SEC-152
< DTC/CIRCUIT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
B2196 DONGLE UNIT
B2196 DONGLE UNIT
DescriptionINFOID:0000000012430482
BCM performs ID verification between BCM and dongle unit.
When verification result is OK, BCM permits cranking.
DTC LogicINFOID:0000000012430483
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Turn ignition switch OFF.
3. Turn ignition switch ON.
4. Check DTC in “Self Diagnostic Result” of “BCM” using CONSULT.
Is the DTC detected?
YES >> Refer to SEC-152, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000012430484
Regarding Wiring Diagram information, refer to SEC-132, "Wiring Diagram".
1.PERFORM INITIALIZATION
1. Perform initialization of BCM and registration of all mechanical keys using CONSULT. For initialization and registration procedures, refe r to CONSULT Immobilizer mode and follow the on-
screen instructions
2. Start the engine.
Dose the engine start?
YES >> Inspection End.
NO >> GO TO 2.
2.CHECK DONGLE UNIT CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect BCM connector and dongle unit connector.
3. Check continuity between BCM harness connector and dongle unit harness connector.
4. Check continuity between BCM harness connector and ground.
Is the inspection result normal?
DTC No. Trouble diagnosis name DTC detecting conditionPossible cause
B2196 DONGLE NG The ID verification results between BCM
and dongle unit is NG. • Harness or connectors
(Dongle unit circuit is open or shorted.)
• Dongle unit
BCM Dongle unit
Continuity
Connector TerminalConnector Terminal
M18 24M6 1Yes
BCM GroundContinuity
Connector Terminal
M18 24 No
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 3010 of 3641
B2196 DONGLE UNITSEC-153
< DTC/CIRCUIT DIAGNOSIS > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
YES >> GO TO 3.
NO >> Repair or replace harness.
3.CHECK DONGLE UNIT GROUND CIRCUIT
Check continuity between dongle unit harness connector and ground.
Is the inspection result normal?
YES >> Replace dongle unit.
NO >> Repair or replace harness.
Dongle unit
GroundContinuity
Connector Terminal
M6 4 Yes
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 3011 of 3641
![NISSAN NOTE 2016 Service Repair Manual SEC-154
< DTC/CIRCUIT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
POWER SUPPLY AND GROUND CIRCUIT
POWER SUPPLY AND GROUND CIRCUIT
BCM
BCM : Diagnosis ProcedureINFOID:0000000012542538
Regarding Wiring NISSAN NOTE 2016 Service Repair Manual SEC-154
< DTC/CIRCUIT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
POWER SUPPLY AND GROUND CIRCUIT
POWER SUPPLY AND GROUND CIRCUIT
BCM
BCM : Diagnosis ProcedureINFOID:0000000012542538
Regarding Wiring](/manual-img/5/57363/w960_57363-3010.png)
SEC-154
< DTC/CIRCUIT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
POWER SUPPLY AND GROUND CIRCUIT
POWER SUPPLY AND GROUND CIRCUIT
BCM
BCM : Diagnosis ProcedureINFOID:0000000012542538
Regarding Wiring Diagram information, refer to
BCS-117, "Wiring Diagram".
1.CHECK FUSES AND FUSIBLE LINK
Check that the following fuses and fusible link are not blown.
Is the fuse blown?
YES >> Replace the blown fuse or fusible link after repairing the affected circuit.
NO >> GO TO 2.
2.CHECK POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect BCM connectors.
3. Check voltage between BCM connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair harness or connector.
3.CHECK GROUND CIRCUIT
Check continuity between BCM connector and ground.
Is the inspection result normal?
YES >> Inspection End.
NO >> Repair harness or connector.
Terminal No. Signal nameFuses and fusible link No.
