CONTENTS
AUDIO, VISUAL & NAVIGATION SYSTEM
BASE AUDIO
PRECAUTION ....... ........................................
6
PRECAUTIONS .............................................. .....6
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ............................................................. ......
6
Precaution for Work ..................................................6
PREPARATION ............................................7
PREPARATION .............................................. .....7
Special Service Tools .......................................... ......7
Commercial Service Tools ........................................7
SYSTEM DESCRIPTION ..............................8
COMPONENT PARTS ................................... .....8
Component Parts Location .................................. ......8
Audio unit ..................................................................8
Speaker .....................................................................9
Bluetooth® Control Unit ............................................9
Bluetooth® Antenna ................................................10
Steering Wheel Audio Control Switches .................10
Microphone .............................................................10
Rod Antenna, Antenna Amp. and Antenna Feeder
....
10
SYSTEM .............................................................12
System Description ............................................. ....12
DIAGNOSIS SYSTEM (AUDIO UNIT) ................14
Diagnosis Description ......................................... ....14
On Board Diagnosis Function .................................14
DIAGNOSIS SYSTEM (BLUETOOTH® CON-
TROL UNIT) ........................................................
17
Diagnosis Description .............................................17
Work Flow ...............................................................17
ECU DIAGNOSIS INFORMATION ..............18
AUDIO UNIT ......................................................18
Reference Value .................................................. ....18
BLUETOOTH® CONTROL UNIT ......................21
Reference Value ......................................................21
WIRING DIAGRAM ......................................24
BASE AUDIO ....................................................24
Wiring Diagram .................................................... ....24
BASIC INSPECTION ...................................33
DIAGNOSIS AND REPAIR WORKFLOW ........33
Work Flow ............................................................ ....33
DTC/CIRCUIT DIAGNOSIS .........................35
POWER SUPPLY AND GROUND CIRCUIT ....35
AUDIO UNIT ........................................................... ....35
AUDIO UNIT : Diagnosis Procedure .......................35
BLUETOOTH® CONTROL UNIT .......................... ....35
BLUETOOTH® CONTROL UNIT : Diagnosis Pro-
cedure ......................................................................
35
FRONT DOOR SPEAKER ................................37
Diagnosis Procedure ...............................................37
REAR DOOR SPEAKER ..................................39
Diagnosis Procedure ...............................................39
BLUETOOTH® VOICE SIGNAL CIRCUIT .......41
Diagnosis Procedure ...............................................41
BLUETOOTH® CONTROL SIGNAL CIRCUIT ...43
Diagnosis Procedure ........................................... ....43
MICROPHONE SIGNAL CIRCUIT ....................44
Diagnosis Procedure ...............................................44
STEERING SWITCH .........................................46
Diagnosis Procedure ...............................................46
Revision: August 2015 2016 Versa Note

cardiagn.com

AV
AV-3
C
DE
F
G H
I
J
K L
M B
A
O P
SYMPTOM DIAGNOSIS ..... .......................108
AUDIO SYSTEM ............................................. ..108
Symptom Table ................................................... ..108
NORMAL OPERATING CONDITION ...............111
Description .......................................................... ..111
REMOVAL AND INSTALLATION .............113
AUDIO UNIT ................................................... ..113
Exploded View .................................................... ..113
Removal and Installation .......................................113
FRONT DOOR SPEAKER ............................. ..114
Removal and Installation .......................................114
REAR DOOR SPEAKER ................................ ..115
Removal and Installation .......................................115
USB INTERFACE ........................................... ..116
Removal and Installation .......................................116
AUXILIARY INPUT JACK .............................. ..117
Removal and Installation .......................................117
REAR VIEW CAMERA ................................... ..118
Removal and Installation .......................................118
BLUETOOTH® CONTROL UNIT ................... ..119
Removal and Installation .......................................119
BLUETOOTH® ANTENNA ............................ ..120
Removal and Installation .......................................120
STEERING SWITCH ...................................... ..121
Removal and Installation .......................................121
MICROPHONE ............................................... ..122
Removal and Installation .......................................122
ROD ANTENNA ............................................. ..123
Exploded View .................................................... ..123
Removal and Installation .......................................123
ANTENNA FEEDER ....................................... ..124
Feeder Layout ..................................................... ..124
SATELLITE RADIO ANTENNA .......................125
Removal and Installation .......................................125
NAVIGATION
PRECAUTION ....... .....................................
126
PRECAUTIONS .............................................. ..126
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ............................................................. ..
126
Cautions in Removing Battery Terminal and AV
Control Unit (Models with AV Control Unit) ...........
126
Precaution for Trouble Diagnosis ..........................126
Precaution for Harness Repair ..............................126
Precaution for Work ............................................ ..127
PREPARATION .........................................128
PREPARATION ...............................................128
Special Service Tools .......................................... ..128
Commercial Service Tools .....................................128
SYSTEM DESCRIPTION ...........................129
COMPONENT PARTS ....................................129
Component Parts Location .................................. ..129
AV Control Unit ......................................................130
Speakers ...............................................................130
USB Interface and AUX In Jack ............................131
Steering Wheel Audio Control Switches ................131
Microphone ............................................................131
Around View Monitor Control Unit .........................131
Rear View Camera ................................................132
Side Cameras ........................................................132
Front Camera ........................................................132
Steering Angle Sensor ...........................................132
Rod Antenna, Antenna Amp., Satellite Antenna
and Antenna Feeder ..............................................
132
GPS Antenna .........................................................134
SD Card .................................................................134
SYSTEM ..........................................................135
System Description .............................................. ..135
DIAGNOSIS SYSTEM (AV CONTROL UNIT) .143
Description .............................................................143
On Board Diagnosis Function ................................143
CONSULT Function ...............................................144
DIAGNOSIS SYSTEM (AROUND VIEW MON-
ITOR CONTROL UNIT) ...................................
146
CONSULT Function ...............................................146
ECU DIAGNOSIS INFORMATION ............148
AV CONTROL UNIT ........................................148
Reference Value .................................................. ..148
DTC Index .............................................................151
AROUND VIEW MONITOR CONTROL UNIT .152
Reference Value ....................................................152
DTC Index .............................................................154
WIRING DIAGRAM ....................................155
NAVIGATION SYSTEM ..................................155
Wiring Diagram .................................................... ..155
BASIC INSPECTION .................................171
DIAGNOSIS AND REPAIR WORKFLOW ......171
Work Flow ............................................................ ..171
INSPECTION AND ADJUSTMENT ................173
ADDITIONAL SERVICE WHEN REPLACING AV
CONTROL UNIT .................................................... ..
173
Revision: August 2015 2016 Versa Note

