2016 NISSAN NOTE Service Repair Manual

fuel additives lane assist mirror controls tire type air bleeding engine coolant

Load previous 8 pages

Page 2833 of 3641

NISSAN NOTE 2016 Service Repair Manual SE-20
< REMOVAL AND INSTALLATION >
FRONT SEAT
DRIVER SIDE : Remova l and Installation
INFOID:0000000012432036
WARNING:
• Do not leave any objects (screwdriver s, tools, etc.) on the seat during repa

Page 2834 of 3641

NISSAN NOTE 2016 Service Repair Manual FRONT SEATSE-21
< REMOVAL AND INSTALLATION >
C
DE
F
G H
I
K L
M A
B
SE
N
O P
PASSENGER SIDE : Exploded ViewINFOID:0000000012829361
AWJIA1999ZZ
1. Headrest 2. Headrest holder (free) 3. Headrest holder

Page 2835 of 3641

NISSAN NOTE 2016 Service Repair Manual SE-22
< REMOVAL AND INSTALLATION >
FRONT SEAT
PASSENGER SIDE : Remo val and Installation
INFOID:0000000012432038
WARNING:
• Do not leave any objects (screwdriver s, tools, etc.) on the seat during r

SE-22
< REMOVAL AND INSTALLATION >
FRONT SEAT
PASSENGER SIDE : Remo val and Installation
INFOID:0000000012432038
WARNING:
• Do not leave any objects (screwdriver s, tools, etc.) on the seat during repair. It can lead to personal
injury if the side air bag module should accidentally deploy.
• Always work from the side or back of th e seatback, do not work in front of seat.
• Do not use air tools or electric tools for servicing the seat assembly.
• Do not drop, tilt, or bump the si de air bag module while installing the seat. Always handle it with
care.
• After the side air bag module inflates, the front seat frame must be replaced.
• Before removing the front seat, tu rn the ignition switch OFF, disconnect both battery cables then
wait at least three minutes.
CAUTION:
When removing and inst alling the seat, use shop cloths to protect components from damage.
REMOVAL
1. Disconnect negative and positive battery terminals, then wait at least three minutes. Refer to PG-70,
"Removal and Installation (Battery)".
2. Slide the seat to the full forward position.
3. Remove the seat rear bolts.
4. Slide the seat to the full rearward position.
5. Remove the seat front bolts.
6. Tilt the seat rearward and disconnect the harness connectors from the seat and remove.
INSTALLATION
Installation is in the reverse order of removal.
WARNING:
• Perform additional services when installing front passenger seat. Refer to SRC-39, "
ZERO POINT
RESET : Description".
• Zero point reset must be performed every time th e front passenger seat is removed from the vehicle.
• Zero point reset is done after the front passenger seat is installed in vehicle and all bolts are tight-
ened to specification.
CAUTION:
Make sure that the seat harness or the floor trim is not damaged during installation.
When installing the passenger side front seat, tighten the bolts in the
order shown.
7. Occupant classification system sen-
sors 8. Occupant classification system har-
ness 9. Occupant classification
system control unit
10. Seat belt buckle 11. Seat cushion outer finisher (LH)
Passenger side front seat
bolt torque: 40 Nm (4.1 kg-m, 30 ft-lb)
AWJIA0921ZZ
Revision: August 2015
2016 Versa Note

cardiagn.com

Page 2836 of 3641

NISSAN NOTE 2016 Service Repair Manual REAR SEATSE-23
< REMOVAL AND INSTALLATION >
C
DE
F
G H
I
K L
M A
B
SE
N
O P
REAR SEAT
Exploded ViewINFOID:0000000012432041
REAR SEAT WITH ARMREST
AWJIA1138ZZ
1. Seatback hinge trim 2. Seatback hinge 3

Page 2837 of 3641

NISSAN NOTE 2016 Service Repair Manual SE-24
< REMOVAL AND INSTALLATION >
REAR SEAT
7. Headrest holder (free)8. Seatback latch bracket (RH) 9. Seatback latch (RH)
10. Seatback frame (RH) 11. Seatback latch finisher (RH) 12. Seatback latch

Page 2838 of 3641

NISSAN NOTE 2016 Service Repair Manual REAR SEATSE-25
< REMOVAL AND INSTALLATION >
C
DE
F
G H
I
K L
M A
B
SE
N
O P
REAR SEAT WITHOUT ARMREST
AWJIA1137ZZ
1. Seatback hinge trim 2. Seatback hinge 3. Seatback striker
4. Headrest 5. Seatback(R

Page 2839 of 3641

NISSAN NOTE 2016 Service Repair Manual SE-26
< REMOVAL AND INSTALLATION >
REAR SEAT
SEAT CUSHION
SEAT CUSHION : Removal and InstallationINFOID:0000000012432042
REMOVAL
1. Lift up the seat cushion assembly front edge (B) to release it from

Page 2840 of 3641

NISSAN NOTE 2016 Service Repair Manual REAR SEATSE-27
< REMOVAL AND INSTALLATION >
C
DE
F
G H
I
K L
M A
B
SE
N
O P
Seatback (RH)
1. Place the seatback (RH) in the folded down position.
2. Release hook fasteners (A).
3. Remove bolts (B) and

Load next 8 pages
