DIAGNOSIS SYSTEM (COMBINATION METER)MWI-19
< SYSTEM DESCRIPTION > [TYPE A]
C
D
E
F
G H
I
J
K L
M B A
O P
NOTE:
Some items are not available according to vehicle specification.
WORK SUPPORT
WARNING

MWI
DIAGNOSIS SYSTEM (COMBINATION METER)MWI-19
< SYSTEM DESCRIPTION > [TYPE A]
C
D
E
F
G H
I
J
K L
M B A
O P
NOTE:
Some items are not available according to vehicle specification.
WORK SUPPORT
WARNING HISTORY
W/L ON HISTORY
• Stores histories when warning/indicator lamp is turned on.
• “W/L ON HISTORY” indicates the “TIME” when the warning/ indicator lamp is turned on.
• The “TIME” above is:
- 0: The condition that the warning/indicator lamp has been turned on 1 or more times after starting the engine and waiting for 30 seconds.
- 1 - 39: The number of times the engi ne was restarted after the 0 condition.
MIL
[ON/OFF] Displays [ON/OFF] condition of malfunction indicator.
CRUISE IND
[Off] Displays [ON/OFF]
condition of CRUISE indicator.
O/D OFF IND
[ON/OFF] Displays [ON/OFF] condition of O/D OFF indicator.
FUEL W/L
[ON/OFF] Displays [ON/OFF] condition of low-fuel warning indicator.
AIR PRES W/L
[ON/OFF] Displays [ON/OFF] condition of tire pressure warning lamp.
EPS W/L
[ON/OFF] Displays [ON/OFF] condition of EPS indicator.
CHG SIG
[On/Off] Displays [ON/OFF] condition of charge warning indicator.
PASS BUCKLE
SW
[ON/OFF] Status of seat belt buckle switch RH.
FUEL CAP W/L
[Off] Displays [ON/OFF] condition of loose fuel cap warning message.
PKB SW
[ON/OFF] Status of parking brake switch.
BUCKLE SW
[ON/OFF] Status of seat belt buckle switch LH.
BRAKE OIL SW
[ON/OFF] Status of brake fluid level switch.
DISTANCE
[M] or [Mi] Displays distance to empty.
FUEL LOW SIG
[ON/OFF] Displays [ON/OFF] condition
of low-fuel warning signal.
BUZZER
[ON/OFF] X Displays [ON/OFF] condition of buzzer.
TPMS PRESS L
[ON/OFF] Displays [ON/OFF] condition of check tire pressure warning message.
Display item [Unit]
MAIN
SIGNALS Description
Work support item
Description
Fuel meter diagnosis(Analog pointer) A possible malfunction can be narrowed down by following the displayed instructions.
Warning lamp diagnosis
Display item Description
W/L ON HISTORY Lighting history of warning lamp and indicator lamp can be checked.
Revision: August 2015 2016 Versa Note

cardiagn.com

Page 2378 of 3641

NISSAN NOTE 2016 Service Repair Manual MWI-20
< SYSTEM DESCRIPTION >[TYPE A]
DIAGNOSIS SYSTEM (COMBINATION METER)
- NO W/L ON HISTORY: Stores NO (0) turning on history of warning/indicator lamp.
NOTE:
• W/L ON HISTORY is not stored for a

Page 2379 of 3641

NISSAN NOTE 2016 Service Repair Manual MWI
COMBINATION METERMWI-21
< ECU DIAGNOSIS INFORMATION > [TYPE A]
C
D
E
F
G H
I
J
K L
M B A
O P
ECU DIAGNOSIS INFORMATION
COMBINATION METER
Reference ValueINFOID:0000000012432554
VALUES ON THE DIAGNO

