
294
FRONT DOOR LOCK ......................................295
Exploded View ..................................................... ..295
DOOR LOCK .......................................................... ..295
DOOR LOCK : Removal and Installation ...............295
INSIDE HANDLE .................................................... ..296
INSIDE HANDLE : Removal and Installation .........296
OUTSIDE HANDLE ................................................ ..297
OUTSIDE HANDLE : Removal and Installation .....297
REAR DOOR LOCK ....................................... .299
Exploded View ..................................................... ..299
DOOR LOCK .......................................................... ..299
DOOR LOCK : Removal and Installation ...............299
INSIDE HANDLE .................................................... ..300
INSIDE HANDLE : Removal and Installation .........300
OUTSIDE HANDLE ................................................ ..301
OUTSIDE HANDLE : Removal and Installation .....301
BACK DOOR LOCK ....................................... .303
Exploded View ..................................................... ..303
BACK DOOR LOCK ............................................... .303
BACK DOOR LOCK : Removal and Installation ...303
OUTSIDE HANDLE ................................................ .303
OUTSIDE HANDLE : Removal and Installation ....303
FUEL FILLER LID OPENER ............................305
Exploded View ..................................................... .305
FUEL FILLER LID .................................................. .305
FUEL FILLER LID : Removal and Installation .......305
FUEL FILLER OPENER CABLE ........................... .306
FUEL FILLER OPENER CABLE : Removal and
Installation .............................................................
306
FUEL FILLER LID LOCK ....................................... .306
FUEL FILLER LID LOCK : Removal and Installa-
tion ........................................................................
307
DOOR SWITCH ................................................308
Removal and Installation .......................................308
REMOTE KEYLESS ENTRY RECEIVER ...... ..309
Removal and Installation .......................................309
KEYFOB BATTERY .........................................310
Removal and Installation .......................................310
STEERING LOCK UNIT ...................................311
Exploded View ..................................................... .311
Removal and Installation - Steering lock unit ........311
Removal and Installation - Ignition switch ............ .312
Revision: August 2015 2016 Versa Note

cardiagn.com

Page 698 of 3641

NISSAN NOTE 2016 Service Repair Manual PRECAUTIONSDLK-9
< PRECAUTION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE

PRECAUTIONSDLK-9
< PRECAUTION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000012429960
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severi ty of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the SR and SB section of
this Service Manual.
WARNING:
• To avoid rendering the SRS inoper ative, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
• Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintentional act ivation of the system. For removal of Spiral Cable and Air Bag
Module, see the SR section.
• Do not use electrical test equipm ent on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identi fied by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
• When working near the Airbag Diagnosis Sensor Un it or other Airbag System sensors with the Igni-
tion ON or engine running, DO NOT use air or el ectric power tools or strike near the sensor(s) with a
hammer. Heavy vibration could activate the sensor( s) and deploy the air bag(s), possibly causing
serious injury.
• When using air or electric power tools or hammers, always switch the Ignition OFF, disconnect the
battery and wait at least three mi nutes before performing any service.
Procedure without Cowl Top CoverINFOID:0000000012429961
When performing the procedure after removing cowl top cover, cover
the lower end of windshield with urethane, etc. to prevent damage to
the windshield.
Precaution for Servicing Doors and LocksINFOID:0000000012429962
WARNING:
Radio waves could adversely affect electric medical equipment. Those who use a pacemaker should
contact the electric medical equipment manufacturer for the possible influences before use,
• After removing and installing the opening/closing parts, be sure to carry out fitting adjustments to check their operation.
• Check the lubrication level, damage, and wear of each part. If necessary, grease or replace it.
• When removing or disassembling each component, be ca reful not to damage or deform it. If a component
may be subject to interference, be sure to protect it with a shop cloth.
• When removing (disengaging) components with a screwdriver or similar tool, be sure to wrap the component
with a shop cloth or vinyl tape to protect it.
• Protect the removed parts with a shop cloth and prevent them from being dropped.
• Replace a deformed or damaged clip.
• If a part is specified as a non-reusabl e part, always replace it with a new one.
PIIB3706J
Revision: August 2015 2016 Versa Note

cardiagn.com

Page 699 of 3641

NISSAN NOTE 2016 Service Repair Manual DLK-10
< PRECAUTION >[WITH INTELLIGENT KEY SYSTEM]
PRECAUTIONS
• Be sure to tighten bolts and nuts securely to the specified torque.
• After installation is complete, be sure
to check that each p

