Front view guiding lines
Rear View• The rear view image improves the visibility of obstacles in the rear of the vehicle and assists backing and
parking by displaying images from birds-eye view and front side view.
• The rear view image displays the vehicle width guiding line and vehicle distance guiding line, in addition to the predictive course line according to the steering angle.
NOTE:
The predictive course line is not di splayed at the steering neutral position.
• The around view monitor control unit receives the steering angle signal from steering angle sensor via CAN
communication, and controls the direction and distance of the predictive course line.
• ON/OFF setting of predictive course line can be performed using CONSULT.
Rear view guiding lines
Front-Side View• The front-side view image improves the visibility of ob stacles in the front RH side of the vehicle and assists
backing and parking.
• The front-side view image displays the vehicle distance guiding line and vehicle width guiding line.
JSNIA0770GB
JSNIA4567GB
Revision: August 2015 2016 Versa Note

cardiagn.com

AV
SYSTEMAV-141
< SYSTEM DESCRIPTION > [NAVIGATION]
C
D
E
F
G H
I
J
K L
M B A
O P
Front-side view area and guiding line
Birds-Eye View• The birds-eye view image improves the visibility of obstacles all around the vehicle and assists backing and
parking.
• The images from the four cameras are converted in to an overhead view, and the surroundings of the vehicle
are displayed.
• The blind spot area is displayed on the image to specify the boundary of the four cameras.
Birds-Eye view display image
JSNIA0771GB
AWNIA3141GB