MWI
COMBINATION METERMWI-21
< ECU DIAGNOSIS INFORMATION > [TYPE A]
C
D
E
F
G H
I
J
K L
M B A
O P
ECU DIAGNOSIS INFORMATION
COMBINATION METER
Reference ValueINFOID:0000000012432554
VALUES ON THE DIAGNOSIS TOOL
Monitor Item Display content Data monitor
Condition Reference value in normal
operation
SPEED METER
[mph or km/h] Speed meter operation While driving Vehicle speed matches
speed meter
SPEED OUTPUT
[mph or km/h] Vehicle speed
While driving The speed output signal val-
ue via CAN communication
is approx. value of vehicle
speed.
ODO OUTPUT
[mi or km] ODO meter operation
Driving Distance driven
TACHO METER
[rpm] Tacho meter operation Engine running The tacho meter is approx.
value of engine speed via
CAN communication.
FUEL METER
[L] Fuel level
Ignition ON Fuel level is approx. value of
fuel gauge.
W TEMP METER
[ ° F] or [° C] Engine coolant temperature Engine running Input value of engine coolant
temperature signal via CAN
communication.
ABS W/L ABS warning lamp When ABS warning lamp is ON
On
When ABS warning lamp is OFF Off
VDC/TCS IND VDC indicator lamp When VDC indicator lamp is ON
On
When VDC indicator lamp is OFF OFF
SLIP IND Slip indicator lamp When SLIP indicator lamp is ON
On
When SLIP indicator lamp is OFF Off
BRAKE W/L Brake warning lamp When Brake warning lamp is ON
On
*
When Brake warning lamp is OFF Off
DOOR W/L Door open warning lamp When Door warning lamp is ON
On
When Door warning lamp is OFF Off
HI-BEAM IND HI-Beam indicator lamp When High-beam indicator lamp is ON
On
When High-beam indicator lamp is OFF Off
TURN IND Turn si gnal indicatorWhen Turn signal indicator lamp is ON
On
When Turn signal indicator lamp is OFF Off
LIGHT IND Light indicator When Tail lamp indicator lamp is ON
On
When Tail lamp indicator lamp is OFF Off
OIL W/L Engine oil pressure warning
light When engine oil pressure warning lamp is ON
On
When engine oil pressure warning lamp is OFF Off
MIL MIL warning lamp When Malfunction indicator lamp (MIL) is ON
On
When Malfunction indicator lamp (MIL) is OFF Off
CRUISE IND Cruise indicator lamp When cruise indicator lamp is ON
On
When cruise indicator lamp is OFF Off
Revision: August 2015 2016 Versa Note

cardiagn.com

Page 2380 of 3641

NISSAN NOTE 2016 Service Repair Manual MWI-22
< ECU DIAGNOSIS INFORMATION >[TYPE A]
COMBINATION METER
*: Displays “Off” if the brake warning lamp is illumi
nated when the valve check starts, the parking brake switch
is turned ON or the

Page 2381 of 3641

NISSAN NOTE 2016 Service Repair Manual MWI
COMBINATION METERMWI-23
< ECU DIAGNOSIS INFORMATION > [TYPE A]
C
D
E
F
G H
I
J
K L
M B A
O P
*1:For Canada
Fail-safeINFOID:0000000012432555
The combination meter activates the fail-safe contro l i

Page 2382 of 3641

NISSAN NOTE 2016 Service Repair Manual MWI-24
< ECU DIAGNOSIS INFORMATION >[TYPE A]
COMBINATION METER
DTC Index
INFOID:0000000012432556
Information display Trip com-
puterCurrent fuel consump-
tion
• When reception time of an abnormal si

Page 2383 of 3641

NISSAN NOTE 2016 Service Repair Manual MWI
BCM (BODY CONTROL MODULE)MWI-25
< ECU DIAGNOSIS INFORMATION > [TYPE A]
C
D
E
F
G H
I
J
K L
M B A
O P
BCM (BODY CONTROL MODULE)
List of ECU ReferenceINFOID:0000000012432557
ECU Reference
BCM BCS-10

Page 2384 of 3641

NISSAN NOTE 2016 Service Repair Manual MWI-26
< WIRING DIAGRAM >[TYPE A]
METER SYSTEM
WIRING DIAGRAM
METER SYSTEM
Wiring DiagramINFOID:0000000012432558
ABNWA2885GB
Revision: August 2015
2016 Versa Note

cardiagn.com
