NISSAN NOTE 2016 Service Repair Manual DLK-256
< DTC/CIRCUIT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
KEYFOB ID SET UP WITH CONSULT
KEYFOB ID SET UP WITH CONSULT
ID Code Entry ProcedureINFOID:0000000012430224
KEYFOB ID SET UP WITH CONSU

Page 946 of 3641

NISSAN NOTE 2016 Service Repair Manual KEYFOB ID SET UP WITHOUT CONSULTDLK-257
< DTC/CIRCUIT DIAGNOSIS > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
KEYFOB ID SET UP WITHOUT CONSULT
ID Code Entry ProcedureINFOID:0000

Page 947 of 3641

NISSAN NOTE 2016 Service Repair Manual DLK-258
< DTC/CIRCUIT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
KEYFOB ID SET UP WITHOUT CONSULT
ID codes should be erased. After all ID codes are eras
ed, the ID codes of all remaining and/or new k

Page 948 of 3641

NISSAN NOTE 2016 Service Repair Manual POWER DOOR LOCK SYSTEM SYMPTOMSDLK-259
< SYMPTOM DIAGNOSIS > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
SYMPTOM DIAGNOSIS
POWER DOOR LOCK SYSTEM SYMPTOMS
Symptom TableINFOID:00

POWER DOOR LOCK SYSTEM SYMPTOMSDLK-259
< SYMPTOM DIAGNOSIS > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
SYMPTOM DIAGNOSIS
POWER DOOR LOCK SYSTEM SYMPTOMS
Symptom TableINFOID:0000000012430226
DOOR LOCK/UNLOCK FUNCTION MALFUNCTION
NOTE:
• Before performing the diagnosis in the following table, check “WORK FLOW”. Refer to DLK-225, "
Work
Flow".
• Check that vehicle is under the condition shown in “Conditions of vehicle” before starting diagnosis, and check each symptom.
• If the following symptoms are detec ted, check systems shown in the “Diagnosis/service procedure” column
in this order.
Symptom Diagnosis/service procedure Reference page
Key reminder door function does not operate
properly. 1. Check door switch.
DLK-232
2. Check key switch.DLK-241
3. Check Intermittent Incident. GI-42
Power door lock does not operate with door
lock and unlock switch on main power window
and door lock/unlock switch or power window
and door lock/unlock switch RH.1. Check BCM power supply and ground circuit.
BCS-1292. Check main power window and door lock and unlock switch. DLK-235
3. Check power window and door lock and unlock switch RH.DLK-236
4. Check Intermittent Incident. GI-42
Specific door lock actuator does not operate.1. Check door lock actuator.Front LH
DLK-242
Front RHDLK-243
Rear LHDLK-244
Rear RHDLK-245
2. Check Intermittent Incident. GI-42
Power door locks do not operate with front
door lock key cylinder switch LH.1. Check key cylinder switch.
DLK-239
2. Replace BCM.BCS-137
Vehicle speed sensing auto door LOCK oper-
ation does not operate.1. Ensure automatic door lock/unlock function (lock operation)
is enabled. DLK-196
2. Check combination meter vehicle speed signal. MWI-40
(Type
A)
MWI-95
(Type
B)
3. Check intermittent incident. GI-42
Ignition OFF interlock auto door UNLOCK
function does not operate.1. Ensure automatic door lock/unlock function (unlock opera-
tion) is enabled. DLK-196
2. Check BCM for DTCs.
BCS-115
3. Check intermittent incident. GI-42
