PARKING BRAKE SYSTEM
PERIODIC MAINTENANCE
PARKING BRAKE SYSTEM
Inspection and AdjustmentINFOID:0000000012430688
INSPECTION
Parking Brake Control Stroke
1. When parking brake control is operated with a force of 196 N(20.0 kg-f, 44.1 lb-f), make sure parking brake control stroke is
within the specified number of notches. (Check by listening and
counting the number of ratchet clicks.)
2. Check that the parking brake lamp illuminates, after parking brake has been operated to the specified number of notches.
Inspect Components
• Check the parking brake components for bends, wear and or damage. Replace if any damage is noted.
• Check that the parking brake operates properly ; be sure that it is not bound up or sticking.
• Check that the brake warning light illuminates afte r parking brake has been operated to the specified number
of notches. Refer to PB-10, "
Parking Brake Control".
• Inspect and adjust the rear brakes if necessary. Refer to BR-43, "
Inspection and Adjustment".
ADJUSTMENT
1. Pull parking brake control (1) until the access hole (2) is visible.
Use suitable tool to adjust nut (A).
2. Turn adjusting nut (A) using suitable tool to loosen the front cable.
3. Depress the brake pedal with a force of 196 N (20. 0 kg-f, 44.1 lb-f) about 10 times and adjust the brake
shoe clearance.
4. Adjust the cable with the following procedure. CAUTION:Number of
notches
: Refer to PB-10, "
Parking Brake
Control".
Number of
notches : Refer to PB-10, "
Parking Brake
Control".
WFIA0508E
AWFIA1013ZZ
Revision: August 2015
2016 Versa Note
cardiagn.com
Page 2498 of 3641
PARKING BRAKE SYSTEMPB-5
< PERIODIC MAINTENANCE >
C
DE
G H
I
J
K L
M A
B
PB
N
O P
To prevent damage to parts, do not bend the parking brake cables.
a. Adjust the parking brake lever stroke by turning the adjusting nut using suitable tool.
CAUTION:
Do not reuse the adjusting nut if the nut is removed.
b. Operate the parking brake lever with a force of 196 N (20.0 kg-f, 44.1lb-f). Check that the lever stroke is
within the specified number of notches. (Check by li stening and counting the number of the ratchet clicks.)
Number of notches : Refer to PB-10, "
Parking Brake Control".
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2499 of 3641

PB-6
< REMOVAL AND INSTALLATION >
PARKING BRAKE CONTROL
REMOVAL AND INSTALLATION
PARKING BRAKE CONTROL
Exploded ViewINFOID:0000000012430689
Removal and InstallationINFOID:0000000012430690
REMOVAL
1. Remove the center console assembly. Refer to IP-18, "Removal and Installation".
2. Remove the adjusting nut. CAUTION:
Do not reuse the adjusting nut.
3. Separate the parking brake front cable fr om the parking brake rear cables (RH/LH).
4. Disconnect the harness connector fr om the parking brake switch.
5. Remove the screw and remove the parking brake switch.
6. Remove the nuts and remove the parking brake control.
INSTALLATION
Installation is in the reverse order of the removal.
CAUTION:
• Replace the parking brake control if it h as been dropped or sustained an impact.
• Replace the parking brake switch if it h as been dropped or sustained an impact.
• Do not reuse the adjusting nut.
Inspect and adjust the parking brake. Refer to PB-4, "
Inspection and Adjustment".
1. Parking brake control2. Adjusting nut3. Parking brake switch
4. Parking brake front cable 5. Parking brake rear cable (LH) 6. Parking brake rear cable (RH)
JPFIB0133GB
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2500 of 3641
PARKING BRAKE CABLEPB-7
< REMOVAL AND INSTALLATION >
C
DE
G H
I
J
K L
M A
B
PB
N
O P
PARKING BRAKE CABLE
Removal and InstallationINFOID:0000000012430691
REMOVAL
1. Remove the center console assembly. Refer to IP-18, "Removal and Installation".
2. Remove the adjusting nut. Refer to PB-6, "
Exploded View".
3. Separate the parking brake front cable from parking brake rear cables (RH/LH). Refer to PB-6, "
Exploded
View".
CAUTION:
To prevent damage to the parts, do not bend the parking brake cables.
4. Remove the parking brake front cable.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
Do not reuse the adjusting nut.
• Inspect and adjust the parking brake. Refer to PB-4, "
Inspection and Adjustment".
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2501 of 3641

PB-8
< REMOVAL AND INSTALLATION >
PARKING BRAKE REAR CABLE
PARKING BRAKE REAR CABLE
Removal and InstallationINFOID:0000000012430692
REMOVAL
1. Remove the center console assembly. Refer to IP-18, "Removal and Installation".
2. Loosen the adjusting nut. Refer to PB-6, "
Exploded View".
NOTE:
It is not necessary to remove the parking brake front cable.
3. Separate the parking brake rear cables (RH/LH ) from the parking brake front cable. Refer to PB-6,
"Exploded View".
4. Remove the rear wheels and tires using power tool. Refer to WT-48, "
Exploded View".
5. Remove rear wheel sensors. Refer to BRC-143, "
REAR SENSOR ROTOR : Removal and Installation".
6. Remove the rear drum brake components. Refer to BR-41, "
Removal and Installation".
CAUTION:
Do not separate the brake tube from the wheel cylinders.
7. Remove the center muffler. Refer to EX-5, "
Exploded View".
8. Remove nuts (A) and remove center floor insulators.
9. Remove the bolts and remove the parking brake rear cables (RH/LH). CAUTION:
Do not excessively bend the parking brake cables.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
Do not reuse the adjusting nut if the nut is removed.
• Inspect and adjust the rear brakes. Refer to BR-43, "
Inspection and Adjustment".
• Inspect and adjust the parking brake. Refer to PB-4, "
Inspection and Adjustment".
ALBIA1147ZZ
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2502 of 3641
PARKING BRAKE SWITCHPB-9
< REMOVAL AND INSTALLATION >
C
DE
G H
I
J
K L
M A
B
PB
N
O P
PARKING BRAKE SWITCH
Removal and InstallationINFOID:0000000012430693
REMOVAL
1. Remove the center console assembly. Refer to PB-6, "Exploded View".
2. Disconnect the harness connector from the parking brake switch. Refer to PB-6, "
Exploded View".
3. Remove the screw and remove the parking brake switch. Refer to PB-6, "
Exploded View".
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
Replace the parking brake switch if it has been dropped or sustained an impact.
Adjust the parking brake cable if necessary. Refer to PB-4, "
Inspection and Adjustment".
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2503 of 3641
PB-10
< SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
Parking Brake ControlINFOID:0000000012430694
ItemStandard
Number of notches [under force of 196 N (20.0 kg-f, 44.1 lb-f)] 11 − 12 notches
Number of notches when brake warning light illuminates 1 notch
Revision: August 20152016 Versa Note
cardiagn.com
Page 2504 of 3641
