Page 1961 of 3641

NISSAN NOTE 2016 Service Repair Manual FRONT DOOR GLASS AND REGULATORGW-21 < REMOVAL AND INSTALLATION > C DE F G H I J L M A B GW N O P FRONT DOOR GLASS AND REGULATOR Exploded ViewINFOID:0000000012430538 Removal and InstallationINFOID:0000

Page 1962 of 3641

NISSAN NOTE 2016 Service Repair Manual GW-22 < REMOVAL AND INSTALLATION > FRONT DOOR GLASS AND REGULATOR 7. Remove front door glass bolts (A). 8. While holding the front door glass, raise it at the rear end andpull it out of the front door

Page 1963 of 3641

NISSAN NOTE 2016 Service Repair Manual FRONT DOOR GLASS AND REGULATORGW-23 < REMOVAL AND INSTALLATION > C DE F G H I J L M A B GW N O P 7. Remove front door glass bolts (A). 8. Raise the front door glass and hold it in place with a suitab

Page 1964 of 3641

NISSAN NOTE 2016 Service Repair Manual GW-24 < REMOVAL AND INSTALLATION > FRONT POWER WINDOW MOTOR FRONT POWER WINDOW MOTOR Removal and InstallationINFOID:0000000012430540 REMOVAL 1. Remove front door glass regulator. Refer to GW-21, "Remo

Page 1965 of 3641

NISSAN NOTE 2016 Service Repair Manual REAR DOOR GLASS AND REGULATORGW-25 < REMOVAL AND INSTALLATION > C DE F G H I J L M A B GW N O P REAR DOOR GLASS AND REGULATOR Exploded ViewINFOID:0000000012430541 Removal and InstallationINFOID:000000

Page 1966 of 3641

NISSAN NOTE 2016 Service Repair Manual GW-26 < REMOVAL AND INSTALLATION > REAR DOOR GLASS AND REGULATOR 5. Remove rear door glass bolts (A) and rear door glass (1). 6. Remove rear door glass front run bolts and remove (if necessary). 7. Re

Page 1967 of 3641

NISSAN NOTE 2016 Service Repair Manual REAR DOOR GLASS AND REGULATORGW-27 < REMOVAL AND INSTALLATION > C DE F G H I J L M A B GW N O P If a malfunction is detect ed, replace or grease it. The arrows in the figure show the application point

Page 1968 of 3641

NISSAN NOTE 2016 Service Repair Manual GW-28 < REMOVAL AND INSTALLATION > REAR POWER WINDOW MOTOR REAR POWER WINDOW MOTOR Removal and InstallationINFOID:0000000012430543 REMOVAL 1. Remove rear door glass regulator. Refer to GW-25, "Removal