cardiagn.com

AV-126
< PRECAUTION >[NAVIGATION]
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint Syst
em (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000012432992
The Supplemental Restraint System such as “A IR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the SR and SB section of
this Service Manual.
WARNING:
• To avoid rendering the SRS inopera tive, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
• Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintent ional activation of the system. For re moval of Spiral Cable and Air Bag
Module, see the SR section.
• Do not use electrical test equipmen t on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harn esses can be identified by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
• When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Igni-
tion ON or engine running, DO NOT use air or electri c power tools or strike near the sensor(s) with a
hammer. Heavy vibration could activate the sensor( s) and deploy the air bag(s), possibly causing
serious injury.
• When using air or electric power tools or hammers , always switch the Ignition OFF, disconnect the
battery and wait at least three minutes before performing any service.
Cautions in Removing Battery Terminal and AV Control Unit (Models with AV Control
Unit)
INFOID:0000000012432993
CAUTION:
Remove battery terminal and AV control unit 30 seconds or more after turning the ignition switch OFF.
NOTE:
After the ignition switch is turned OFF, the AV cont rol unit continues operating for approximately 30 seconds.
Therefore, data corruption may occur if battery voltage is cut off within 30 seconds.
Precaution for Trouble DiagnosisINFOID:0000000012432994
AV COMMUNICATION SYSTEM
• Do not apply voltage of 7.0 V or higher to the measurement terminals.
• Use the tester with its open terminal voltage being 7.0 V or less.
• Be sure to turn ignition switch OFF and disconnect the battery cable from\
the negative terminal before checking the circuit.
Precaution for Harness RepairINFOID:0000000012432995
AV COMMUNICATION SYSTEM
Revision: August 2015 2016 Versa Note

cardiagn.com

AV
COMPONENT PARTSAV-129
< SYSTEM DESCRIPTION > [NAVIGATION]
C
D
E
F
G H
I
J
K L
M B A
O P
SYSTEM DESCRIPTION
COMPONENT PARTS
Component Parts LocationINFOID:0000000012432999
A. Front of headliner B. View with passenger seat removed C. Center of back door
AWNIA3648ZZ
No.Component Function
1. Rod antenna Refer to AV- 1 3 2 , "
Rod Antenna, Antenna Amp., Satellite Antenna and Antenna
Feeder".
2. Antenna base (antenna amp. and satellite
antenna)
3. Rear door speaker RH Refer to AV- 1 3 0 , "
Spe ak ers".
4. Front door speaker RH
5. Front camera Refer to AV- 1 3 2 , "
Front Camera".
6. Front door speaker LH Refer to AV- 1 3 0 , "
Spe ak ers".
7. Side camera Refer to AV- 1 3 2 , "
Side Cameras".
8. Rear door speaker LH Refer to AV- 1 3 0 , "
Spe ak ers".
9. AV control unit Refer to AV- 1 3 0 , "
AV Control Unit".
10. GPS antenna Refer to AV- 1 3 4 , "
GPS Antenna".
11. Steering wheel audio control switches Refer to AV- 1 3 1 , "
Steering Wheel Audio Control Switches".
12. Steering angle sensor Refer to AV- 1 3 2 , "
Steering Angle Sensor".
13. USB interface and AUX in jack Refer to AV- 1 3 1 , "
USB Interface and AUX In Jack".
14. Microphone Refer to AV- 1 3 1 , "
Microphone".
Revision: August 2015 2016 Versa Note