37 Battery power supply 8 (10A)
42 12 (10A)
50 G (40A)
11 Ignition switch ACC or ON 18 (10A)
38 Ignition switch ON or START 2 (10A)
BCMGround Ignition switch position
Connector Terminal
—OFF
ACC ON
M18 11
0 V
Battery voltage
Battery voltage
37
Battery voltage
38 0 V0 V
M19 42
Battery voltage Battery voltage
50
BCM GroundContinuity
Connector Terminal
M19 55—Yes
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 3012 of 3641
![NISSAN NOTE 2016 Service Repair Manual VEHICLE SECURITY INDICATORSEC-155
< DTC/CIRCUIT DIAGNOSIS > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
VEHICLE SECURITY INDICATOR
DescriptionINFOID:0000000012430486
• Vehicle NISSAN NOTE 2016 Service Repair Manual VEHICLE SECURITY INDICATORSEC-155
< DTC/CIRCUIT DIAGNOSIS > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
VEHICLE SECURITY INDICATOR
DescriptionINFOID:0000000012430486
• Vehicle](/manual-img/5/57363/w960_57363-3011.png)
VEHICLE SECURITY INDICATORSEC-155
< DTC/CIRCUIT DIAGNOSIS > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
VEHICLE SECURITY INDICATOR
DescriptionINFOID:0000000012430486
• Vehicle security indicator is built in combination meter.
• NATS (Nissan Anti-Theft System) condition is indicated by blink or illumination of vehicle security indicator.
Component Function CheckINFOID:0000000012430487
1.CHECK FUNCTION
1. Perform “Active Test” of “THEFT I ND” in the “IMMU” using CONSULT.
2. Check vehicle security indicator operation.
Is the inspection result normal?
YES >> Inspection End.
NO >> Refer to SEC-155, "
Diagnosis Procedure (Type B)" or SEC-156, "Diagnosis Procedure (Type A)".
Diagnosis Procedu re (Type B)INFOID:0000000012430488
Regarding Wiring Diagram information, refer to SEC-132, "Wiring Diagram".
1.SECURITY INDICATOR LAMP ACTIVE TEST
With CONSULT
Check “THEFT IND”” in “Active Test” of “IMMU”.
Without CONSULT
1. Disconnect BCM.
2. Check voltage between BCM harness connector M18 terminal 23 and ground.
Is the inspection result normal?
YES >> Security indicator lamp is OK.
NO >> GO TO 2.
2.SECURITY INDICATOR LAMP CHECK
Check security indicator lamp condition.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace combination meter. Refer to MWI-115, "
Removal and Installation".
3.CHECK HARNESS CONTINUITY
1. Turn ignition switch OFF.
2. Disconnect BCM and security indicator lamp connector.
3. Check continuity between BCM connector M18 terminal 23 and combination meter connector M24 termi- nal 18.
Te s t i t e m D e s c r i p t i o n
THEFT IND ON
Vehicle security indicator ON
OFF OFF
ConnectorTe r m i n a l s
ConditionVoltage (V)
(Approx.)
(+) (-)
M18 23Ground ON
0
OFF Battery voltage
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 3013 of 3641
![NISSAN NOTE 2016 Service Repair Manual SEC-156
< DTC/CIRCUIT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
VEHICLE SECURITY INDICATOR
4. Check continuity between BCM connector M18 terminal 23 and ground.
Is the inspection result normal?
YES NISSAN NOTE 2016 Service Repair Manual SEC-156
< DTC/CIRCUIT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
VEHICLE SECURITY INDICATOR
4. Check continuity between BCM connector M18 terminal 23 and ground.
Is the inspection result normal?
YES](/manual-img/5/57363/w960_57363-3012.png)
SEC-156
< DTC/CIRCUIT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
VEHICLE SECURITY INDICATOR
4. Check continuity between BCM connector M18 terminal 23 and ground.
Is the inspection result normal?
YES >> Check the following:
• 10A fuse No. 8, located in fuse block (J/B)
• Harness for open or short between security indicator lamp and fuse.
