Page 441 of 3641

NISSAN NOTE 2016 Service Repair Manual BRM-42 < SERVICE DATA AND SPECIFICATIONS (SDS) BODY ALIGNMENT Description INFOID:0000000012430815 • All dimensions indicated in the figures are actual. • When using a tracking gauge, adjust both

Page 442 of 3641

NISSAN NOTE 2016 Service Repair Manual BODY ALIGNMENTBRM-43 < SERVICE DATA AND SPECIFICATIONS (SDS) C DE F G H I J L M A B BRM N O P Unit: mm (in) ALKIA3123ZZ Position Description Measurement A. Center of rear hood hinge hole to center of

Page 443 of 3641

NISSAN NOTE 2016 Service Repair Manual BRM-44 < SERVICE DATA AND SPECIFICATIONS (SDS) BODY ALIGNMENT Underbody INFOID:0000000012430817 MEASUREMENT F. Upper hole for front bumper reinforcement to upper hole front bumper reinforcement 8.

Page 444 of 3641

NISSAN NOTE 2016 Service Repair Manual BODY ALIGNMENTBRM-45 < SERVICE DATA AND SPECIFICATIONS (SDS) C DE F G H I J L M A B BRM N O P Unit:mm (in) Front LH side Points Measurement PointsMeasurement A-a 904.0 (35.59) B-b820.0 (32.28) C-c 79

Page 445 of 3641

NISSAN NOTE 2016 Service Repair Manual BRM-46 < SERVICE DATA AND SPECIFICATIONS (SDS) BODY ALIGNMENT MEASURMENT POINTS Unit: mm (in) AWKIA2547ZZ Front Points Coordinates Remarks XYZ A, a ± 299.0 ( ±11 . 7 7 ) ±±452.0 (17.80) 293.6 (11

Page 446 of 3641

NISSAN NOTE 2016 Service Repair Manual BODY ALIGNMENTBRM-47 < SERVICE DATA AND SPECIFICATIONS (SDS) C DE F G H I J L M A B BRM N O P Passenger CompartmentINFOID:0000000012430818 MEASURMENTS Unit: mm (in) The vehicle is symmetrically iden

Page 447 of 3641

NISSAN NOTE 2016 Service Repair Manual BRM-48 < SERVICE DATA AND SPECIFICATIONS (SDS) BODY ALIGNMENT Rear End Panel INFOID:0000000012430819 Unit: mm (in) * The vehicle is symmetrically identical dimensions on both RH and LH sides of the v

Page 448 of 3641

NISSAN NOTE 2016 Service Repair Manual BODY ALIGNMENTBRM-49 < SERVICE DATA AND SPECIFICATIONS (SDS) C DE F G H I J L M A B BRM N O P Front Point Description PointDescription A. Roof flange end of center positioning mark B. Back pillar ma
