Page 2145 of 3641
MAP LAMPINL-51
< REMOVAL AND INSTALLATION >
C
DE
F
G H
I
J
K
M A
B
INL
N
O P
REMOVAL AND INSTALLATION
MAP LAMP
Exploded ViewINFOID:0000000012432752
Removal and InstallationINFOID:0000000012432753
REMOVAL
1. Release lens pawls using a suitable tool (A) and remove. : Pawl
2. Release map lamp pawl using suitable tool (A). : Pawl
3. Disconnect the harness connector from map lamp and remove.
INSTALLATION
Installation is in the reverse order of removal.
Bulb ReplacementINFOID:0000000012432754
WARNING:
1. Map lamp 2. Bulb3. Lens
Pawl
AWLIA2175ZZ
AWLIA2150ZZ
AWLIA2144ZZ
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2146 of 3641
INL-52
< REMOVAL AND INSTALLATION >
MAP LAMP
Do not touch bulb while it is lit or right after being turned OFF. Burning may result.
CAUTION:
• Do not touch the glass surface of the bulb with bare hands or allow oil or grease to get on it to pre-vent damage to bulb.
• Do not leave bulb out of lamp reflector for a long time because dust, moisture smoke, etc. may affect
the performance of lamp.
REMOVAL
1. Release lens pawls using suitable tool (A) and remove.
: Pawl
2. Remove the bulb.
INSTALLATION
Installation is in the reverse order of removal.
AWLIA2150ZZ
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2147 of 3641

INTERIOR ROOM LAMPINL-53
< REMOVAL AND INSTALLATION >
C
DE
F
G H
I
J
K
M A
B
INL
N
O P
INTERIOR ROOM LAMP
Exploded ViewINFOID:0000000012432755
Removal and InstallationINFOID:0000000012432756
REMOVAL
1. Release interior room lamp metal clips using a suitable tool.
2. Disconnect the harness connector from room lamp and remove.
INSTALLATION
Installation is in the reverse order of removal.
Bulb ReplacementINFOID:0000000012432757
WARNING:
Do not touch bulb while it is lit or right after being turned OFF. Burning may result.
CAUTION:
• Do not touch the glass surface of the bulb with bare hands or allow oi l or grease to get on it to pre-
vent damage to bulb.
• Do not leave bulb out of lamp reflector for a long time because dust, moisture smoke, etc. may affect the performance of lamp.
REMOVAL
1. Release interior room lamp lens pawls using a suitable tool and remove.
2. Remove bulb.
INSTALLATION
Installation is in the reverse order of removal.
NOTE:
Insert the lens hook end RH side first when installing lens.
1. Interior room lamp 2. Bulb3. Lens
A. Pawls to release first for lens removal B. Pawl to install first for lens installation Pawl
Metal clip
AWLIA2174ZZ
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2148 of 3641

INL-54
< REMOVAL AND INSTALLATION >
CARGO ROOM LAMP
CARGO ROOM LAMP
Exploded ViewINFOID:0000000012432758
Removal and InstallationINFOID:0000000012432759
REMOVAL
1. Release cargo room lamp pawl with a suitable tool (A): Pawl: Front
2. Disconnect harness connector from cargo room lamp and remove.
INSTALLATION
Installation is in the reverse order of removal.
Bulb ReplacementINFOID:0000000012432760
WARNING:
Do not touch bulb while it is lit or right after being turned OFF. Burning may result.
CAUTION:
• Do not touch the glass surface of the bulb with bare hands or allow oil or grease to get on it to pre-vent damage to bulb.
• Do not leave bulb out of lamp reflector for a long time because dust, moisture smoke, etc. may affect
the performance of lamp.
REMOVAL
1. Release cargo room lamp lens pawl using a suitable tool.
2. Remove the bulb.
INSTALLATION
Installation is in the reverse order of removal.
1. Cargo room lamp 2. Bulb3. Lens
Front Pawl
AWLIA2148ZZ
AWLIA2149ZZ
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2149 of 3641
SHIFT SELECTOR LAMPINL-55
< REMOVAL AND INSTALLATION >
C
DE
F
G H
I
J
K
M A
B
INL
N
O P
SHIFT SELECTOR LAMP
Bulb ReplacementINFOID:0000000012432761
WARNING:
Do not touch bulb while it is lit or right after being turned OFF. Burning may result.
CAUTION:
• Do not touch the glass surface of the bulb with bare hands or allow oil or grease to get on it to pro-
tect damage to bulb.
• Do not leave bulb out of lamp reflector for a long time because dust, moisture smoke, etc. may affect
the performance of lamp.
REMOVAL
1. Remove the center console assembly. Refer to IP-18, "Removal and Installation".
2. Remove shift selector lamp bulb from bulb socket (1). : Front
INSTALLATION
Installation is in the reverse order of removal.
AWLIA2147ZZ
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2150 of 3641
INL-56
< REMOVAL AND INSTALLATION >
ILLUMINATION CONTROL SWITCH
ILLUMINATION CONTROL SWITCH
Removal and InstallationINFOID:0000000012432762
The illumination control switch is part of the combination meter. Refer to MWI-54, "Removal and Installation".
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2151 of 3641
SERVICE DATA AND SPECIFICATIONS (SDS)INL-57
< SERVICE DATA AND SPECIFICATIONS (SDS)
C
DE
F
G H
I
J
K
M A
B
INL
N
O P
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
Bulb SpecificationsINFOID:0000000012432763
*: Always check with the Parts Department for the latest parts info.
Item Wattage (W)*
Map lamp 5
Interior room lamp 8
Cargo room lamp 5
Shift selector lamp —