NO >> Repair or replace harness.
Diagnosis Procedure (Type A)INFOID:0000000012430489
Regarding Wiring Diagram information, refer to SEC-132, "Wiring Diagram".
1.SECURITY INDICATOR LAMP ACTIVE TEST
With CONSULT
Check “THEFT IND”” in “Active Test” of “IMMU”.
Without CONSULT
1. Disconnect BCM.
2. Check voltage between BCM harness connector M18 terminal 23 and ground.
Is the inspection result normal?
YES >> Security indicator lamp is OK.
NO >> GO TO 2.
2.SECURITY INDICATOR LAMP CHECK
Check security indicator lamp condition.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace combination meter. Refer to MWI-54, "
Removal and Installation".
3.CHECK HARNESS CONTINUITY
1. Turn ignition switch OFF.
2. Disconnect BCM and security indicator lamp connector.
3. Check continuity between BCM connector M18 term inal 23 and combination meter connector M82 termi-
nal 18.
4. Check continuity between BCM connector M18 terminal 23 and ground.
BCM Combination meter
Continuity
Connector TerminalConnector Terminal
M 182 3M 241 8 Y es
BCM GroundContinuity
Connector Terminal
M18 23 No
ConnectorTe r m i n a l s
ConditionVoltage (V)
(Approx.)
(+) (-)
M18 23Ground ON
0
OFF Battery voltage
BCM Combination meter
Continuity
Connector TerminalConnector Terminal
M 182 3M 821 8 Y es
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 3014 of 3641
VEHICLE SECURITY INDICATORSEC-157
< DTC/CIRCUIT DIAGNOSIS > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
Is the inspection result normal?
YES >> Check the following: • 10A fuse No. 8, located in fuse block (J/B)
• Harness for open or short between security indicator lamp and fuse.
NO >> Repair or replace harness.
BCM
GroundContinuity
Connector Terminal
M18 23 No
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 3015 of 3641
SEC-158
< SYMPTOM DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
NISSAN VEHICLE IMMOBILIZE
R SYSTEM-NATS SYMPTOMS
SYMPTOM DIAGNOSIS
NISSAN VEHICLE IMMOBILIZER SYSTEM-NATS SYMPTOMS
Symptom TableINFOID:0000000012430490
NOTE:
• Before performing the diagnosis in the following table, check “ SEC-139, "
Work Flow"”.
• Check that vehicle is under the condition shown in “Conditions of vehicle” before starting diagnosis, and check each symptom.
• If the following symptoms are detected, check syst ems shown in the “Diagnosis/service procedure” column
in this order.
CONDITIONS OF VEHICLE (OPERATING CONDITIONS)
• Mechanical key is not inserted into key cylinder.
• Ignition knob switch is not depressed.
Symptom Diagnosis/service procedure Reference page
Security indicator does not turn ON or flash. 1. Check vehicle security indicator
SEC-155
2. Check Intermittent Incident GI-42
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 3016 of 3641
NATS ANTENNA AMP.SEC-159
< REMOVAL AND INSTALLATION > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
REMOVAL AND INSTALLATION
NATS ANTENNA AMP.
Removal and InstallationINFOID:0000000012430491
REMOVAL
1. Remove combination switch. Refer to BCS-75, "Removal and Installation".
2. Remove the NATS antenna amp bolt (A).
3. Disconnect the harness connector (B) from the NATS antenna amp. (1) and remove.
INSTALLATION
Installation is in the reverse order of removal.
NOTE:
• If NATS antenna amp. is not installed correctly, NV IS (NATS) system will not operate properly and “SELF-
DIAG RESULTS" on CONSULT screen will show “LOCK MODE” or "CHAIN OF IMMU-KEY".
• Initialization is not necessary when only the NATS antenna amp. is replaced with a new one.
AWKIA2524ZZ
Revision: August 2015 2016 Versa Note
cardiagn.com