cardiagn.com

AV-130
< SYSTEM DESCRIPTION >[NAVIGATION]
COMPONENT PARTS
*: Around View Monitor is a parking aid/convenience feature. Around View Monitor cannot completely eliminate
blind spots. Around View Monitor may not detect ever y object and does not warn of moving objects. Always
check surroundings before moving vehicle. Around View Monitor is not a substitute for proper backing proce-
dures. Always turn to check what is behind you before backing up.
AV Control UnitINFOID:0000000012433000
Description
• A 5.8-inch QVGA display, an AM/FM electronic tuner radio, CD
drive, audio amplifier, Bluetooth
® module, camera controller and
navigation unit are integrated into the AV control unit.
• The 5.8-inch display is a high resolution monitor that includes touch panel functions.
• Music files stored in iPod
®*/USB memory can be played using the
separate USB interface.
*: iPod® is a registered trademark of Apple, Inc. All rights reserved.
SpeakersINFOID:0000000012433001
FRONT DOOR SPEAKER
• 16.5 cm (6.5 in) speakers are installed in the bottom of the front doors.
• Sound signals are input from the AV control unit to output high, mid and low range sounds.
REAR DOOR SPEAKER
• 16.5 cm (6.5 in) speakers are installed in the bottom of the rear doors.
• Sound signals are input from the AV control unit to output high, midand low range sounds.
15. Around View®* Monitor control unit (if
equipped) Refer to AV- 1 3 1 , "Around View Monitor Control Unit".
16. Rear view camera Refer to AV- 1 3 2 , "
Rear View Camera".
No.
Component Function
ALNIA1524ZZ
JPNIA1454ZZ
JPNIA1454ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

AV
COMPONENT PARTSAV-131
< SYSTEM DESCRIPTION > [NAVIGATION]
C
D
E
F
G H
I
J
K L
M B A
O P
USB Interface and AUX In JackINFOID:0000000012433002
• USB Interface and AUX in jack is installed in the console.
•iPod
® and USB memory can be connected to the AV control unit
through the USB interface.
• An external audio device can be connected to the AV control unit through the AUX in jack.
Steering Wheel Audio Control SwitchesINFOID:0000000012433003
• Steering wheel audio control switches are installed in the steering
wheel.
• Operations for audio and hands-free phone are possible.
• Switch is connected to the AV control unit.
MicrophoneINFOID:0000000012433004
• The microphone is installed in the roof in front of the map lamp
assembly.
• Power is supplied from the AV control unit.
Around View Monitor Control UnitINFOID:0000000012433005
• The around view monitor control unit is installed underneath the passenger seat.
• Vehicle width guide lines, predicted course line, vehicle front guid- ing line and vehicle side line, and vehicle icon are displayed and
combined with camera images.
ALNIA1523ZZ
ALNIA1659ZZ
JPNIA1448ZZ
JSNIA5395ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

AV-132
< SYSTEM DESCRIPTION >[NAVIGATION]
COMPONENT PARTS
Rear View Camera
INFOID:0000000012433006
• The rear view camera is installed in the back door finisher.
• Power is supplied from the around view monitor control unit (with around view monitor).
• Power is supplied from the AV control unit (without around view monitor).
Side CamerasINFOID:0000000012433007
• The side cameras are installed in the door mirrors.
• Power is supplied from the around view monitor control unit.
Front Camera INFOID:0000000012433008
• The front camera is installed in the front grille.
• Power is supplied from the around view monitor control unit.
Steering Angle SensorINFOID:0000000012433009
• Steering sensor is installed to the spiral cable.
• Steering angle sends the steering signal necessary for predictivecourse line via CAN communication.
Rod Antenna, Antenna Amp., Sate llite Antenna and Antenna FeederINFOID:0000000012433010
RADIO ANTENNA AND SATELLITE ANTENNA
JPNIA1452ZZ
JSNIA5397ZZ
JSNIA5398ZZ
JSNIA1571ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

AV
COMPONENT PARTSAV-133
< SYSTEM DESCRIPTION > [NAVIGATION]
C
D
E
F
G H
I
J
K L
M B A
O P
AM/FM radio rod antenna, antenna base and satellite antenna are located on the rear of the roof. The antenna
amp. and satellite antenna are built into the antenna base.
ANTENNA FEEDER LAYOUT
AWNIA3133GB
1. Antenna base (antenna amp. and
satellite antenna) 2. Rod Antenna 3. M351
4. M352 5. M110, M3536. M67, M350
7. M111 8. M73
ALNIA1520ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com