DLK-10
< PRECAUTION >[WITH INTELLIGENT KEY SYSTEM]
PRECAUTIONS
• Be sure to tighten bolts and nuts securely to the specified torque.
• After installation is complete, be sure
to check that each part works properly.
• Follow the steps below to clean components:
- Water soluble dirt:
• Dip a soft cloth into lukewarm water, wring the water out of the cloth and wipe the dirty area.
• Then rub with a soft, dry cloth.
- Oily dirt:
• Dip a soft cloth into lukewarm water with mild detergent (concentration: within 2 to 3%) and wipe the dirty area.
• Then dip a cloth into fresh water, wring the water out of the cloth and wipe the detergent off.
• Then rub with a soft, dry cloth.
- Do not use organic solvent such as thinner, benzene, alcohol or gasoline.
- For genuine leather seats, use a genuine leather seat cleaner.
Precaution for WorkINFOID:0000000012918340
• When removing or disassembling each component, be careful not to damage or deform it. If a component may be subject to interference, be sure to protect it with a shop cloth.
• When removing (disengaging) components with a screwdriver or similar tool, be sure to wrap the component with a shop cloth or vinyl tape to protect it.
• Protect the removed parts with a shop cloth and prevent them from being dropped.
• Replace a deformed or damaged clip.
• If a part is specified as a non-reusable part, always replace it with a new one.
• Be sure to tighten bolts and nuts securely to the specified torque.
• After installation is complete, be sure to check that each part works properly.
• Follow the steps below to clean components:
- Water soluble dirt:
• Dip a soft cloth into lukewarm water, wring the water out of the cloth and wipe the dirty area.
• Then rub with a soft, dry cloth.
- Oily dirt:
• Dip a soft cloth into lukewarm water with mild detergent (concentration: within 2 to 3%) and wipe the dirty area.
• Then dip a cloth into fresh water, wring the water out of the cloth and wipe the detergent off.
• Then rub with a soft, dry cloth.
- Do not use organic solvent such as thinner, benzene, alcohol or gasoline.
- For genuine leather seats, use a genuine leather seat cleaner.
Revision: August 2015 2016 Versa Note

cardiagn.com

Page 700 of 3641

NISSAN NOTE 2016 Service Repair Manual PREPARATIONDLK-11
< PREPARATION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
PREPARATION
PREPARATION
Special Service ToolsINFOID:0000000012429963
The actual shape of the tools ma

Page 701 of 3641

NISSAN NOTE 2016 Service Repair Manual DLK-12
< PREPARATION >[WITH INTELLIGENT KEY SYSTEM]
PREPARATION
Commercial Service Tools
INFOID:0000000012429964
KV48105501
(J-45295-A)
Transmitter Activation Tool • Activate TPMS transmitter IDs
�

Page 702 of 3641

NISSAN NOTE 2016 Service Repair Manual COMPONENT PARTSDLK-13
< SYSTEM DESCRIPTION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
SYSTEM DESCRIPTION
COMPONENT PARTS
INTELLIGENT KEY SYSTEM
INTELLIGENT KEY SYSTEM : Compone

Page 703 of 3641

NISSAN NOTE 2016 Service Repair Manual DLK-14
< SYSTEM DESCRIPTION >[WITH INTELLIGENT KEY SYSTEM]
COMPONENT PARTS
A. View with instrument panel assembly
removed B. View with glove box door removed C. View with front grille removed
D. View

DLK-14
< SYSTEM DESCRIPTION >[WITH INTELLIGENT KEY SYSTEM]
COMPONENT PARTS
A. View with instrument panel assembly
removed B. View with glove box door removed C. View with front grille removed
D. View of LH door (RH similar) E. View of LH door switch (RH similar) F. View with rear bumper cover re- moved
G. View from rear of vehicle H. View with rear seat cushion removed I. View with center console removed
No. Component Function
1. Combination meter Combination meter transmits the vehicle speed sig-
nal to BCM via CAN communication.
BCM also receives the vehicle speed signal from
ABS actuator and electric uni
t (control unit) via CAN
communication. BCM compares both signals to de-
tect the vehicle speed.
Security indicator lamp is located on combination
meter.
Security indicator lamp blinks when ignition switch
is in any position other than ON to warn that NIS-
SAN VEHICLE IMMOBILIZER SYSTEM-NATS
[NVIS (NATS)] is on board.
Refer to MWI-59, "
METER SYSTEM : Combination
Meter".
2. Push-button ignition switch Push-button ignition switch has push switch inside
which detects that push-button ignition switch is
pressed, and then transmits ON/OFF signal to
BCM. BCM changes the ignition switch position with
the operation of push-button ignition switch. BCM
maintains the ignition switch position status while
push-button ignition switch is not operated.
3. BCM BCM controls INTELLIGENT KEY SYSTEM (EN-
GINE START FUNCTION), NISSAN VEHICLE IM-
MOBILIZER SYSTEM-NATS [NVIS (NATS)] and
VEHICLE SECURITY SYSTEM.
BCM performs the ID verification between BCM and
Intelligent Key when the Intelligent Key is carried
into the detection area of inside key antenna, and
push-button ignition switch is pressed. If the ID ver-
ification result is OK, ignition switch operation is
available.
Then, when the ignition switch is turned ON, BCM
performs ID verification between BCM and ECM. If
the ID verification result is OK, ECM can start en-
gine.
Refer to BCS-6, "
BODY CONTROL SYSTEM :
Component Parts Location" for detailed installation
location.
4. Main power window and door lock/unlock switch Door lock and unlock switch is integrated into the
main power window and door lock/unlock switch.
Door lock and unlock switch transmits door lock/un-
lock operation signal to BCM.
Refer to PWC-7, "
Main Power Window And Door
Lock/Unlock Switch".
5. Front door lock assembly LH Door key cylinder switch is integrated into front door
lock assembly (driver side).
Door key cylinder switch detects door LOCK/UN-
LOCK operation using mechanical key, and then
transmits the operation signal to BCM.
Refer to DLK-17, "
INTELLIGENT KEY SYSTEM :
Front Door Lock Asse
mbly (Driver Side)".
6. Rear door lock actuator LH Rear door lock actuator locks/unlocks the rear door
latch assembly.
Revision: August 2015
2016 Versa Note

