AV-140
< SYSTEM DESCRIPTION >[NAVIGATION]
SYSTEM
Front view guiding lines
Rear View• The rear view image improves the visibility of obstacles in the rear of the vehicle and assists backing and
parking by displaying images from birds-eye view and front side view.
• The rear view image displays the vehicle width guiding line and vehicle distance guiding line, in addition to the predictive course line according to the steering angle.
NOTE:
The predictive course line is not di splayed at the steering neutral position.
• The around view monitor control unit receives the steering angle signal from steering angle sensor via CAN
communication, and controls the direction and distance of the predictive course line.
• ON/OFF setting of predictive course line can be performed using CONSULT.
Rear view guiding lines
Front-Side View• The front-side view image improves the visibility of ob stacles in the front RH side of the vehicle and assists
backing and parking.
• The front-side view image displays the vehicle distance guiding line and vehicle width guiding line.
JSNIA0770GB
JSNIA4567GB
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 146 of 3641
AV
SYSTEMAV-141
< SYSTEM DESCRIPTION > [NAVIGATION]
C
D
E
F
G H
I
J
K L
M B A
O P
Front-side view area and guiding line
Birds-Eye View• The birds-eye view image improves the visibility of obstacles all around the vehicle and assists backing and
parking.
• The images from the four cameras are converted in to an overhead view, and the surroundings of the vehicle
are displayed.
• The blind spot area is displayed on the image to specify the boundary of the four cameras.
Birds-Eye view display image
JSNIA0771GB
AWNIA3141GB
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 147 of 3641
AV-142
< SYSTEM DESCRIPTION >[NAVIGATION]
SYSTEM
Birds-Eye view display area
AWNIA3142GB
Revision: August 2015
2016 Versa Note
cardiagn.com
Page 148 of 3641
![NISSAN NOTE 2016 Service Repair Manual AV
DIAGNOSIS SYSTEM (AV CONTROL UNIT)AV-143
< SYSTEM DESCRIPTION > [NAVIGATION]
C
D
E
F
G H
I
J
K L
M B A
O P
DIAGNOSIS SYSTEM (AV CONTROL UNIT)
DescriptionINFOID:0000000012433014
The AV control unit NISSAN NOTE 2016 Service Repair Manual AV
DIAGNOSIS SYSTEM (AV CONTROL UNIT)AV-143
< SYSTEM DESCRIPTION > [NAVIGATION]
C
D
E
F
G H
I
J
K L
M B A
O P
DIAGNOSIS SYSTEM (AV CONTROL UNIT)
DescriptionINFOID:0000000012433014
The AV control unit](/manual-img/5/57363/w960_57363-147.png)
AV
DIAGNOSIS SYSTEM (AV CONTROL UNIT)AV-143
< SYSTEM DESCRIPTION > [NAVIGATION]
C
D
E
F
G H
I
J
K L
M B A
O P
DIAGNOSIS SYSTEM (AV CONTROL UNIT)
DescriptionINFOID:0000000012433014
The AV control unit on board diagnosis performs the functions listed in the table below:
Perform CONSULT diagnosis if the AV control unit on board diagnosis does not start or the screen does not
display anything.
On Board Diagnosis FunctionINFOID:0000000012433015
METHOD OF STARTING
1. Turn the ignition ON.
2. Turn the audio system OFF.
Mode ItemContent
Ve r s i o n —Version data of the AV control unit is dis-
played.
User Configuration Touch Display Calibration
—Calibration of the touch panel display
can be performed.
Screenshot to USB —A screenshot of the display can be
saved to USB memory.
Time Interval —Destination time interval can be select-
ed.
Radio FM monitor
—
Monitors the dynamic values of the cur-
rent tuner
AM monitor —
SXM monitor —Version data is displayed.
System State Running System Status • SD card slot acces.
• Power Supply
• Speed Signal
• Direction Signal
• Illumination Signal
• GPS Antenna
• GPS tracking
• Satellites visible
• Satellites tracked
• Microphone Current
• Steer. wheel key
• Radio Antenna
• SXM Antenna
• USB Device
• iPod firmware ver.
• BT Status The current system status is displayed.
Sp ea ke r Tes t 4 kH z —This activates a sequence of test tone
outputs to the audio circuits one after the
other for 1 second.
Speaker Test 100Hz
Display-Test
—This provides a test sequence where
test displays (plain colored display: e.g.
white, black, red, blue, green) are shown
one after the other.
The respective color is shown for an in-
dicated period of time (parameter). After
the display test, the design of the display
previously available is stored. While the
screen shows a plain colored display, a
pixel malfunction may be detected.
Self Test • SD Card Access
• BT Module Access
• GPS Antenna
• Radio Antenna
• SXM Antenna A system self test is executed and the
results are stored into the error memory.
Revision: August 2015
2016 Versa Note
cardiagn.com
Page 149 of 3641
![NISSAN NOTE 2016 Service Repair Manual AV-144
< SYSTEM DESCRIPTION >[NAVIGATION]
DIAGNOSIS SYSTEM (AV CONTROL UNIT)
3. While pressing the APPS button, turn the TUNE dial counter-
clockwise 5 or more clicks, then clockwise 5 or more clicks, NISSAN NOTE 2016 Service Repair Manual AV-144
< SYSTEM DESCRIPTION >[NAVIGATION]
DIAGNOSIS SYSTEM (AV CONTROL UNIT)
3. While pressing the APPS button, turn the TUNE dial counter-
clockwise 5 or more clicks, then clockwise 5 or more clicks,](/manual-img/5/57363/w960_57363-148.png)
AV-144
< SYSTEM DESCRIPTION >[NAVIGATION]
DIAGNOSIS SYSTEM (AV CONTROL UNIT)
3. While pressing the APPS button, turn the TUNE dial counter-
clockwise 5 or more clicks, then clockwise 5 or more clicks, then
counterclockwise 5 or more clicks. Shifting from current screen
to previous screen is performed by pressing BACK button.
4. The trouble diagnosis initial screen is displayed, and Version, User Configuration, Radio, Syst em State or Self Test can be
