NISSAN NOTE 2016 Service Repair Manual EC-402
< DTC/CIRCUIT DIAGNOSIS >[HR16DE]
P2100, P2103 THROTTLE
CONTROL MOTOR RELAY
P2100, P2103 THROTTLE CONTROL MOTOR RELAY
DTC LogicINFOID:0000000012431613
DTC DETECTION LOGIC
DTC CONFIRMATION PROC

EC-402
< DTC/CIRCUIT DIAGNOSIS >[HR16DE]
P2100, P2103 THROTTLE
CONTROL MOTOR RELAY
P2100, P2103 THROTTLE CONTROL MOTOR RELAY
DTC LogicINFOID:0000000012431613
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conducted, always perform the following before conduct-
ing the next test.
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the following procedure, co nfirm that battery voltage is more than 8 V.
Witch DTC is detected?
P2100 >> GO TO 2.
P2103 >> GO TO 3.
2.PERFORM DTC CONFIRMATION PROCEDURE FOR DTC P2100
1. Turn ignition switch ON and wait at least 2 seconds.
2. Start engine and let it idle for 5 seconds.
3. Check DTC.
Is DTC detected?
YES >> Go to EC-402, "Diagnosis Procedure".
NO >> INSPECTION END
3.PERFORM DTC CONFIRMATION PROCEDURE FOR DTC P2103
1. Turn ignition switch ON and wait at least 1 second.
2. Check DTC.
Is DTC detected?
YES >> Go to EC-402, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000012431614
1.CHECK THROTTLE CONTROL MOTOR RELAY POWER SUPPLY CIRCUIT-I
1. Turn ignition switch OFF.
2. Check voltage between ECM harness connector and ground.
Is the inspection result normal?
YES >> GO TO 5.
NO >> GO TO 2.
DTC No. Trouble diagnosis content DTC detecting condition Possible cause
P2100 Throttle control motor relay
circuit open ECM detects a voltage of power source for
throttle control moto
r is excessively low. • Harness or connectors
(Throttle control motor relay circuit is open)
• Throttle control motor relay
P2103 Throttle control motor relay
circuit short ECM detect the throttle control motor relay
is stuck ON. • Harness or connectors
(Throttle control motor re lay circuit is shorted)
• Throttle control motor relay
ECM
Voltag e
+ −
Connector Terminal Connector Terminal F10 15 E16 108 Battery voltage
Revision: August 2015 2016 Versa Note

cardiagn.com

Page 1530 of 3641

NISSAN NOTE 2016 Service Repair Manual P2100, P2103 THROTTLE CONTROL MOTOR RELAYEC-403
< DTC/CIRCUIT DIAGNOSIS > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
2.CHECK THROTTLE CONTROL MOTOR
RELAY INPUT SIGNAL CIRCUIT-I
1. Disconnect ECM harnes

Page 1531 of 3641

NISSAN NOTE 2016 Service Repair Manual EC-404
< DTC/CIRCUIT DIAGNOSIS >[HR16DE]
P2100, P2103 THROTTLE
CONTROL MOTOR RELAY
7.DETECT MALFUNCTIONING PART
Check the following.
• IPDM E/R connector F42
• Harness for open or short between I

Page 1532 of 3641

NISSAN NOTE 2016 Service Repair Manual P2101 ELECTRIC THROTTLE CONTROL FUNCTIONEC-405
< DTC/CIRCUIT DIAGNOSIS > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
P2101 ELECTRIC THROTTLE CONTROL FUNCTION
DTC LogicINFOID:0000000012431615
DTC DETECTIO

Page 1533 of 3641

NISSAN NOTE 2016 Service Repair Manual EC-406
< DTC/CIRCUIT DIAGNOSIS >[HR16DE]
P2101 ELECTRIC THROTTLE CONTROL FUNCTION
Is the inspection result normal?
YES >> GO TO 11.
NO >> GO TO 3.
3.CHECK THROTTLE CONTROL MOTOR
RELAY POWER SUPPLY CI

Page 1534 of 3641

NISSAN NOTE 2016 Service Repair Manual P2101 ELECTRIC THROTTLE CONTROL FUNCTIONEC-407
< DTC/CIRCUIT DIAGNOSIS > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
4. Also check harness for short to ground and short to power.
Is the inspection result

Page 1535 of 3641

NISSAN NOTE 2016 Service Repair Manual EC-408
< DTC/CIRCUIT DIAGNOSIS >[HR16DE]
P2101 ELECTRIC THROTTLE CONTROL FUNCTION
2. Check if foreign matter is caught between the throttle valve and
the housing.
Is the inspection result normal?
YES

Page 1536 of 3641

NISSAN NOTE 2016 Service Repair Manual P2118 THROTTLE CONTROL MOTOREC-409
< DTC/CIRCUIT DIAGNOSIS > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
P2118 THROTTLE CONTROL MOTOR
DTC LogicINFOID:0000000012431618
DTC DETECTION LOGIC
DTC CONFIRMATION