cardiagn.com

Page 704 of 3641

NISSAN NOTE 2016 Service Repair Manual COMPONENT PARTSDLK-15
< SYSTEM DESCRIPTION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
INTELLIGENT KEY SYSTEM : Inside Key Antenna (Instrument Center)INFOID:0000000012429966
•

COMPONENT PARTSDLK-15
< SYSTEM DESCRIPTION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
INTELLIGENT KEY SYSTEM : Inside Key Antenna (Instrument Center)INFOID:0000000012429966
• Inside key antenna (instrument center) detects that Intelligent Key
is within the inside detection area, and then transmits detection
status to BCM.
• Inside key antenna (instrument center) is installed in the rear of cluster lid C of instrument center.
7. Back door lock actuator Back door lock actuator locks/unlocks the back door
latch assembly.
8. Inside key antenna (instrument center) Inside key antenna (instrument center) detects
whether Intelligent Key is inside the vehicle or not,
and then transmits the signal to the BCM.
Refer to
DLK-15, "
INTELLIGENT KEY SYSTEM :
Inside Key Antenna (Instrument Center)".
9. Remote keyless entry receiver Remote keyless entry receiver receives button op-
eration signal and key ID signal of Intelligent Key,
and them transmits them to the BCM.
Refer to
DLK-17, "
INTELLIGENT KEY SYSTEM :
Remote Keyless Entry Receiver".
10. Intelligent Key warning buzzer Intelligent Key warning buzzer warns the user, who
is outside the vehicle, of operation confirmation ac-
cording to Intelligent Key operation and door re-
quest switch operation, or of an inappropriate
operation.
Refer to
DLK-17, "
INTELLIGENT KEY SYSTEM :
Intelligent Key Warning Buzzer".
11. Outside key antenna LH Outside key antenna (LH) detects whether Intelli-
gent Key is outside the vehicle or not, and then
transmits the signal to the BCM.
Refer to
DLK-16, "
INTELLIGENT KEY SYSTEM :
Outside Key Antenna (Driver Side)".
12. Door request switch Door request switch transmits door lock/unlock re-
quest signal to the BCM.
13. Door switch Door switch detects door open/close condition and
then transmits ON/OFF signal to BCM.
14. Outside key antenna (rear bumper) Outside key antenna (Rear bumper) detects wheth-
er Intelligent Key is outside the vehicle or not, and
then transmits the signal to the BCM.
Refer to
DLK-16, "
INTELLIGENT KEY SYSTEM :
Outside Key Antenna (Rear Bumper)".
15. Back door request switch Back door request switch transmits door lock/unlock
request signal to the BCM.
16. Inside key antenna (trunk room) Inside key antenna (trunk room) detects whether In-
telligent Key is inside the vehicle or not, and then
transmits the signal to the BCM.
Refer to
DLK-16, "
INTELLIGENT KEY SYSTEM :
Inside Key Antenna (Trunk Room)".
17. Inside key antenna (console) Inside key antenna (console) detects whether Intel-
ligent Key is inside the vehicle or not, and then
transmits the signal to the BCM.
Refer to
DLK-16, "
INTELLIGENT KEY SYSTEM :
Inside Key Antenna (Console)".
No.
Component Function
JMKIA8646ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

Load next 8 pages

Page: < prev 1-10 ... 665-672 673-680 681-688 689-696 697-704 705-712 713-720 721-728 729-736 ... 3648 next >

ABS change time adblue headlight bulb fuel tank capacity wheel bolts
